Research Advances in Application of Piezoelectric Sensing Technology in Tunnel and Underground Engineering
-
摘要:
随着隧道与地下工程不断向大埋深及复杂环境条件发展，围岩-支护体系监测面临高地应力、多物理场耦合和病害隐蔽性强等挑战，传统监测方法在局部隐蔽损伤识别、动态事件捕获及长期环境适应性方面已难以满足精细化感知需求. 压电传感技术因具有高频响应、主被动一体化监测及良好嵌入性等优势，已从桥梁和岩土工程逐步拓展至隧道与地下工程领域. 本文系统综述了压电传感技术的基本机理、监测模式及其在围岩-支护体系受力与变形监测、衬砌病害识别、动力扰动与灾变响应感知、复杂环境下性能劣化表征以及阵列化、分布式和无线监测中的研究进展. 压电传感技术在地下工程局部损伤识别和动态响应监测中已表现出较大应用潜力. 未来应重点围绕压电响应机理与参数反演、复杂环境下长期服役可靠性、阵列化与系统化工程部署以及机理约束与数据驱动融合的智能识别方法开展研究. 压电传感技术有望成为智能隧道与地下工程全寿命安全监测的重要发展方向.
Abstract:As tunnel and underground engineering continue to advance toward greater burial depths and increasingly complex environmental conditions, monitoring of the surrounding rock–support system faces growing challenges, including high geostress, multi-physical field coupling, and the strong concealment of structural defects. Conventional monitoring methods have become increasingly inadequate for refined perception, particularly in the identification of localized concealed damage, the capture of dynamic events, and long-term environmental adaptability. Owing to its high-frequency response, active and passive integrated monitoring capability, and good embeddability, piezoelectric sensing technology has gradually expanded from bridges and geotechnical engineering into the field of tunnels and underground engineering. The fundamental mechanisms and monitoring modes of piezoelectric sensing technology were systematically reviewed, as well as its research progress in force and deformation monitoring of surrounding rock–support systems, lining defect identification, dynamic disturbance and disaster-response perception, performance degradation characterization under complex environments, and array-based, distributed, and wireless monitoring. The huge application potential of piezoelectric sensing technology was exhibited in local damage identification and dynamic response monitoring in underground engineering. Future research should focus on piezoelectric response mechanisms and parameter inversion, long-term service reliability under complex environments, array-based and systematic engineering deployment, and intelligent identification methods integrating mechanism constraints with data-driven approaches. Piezoelectric sensing technology is expected to be a key development direction for full-life cycle safety monitoring in intelligent tunnels and underground engineering.
-
图 1 压电正、逆效应及极化方向示意
Figure 1. Direct and converse piezoelectric effects and polarization direction
图 5 压电传感主动监测模式（波动法）示意
Figure 5. Active monitoring mode based on piezoelectric sensing (wave method)
图 6 压电传感主动监测模式（机电阻抗法）示意
Figure 6. Active monitoring mode based on piezoelectric sensing （EMI）
图 7 基于压电传感的围岩-锚杆监测原理示意
Figure 7. Monitoring principle of surrounding rock and anchor rods based on piezoelectric sensing
图 8 隧道衬砌裂缝与背后脱空的压电检测原理示意
Figure 8. Piezoelectric detection principle for tunnel lining cracks and behind-lining voids
图 9 压电传感识别冻融循环土体强度原理示意
Figure 9. Principle of piezoelectric sensing for identifying strength of freeze-thaw cyclic soil
图 10 隧道压电阵列与无线监测系统总体框架
Figure 10. Overall framework of piezoelectric array and wireless monitoring system in tunnel
表 1 压电材料常用性能参数
