| Citation: | ZHANG Jie, PANG Jian, ZHANG Siwen, WAN Yuping, JIA Wenyu, LEI Yang, FU Jianghua. Control of interior Low Frequency Booming Based on Vehicle Liftgate Constraints[J]. Journal of Southwest Jiaotong University, 2023, 58(2): 280-286. doi: 10.3969/j.issn.0258-2724.20210979
|
The liftgate is generally installed and fixed to the vehicle body through hinges, lock pins, sealing and buffers, whose rigid body modes vibrations are coupled with the passenger acoustic cavity modes, which are the main cause of low frequency booming noise. In this paper, a one-dimensional plate-cavity coupled analytical model including liftgate vibration and passenger acoustic cavity is established, and the effect of the boundary constraints stiffness on panel vibration and sound pressure level in cavity is analytically studied and experimentally verified in real vehicles. The theoretical results show that the sound pressure amplitude in cavity increases along the direction away from the liftgate and reaches the maximum value at the bottom location. The amplitude at the peak frequency of panel’s surface velocity and sound pressure level in cavity decreases with decreasing of stiffness of constraints. In the frequency range of 20−30 Hz, the amplitude at the peak frequency of sound pressure level at front seat is 8 dB(A) higher than that at middle seat and rear seat, which validates the theoretical results. The coupling sound pressure in the passenger cabin decreases with the increase of the relative position of the lockpin and the decrease of the relative height of the buffers. When the lockpin is increased 2 mm towards the rear of the vehicle body or the relative height of bumpers is decreased 2 mm, the liftgate vibration velocity can be reduced by 0.002−0.003 m/s, and the sound pressure level of the front row can be reduced by 3.5−14.8 dB(A).
| [1] |
QATU M S, ABDELHAMID M K, PANG J, et al. Overview of automotive noise and vibration[J]. International Journal of Vehicle Noise and Vibration, 2009, 5(1/2): 1-34. doi: 10.1504/IJVNV.2009.029187
|
| [2] |
庞剑, 谌刚, 何华. 汽车噪声与振动: 理论与应用[M]. 北京: 北京理工大学出版社, 2006: 93-94. .
|
| [3] |
PANG J. Noise and vibration control in automotive bodies[M]. Chichester: John Wiley & Sons Ltd., 2018: 105-106.
|
| [4] |
PANG J, ZHANG J, ZHANG J, et al. A simplified model for vehicle body panel vibration and sound radiation and interior booming control[C]//21st International Congress on Sound and Vibration 2014. Beijing: International Institute of Acoustics and Vibrations, 2014: 920-927.
|
| [5] |
ZHANG J, PANG J, ZHANG J, et al. Experimental and simulation analysis of interior booming induced by vehicle body panel vibration[C]//23rd International Congress on Sound and Vibration: From Ancient to Modern Acoustics. Athens: International Institute of Acoustics and Vibrations, 2019, 28-39.
|
| [6] |
ZHANG J, PANG J, WAN Y P, et al. Research and application of reinforcement beams supporting body panel on attenuation of low frequency vibration and sound radiation[C]//Proceedings of China SAE Congress 2019: Selected Papers. Singapore: [s.n.], 2021, 646: 861-871.
|
| [7] |
WAN Y P, PANG J, ZHANG J, et al. Research and application of lumped mass damper on the control of vehicle body panel low frequency vibration and sound radiation[J]. INTER-NOISE and NOISE-CON Congress and Conference Proceedings, 2019, 259(8): 1390-1398.
|
| [8] |
宋福强,罗培智. SUV后背门振动对车内噪声影响的研究[J]. 汽车技术,2017(6): 35-39. doi: 10.3969/j.issn.1000-3703.2017.06.007
SONG Fuqiang, LUO Peizhi. Research on the influence of liftgate vibration of SUV on interior noise[J]. Automobile Technology, 2017(6): 35-39. doi: 10.3969/j.issn.1000-3703.2017.06.007
|
| [9] |
OSAWA T, IWAMA A. A study of the vehicle acoustic control for booming noise utilizing the vibration characteristics of trunk lid[C]//SAE Technical Paper Series. Warrendale: SAE International, 1986, 861410.1-861410.12.
|
| [10] |
SUNG S, CHAO S, LINGALA H, et al. Structural-acoustic analysis of vehicle body panel participation to interior acoustic boom noise[C]//SAE Technical Paper Series.Warrendale: SAE International, 2011: 0496.1-0496.7.
|
| [11] |
GUPTA G, GAUTAM R, JAIN C P. Study of coupling behavior of acoustic cavity modes to improve booming noise in passenger vehicles[C]//SAE Technical Paper Series. Warrendale: SAE International, 2014: 1974.1-1974.8.
|
| [12] |
DOWELL E H, GORMAN G F Ⅲ, SMITH D A. Acoustoelasticity: General theory, acoustic natural modes and forced response to sinusoidal excitation, including comparisons with experiment[J]. Journal of Sound and Vibration, 1977, 52(4): 519-542. doi: 10.1016/0022-460X(77)90368-6
|
| [13] |
KIM S M, BRENNAN M J. A compact matrix formulation using the impedance and mobility approach for the analysis of structural-acoustic systems[J]. Journal of Sound and Vibration, 1999, 223(1): 97-113. doi: 10.1006/jsvi.1998.2096
|
| [14] |
ZHANG J, PANG J, WAN Y P, et al. Analysis of structure−acoustic coupling characteristics between adjacent flexible panels and enclosed cavity[J]. Journal of Vibration and Acoustics, 2021, 143(2): 021006.1-021006.9.
|