Table 1. Common performance parameters of piezoelectric materials
名称 符号 意义 压电系数 d33 是压电材料压电效应强弱程度的度量，直接关系到压电陶瓷传感器输出的灵敏度 弹性常数 cij 与压电材料的质地有关，其大小决定了压电元件的固有频率和动态特性 机电耦合系数 κ 反映压电材料机电能量转换效率的重要参数 机械品质因子 Qm 表征材料机械损耗的倒数量级，越大表示机械损耗越小、谐振特性更尖锐，更适合高功率、谐振型换能器
下载: 导出CSV
-
[1] 莫言迟, 刘占省, 刘子昌, 等. 大型隧道施工过程安全数字孪生建模方法与优化分析[J]. 应用基础与工程科学学报, 2025, 33(3): 843-855.MO Yanchi, LIU ZhanSheng, LIU Zichang, et al. Digital twin modelling approach and optimization analysis for safety in large tunnel construction processes[J]. Journal of Basic Science and Engineering, 2025, 33(3): 843-855. [2] 戴正彬, 卢云龙. 盾构超近距离下穿对既有隧道变形的影响[J]. 岩土工程学报, 2025, 47(10): 2154-2162.DAI Zhengbin, LU Yunlong. Influence of ultra-close undercrossing shield on deformation of existing tunnels[J]. Chinese Journal of Geotechnical Engineering, 2025, 47(10): 2154-2162. [3] 相懋龙, 阳军生, 吴剑, 等. 水平互层围岩铁路隧道底部变形模型试验研究[J]. 铁道学报, 2025(3): 168-177.XIANG Maolong, YANG Junsheng, WU Jian, et al. Model experimental study of deformation at bottom of railway tunnels in horizontally interbedded surrounding rocks[J]. Journal of the China Railway Society, 2025(3): 168-177. [4] 程刚, 王振雪, 朱鸿鹄, 等. 基于分布式光纤感测的岩土体变形监测研究综述[J]. 激光与光电子学进展, 2022, 59(19): 1900004. doi: 10.3788/LOP202259.1900004CHENG Gang, WANG Zhenxue, ZHU HongHu, et al. Research review of rock and soil deformation monitoring based on distributed fiber optic sensing[J]. Laser & Optoelectronics Progress, 2022, 59(19): 1900004. doi: 10.3788/LOP202259.1900004 [5] 《中国公路学报》编辑部. 中国交通隧道工程学术研究综述•2022[J]. 中国公路学报, 2022, 35(4): 1-40.Editorial Department of China Journal of Highway and Transport. Review on China’s traffic tunnel engineering research: 2022[J]. China Journal of Highway and Transport, 2022, 35(4): 1-40. [6] HASSANI S, DACKERMANN U. A systematic review of advanced sensor technologies for non-destructive testing and structural health monitoring[J]. Sensors, 2023, 23(4): 2204. doi: 10.3390/s23042204 [7] YASSIN M H, FARHAT M H, SOLEIMANPOUR R, et al. Fiber bragg grating (FBG)-based sensors: a review of technology and recent applications in structural health monitoring (SHM) of civil engineering structures[J]. Discover Civil Engineering, 2024, 1(1): 151. doi: 10.1007/s44290-024-00141-4 [8] ALHUSSEIN A N D, QAID M R T M, AGLIULLIN T, et al. Fiber bragg grating sensors: design, applications, and comparison with other sensing technologies[J]. Sensors, 2025, 25(7): 2289. doi: 10.3390/s25072289 [9] DING L, SUN Y J, ZHANG W Z, et al. Stress monitoring of segment structure during the construction of the small-diameter shield tunnel[J]. Sensors, 2023, 23(19): 8023. doi: 10.3390/s23198023 [10] ABBAS N, UMAR T, SALIH R, et al. Structural health monitoring of underground metro tunnel by identifying damage using ANN deep learning auto-encoder[J]. Applied Sciences, 2023, 13(3): 1332. doi: 10.3390/app13031332 [11] COLLINS E, PANTOYA M, NEUBER A A, et al. Piezoelectric ignition of nanocomposite energetic materials[J]. Journal of Propulsion and Power, 2014, 30(1): 15-18. doi: 10.2514/1.B35034 [12] PYUN J Y, KIM Y H, PARK K K. Design of piezoelectric acoustic transducers for underwater applications[J]. Sensors, 2023, 23(4): 1821. doi: 10.3390/s23041821 [13] MESHKINZAR A, M AL-JUMAILY A. Cylindrical piezoelectric PZT transducers for sensing and actuation[J]. Sensors, 2023, 23(6): 3042. doi: 10.3390/s23063042 [14] LIU J F, GAO X Y, JIN H N, et al. Miniaturized electromechanical devices with multi-vibration modes achieved by orderly stacked structure with piezoelectric strain units[J]. Nature Communications, 2022, 13: 6567. doi: 10.1038/s41467-022-34231-7 [15] YU Y L, CHENG Z, CHANG J L, et al. Enhanced in-plane omnidirectional energy harvesting from extremely weak magnetic fields via fourfold symmetric magneto-mechano-electric coupling[J]. Advanced Energy Materials, 2024, 14(43): 2402487. doi: 10.1002/aenm.202402487 [16] CHENG Z, ZHOU J, WANG B, et al. A bionic flapping magnetic-dipole resonator for ELF cross-medium communication[J]. Advanced Science, 2024, 11(30): 2403746. [17] JU M, DOU Z S, LI J W, et al. Piezoelectric materials and sensors for structural health monitoring: fundamental aspects, current status, and future perspectives[J]. Sensors, 2023, 23(1): 543. doi: 10.3390/s23010543 [18] LE T C, LUU T H T, NGUYEN H P, et al. Piezoelectric impedance-based structural health monitoring of wind turbine structures: current status and future perspectives[J]. Energies, 2022, 15(15): 5459. doi: 10.3390/en15155459 [19] PARIDA L, MOHARANA S. A comprehensive review on piezo impedance based multi sensing technique[J]. Results in Engineering, 2023, 18: 101093. doi: 10.1016/j.rineng.2023.101093 [20] JIN J P, XU W C, LI P F, et al. Advances in the development of piezoelectric smart aggregates for structural health monitoring[J]. Journal of Intelligent Construction, 2024, 2(3): 1-20. doi: 10.26599/jic.2024.9180016 [21] ZHANG H, WANG L L, LI J J, et al. Embedded PZT aggregates for monitoring crack growth and predicting surface crack in reinforced concrete beam[J]. Construction and Building Materials, 2023, 364: 129979. doi: 10.1016/j.conbuildmat.2022.129979 [22] 霍林生, 黄颖, 任亮, 等. 基于近场动力学理论与声发射技术的钢材裂纹扩展中能量释放特征研究[J]. 计算力学学报, 2025, 42(4): 664-669.HUO Linsheng, HUANG Ying, REN Liang, et al. Characterization of energy release in steel crack extension based on peridynamic theory and acoustic emission technique[J]. Chinese Journal of Computational Mechanics, 2025, 42(4): 664-669. [23] 张耀文, 何颖, 赵晶, 等. 压电阻抗法最优检测频段选择试验研究[J]. 大连交通大学学报, 2023, 44(6): 113-117.ZHANG Yaowen, HE Ying, ZHAO Jing, et al. Experiment study of optimal frequency range selection for electro-mechanical impedance technique[J]. Journal of Dalian Jiaotong University, 2023, 44(6): 113-117. [24] 张耀文, 何颖, 赵晶, 等. 压电阻抗法中PZT片的形状选择研究[J]. 传感器与微系统, 2024, 43(4): 45-48, 52. doi: 10.13873/J.1000-9787(2024)04-0045-04ZHANG Yaowen, HE Ying, ZHAO Jing, et al. Study on shape selection of PZT patch for electro mechanical impedance method[J]. Transducer and Microsystem Technologies, 2024, 43(4): 45-48, 52. doi: 10.13873/J.1000-9787(2024)04-0045-04 [25] 张耀文, 赵晶, 何颖, 等. PZT尺寸与位置对传感器导纳的影响[J]. 压电与声光, 2022, 44(4): 638-642, 646.ZHANG Yaowen, ZHAO Jing, HE Ying, et al. Study on influence of size and bonding location of PZT on sensor admittance[J]. Piezoelectrics & Acoustooptics, 2022, 44(4): 638-642, 646. [26] 张耀文, 赵晶, 何颖, 等. 三种PZT薄片粘贴状态的导纳理论模型的适用性分析[J]. 传感技术学报, 2023, 36(12): 1878-1885.ZHANG Yaowen, ZHAO Jing, HE Ying, et al. Fitness comparison of three admittance models of the PZT patch after bonded[J]. Chinese Journal of Sensors and Actuators, 2023, 36(12): 1878-1885. [27] SUN R, LU Y F, LIU G, et al. Damage identification of steel-ECC composite deck incorporating piezoelectric impedance methodology and hierarchical clustering analysis[J]. Archives of Civil and Mechanical Engineering, 2024, 24(3): 187. doi: 10.1007/s43452-024-00999-2 [28] ZHANG Z W, XIANG H J, WANG J J, et al. Broadband energy harvesting from high-speed railway bridge vibrations using piezoelectric energy harvester arrays[J]. Mechanical Systems and Signal Processing, 2025, 241: 113511. doi: 10.1016/j.ymssp.2025.113511 [29] GAUTE-ALONSO A, GARCIA-SANCHEZ D, ALONSO-COBO C, et al. Temporary cable force monitoring techniques during bridge construction-phase: the Tajo River Viaduct experience[J]. Scientific Reports, 2022, 12: 7689. doi: 10.1038/s41598-022-11746-z [30] LIU Z M, CAI G J, WANG J, et al. Evaluation of mechanical and electrical properties of a new sensor-enabled piezoelectric geocable for landslide monitoring[J]. Measurement, 2023, 211: 112667. doi: 10.1016/j.measurement.2023.112667 [31] WANG J, RAO Y, GAO Z Y, et al. Evaluation of mechanical and sensing performance of a new sensor-enabled piezoelectric geosynthetic material[J]. Journal of Materials in Civil Engineering, 2024, 36(11): 06024005. doi: 10.1061/JMCEE7.MTENG-17458 [32] HONG X, PAN C, ZUO Y J, et al. Multifaceted characteristics of acoustic emission damage and precursor indicators of instability in sandstone under cyclic impact loading[J]. Scientific Reports, 2025, 15: 19859. doi: 10.1038/s41598-025-04900-w [33] WEN M, MIAO L J, GUAN X C. High-compatibility thick-film smart aggregates for strain monitoring of concrete[J]. International Journal of Smart and Nano Materials, 2025, 16(3): 596-611. doi: 10.1080/19475411.2025.2534964 [34] PHAM Q Q, DANG N L, KIM J T. Smart PZT-embedded sensors for impedance monitoring in prestressed concrete anchorage[J]. Sensors, 2021, 21(23): 7918. doi: 10.3390/s21237918 [35] HAN G S, SU Y F, HE R, et al. Real-time concrete strength monitoring using piezoelectric sensors and deep learning[J]. Nature Communications, 2026, 17: 473. doi: 10.1038/s41467-025-67168-8 [36] ZHONG H Q, SHUAI L W, DENG D M. Research on concrete structure damage detection based on piezoelectric sensing technology and morphological fractal method[J]. Scientific Reports, 2025, 15: 26604. doi: 10.1038/s41598-025-11619-1 [37] 余慧芬, 祁核, 涂小牛, 等. 高温压电振动传感器及其压电材料研究进展[J]. 物理学报, 2025, 74(2): 176-205. doi: 10.7498/aps.74.20240906YU Huifen, QI He, TU Xiaoniu, et al. Research progress of high-temperature piezoelectric vibration sensors and piezoelectric materials[J]. Acta Physica Sinica, 2025, 74(2): 176-205. doi: 10.7498/aps.74.20240906 [38] 杜荣华, 朱胜亿, 魏克湘, 等. 交通环境能量采集及自供能交通设施健康状态监测研究进展[J]. 仪器仪表学报, 2022, 43(3): 3-23.DU Ronghua, ZHU Shengyi, WEI Kexiang, et al. Research progress of energy harvesting in transportation environment and self-powered transportation infrastructure health monitoring[J]. Chinese Journal of Scientific Instrument, 2022, 43(3): 3-23. [39] FAN X Y, LI J, HAO H. Review of piezoelectric impedance based structural health monitoring: Physics-based and data-driven methods[J]. Advances in Structural Engineering, 2021, 24(16): 3609-3626. doi: 10.1177/13694332211038444 [40] GUAN L J, MEHDI D, LI H X, et al. Covalent organic frameworks: an emerging class of piezoelectric materials for mechanical energy transfer application[J]. Chinese Chemical Letters, 2025: 111389. [41] DE MARZO G, FACHECHI L, ANTONACI V, et al. On the measurement of piezoelectric d33 coefficient of soft thin films under weak mechanical loads: a rapid and affordable method[J]. Materials & Design, 2024, 247: 113399 doi: 10.1016/j.matdes.2024.113399 [42] CUI G L, QI J J, LIANG Z H, et al. Growth of noncentrosymmetric two-dimensional single crystals[J]. Precision Chemistry, 2024, 2(7): 330-354. doi: 10.1021/prechem.3c00122 [43] CHAKKORIA J J, DUBEY A, MITCHELL A, et al. Ferroelectric domain engineering of Lithium niobate[J]. Opto-Electronic Advances, 2025, 8(2): 240139. [44] YE Z J, ZHENG R, LI S J, et al. A review: recent advances of piezoelectric photocatalysis in the environmental fields[J]. Nanomaterials, 2024, 14(20): 1641. doi: 10.3390/nano14201641 [45] GILL M, MÁTHÉ M T, SALAMON P, et al. From solid to liquid piezoelectric materials[J]. Materials Horizons, 2025, 12(21): 8920-8942. doi: 10.1039/D5MH00917K [46] VISHNOI S, KUMARI G, GUEST R, et al. High-throughput computational screening of small molecular crystals for sustainable piezoelectric materials[J]. Angewandte Chemie International Edition, 2025, 64(18): e202501232. doi: 10.1002/anie.202501232 [47] KAARTHIK J, JANG J. Advancements in PZT-based and relaxor–PT piezoelectric single crystals: Synthesis, properties, and applications in IoT, biomedical, and engineering systems[J]. Ceramics International, 2025, 51(28): 58515-58541. doi: 10.1016/j.ceramint.2025.10.177 [48] YAN X D, ZHENG M P, GAO X, et al. Ultrahigh energy harvesting performance in lead-free piezocomposites with intragranular structure[J]. Acta Materialia, 2022, 222: 117450. doi: 10.1016/j.actamat.2021.117450 [49] 杨皓迪, 杨勋午, 唐义贵, 等. 压电耦合光-电催化在能源环境应用领域的研究进展[J/OL]. 环境化学, 2026-04-20. https://link.cnki.net/urlid/11.1844.X.20250826.1054.004. [50] 吴杰, 杨帅, 王明文, 等. 铅基织构压电陶瓷的发展历程、现状与挑战[J]. 无机材料学报, 2025, 40(6): 575-586. doi: 10.15541/jim20240533WU Jie, YANG Shuai, WANG Mingwen, et al. Textured PT-based piezoelectric ceramics: development, status and challenge[J]. Journal of Inorganic Materials, 2025, 40(6): 575-586. doi: 10.15541/jim20240533 [51] 张广明, 艾明理, 宋道森, 等. 压电陶瓷3D打印研究进展[J]. 航空制造技术, 2025, 68(8): 46-56.ZHANG Guangming, AI Mingli, SONG Daosen, et al. Research progress on 3D printing of piezoelectric ceramics[J]. Aeronautical Manufacturing Technology, 2025, 68(8): 46-56 [52] 许明浩, 花开慧, 曾群, 等. 钛酸钡与铌酸钾钠无铅压电陶瓷研究进展[J]. 硅酸盐通报, 2024, 43(2): 649-658, 694.XU Minghao, HUA Kaihui, ZENG Qun, et al. Research progress of barium titanate and potassium sodium niobate lead-free piezoelectric ceramics[J]. Bulletin of the Chinese Ceramic Society, 2024, 43(2): 649-658, 694. [53] 戚相成, 任鹏荣, 同向前. 铌酸钾钠基电工新型压电陶瓷电致应变及温度稳定性研究进展[J]. 高电压技术, 2023, 49(7): 2831-2840.QI Xiangcheng, REN Pengrong, TONG Xiangqian. Research progress in the electrostrain and temperature stability of potassium sodium niobate-based electrician novel piezoelectric ceramics[J]. High Voltage Engineering, 2023, 49(7): 2831-2840. [54] 李炬, 刘雯雯, 谢传乐, 等. PVDF柔性压电传感纺织品的研究进展[J]. 东华大学学报(自然科学版), 2025, 51(5): 177-187. doi: 10.19886/j.cnki.dhdz.2025.0201LI Ju, LIU Wenwen, XIE Chuanle, et al. Research progress on PVDF flexible piezoelectric sensing textiles[J]. Journal of Donghua University (Natural Science), 2025, 51(5): 177-187. doi: 10.19886/j.cnki.dhdz.2025.0201 [55] 姜昆, 李乐天, 郑木鹏, 等. PZT陶瓷的低温烧结研究进展[J]. 无机材料学报, 2025, 40(6): 627-638. doi: 10.15541/jim20240513JIANG Kun, LI Letian, ZHENG Mupeng, et al. Research progress on low-temperature sintering of PZT ceramics[J]. Journal of Inorganic Materials, 2025, 40(6): 627-638. doi: 10.15541/jim20240513 [56] 戴中华, 谢景龙, 琚思懿, 等. BT基无铅压电陶瓷的最新进展[J]. 电子元件与材料, 2018, 37(8): 1-9. doi: 10.14106/j.cnki.1001-2028.2018.08.001DAI Zhonghua, XIE Jinglong, JU Siyi, et al. Latest progress on BaTiO3-based lead-free piezoelectric ceramics[J]. Electronic Components and Materials, 2018, 37(8): 1-9. doi: 10.14106/j.cnki.1001-2028.2018.08.001 [57] 姜河, 王树伦, 庄杰, 等. KNN基无铅压电陶瓷研究进展[J]. 兵器材料科学与工程, 2020, 43(2): 118-122. doi: 10.11896/cldb.21090233JIANG He, WANG Shulun, ZHUANG Jie, et al. Research progress in KNN-based lead-free piezoelectric ceramics[J]. Ordnance Material Science and Engineering, 2020, 43(2): 118-122. doi: 10.11896/cldb.21090233 [58] 雷炳育, 黄建军, 陈婷婷, 等. 逐层静电纺丝-热压技术制备全有机复合电介质薄膜[J]. 材料工程, 2025, 53(9): 211-218.LEI Bingyu, HUANG Jianjun, CHEN Tingting, et al. Preparation of all-organic composite dielectric films by layer-by-layer electrospinning-hot pressing technique[J]. Journal of Materials Engineering, 2025, 53(9): 211-218. [59] 徐子硕, 胡悦娟, 胡宇晨, 等. 粉末热压法制备高性能n型PVDF/Ag2Se自支撑柔性复合热电薄膜[J]. 无机材料学报, 2026, 41(4): 462-468.XU Zishuo, HU Yuejuan, HU Yuchen, et al. High-performance n-type PVDF/Ag2Se free-standing flexible composite thermoelectric films fabricated by powder hot-pressing[J]. Journal of Inorganic Materials, 2026, 41(4): 462-468. [60] 高莉宁, 丁思晴, 佘江江, 等. 压电技术在智能道路中应用研究现状[J]. 科学技术与工程, 2023, 23(27): 11486-11495.GAO Lining, DING Siqing, SHE Jiangjiang, et al. Research status of piezoelectric technology application in intelligent road[J]. Science Technology and Engineering, 2023, 23(27): 11486-11495. [61] 张玉栋, 丛晓红, 赵玉婕, 等. 基于碳纳米管改性0-3-1型水泥基压电复合材料诱导极化工艺的研究[J]. 新型建筑材料, 2020, 47(6): 6-8.ZHANG Yudong, CONG Xiaohong, ZHAO Yujie, et al. Study on induction polarization process of carbon nanotube modified 0-3-1 type cement-based piezoelectric composites[J]. New Building Materials, 2020, 47(6): 6-8. [62] LIU W B, ZHENG T, ZHOU Z Y, et al. Ultrahigh piezoelectricity and temperature stability in piezoceramics by synergistic design[J]. Nature Communications, 2025, 16: 1527. [63] GONG G Y, YOU Y, SHEN H J, et al. 3D printing piezoelectric materials: Innovations, challenges, and future perspectives[J]. Materials Today Sustainability, 2025, 32: 101257. [64] SUKUMARAN S, SZEWCZYK P K, KNAPCZYK-KORCZAK J, et al. Optimizing piezoelectric coefficient in PVDF fibers: key strategies for energy harvesting and smart textiles[J]. Advanced Electronic Materials, 2023, 9(12): 2300404. [65] ZHOU Y X, MA Z P, FU L. A review of key signal processing techniques for structural health monitoring: highlighting non-parametric time-frequency analysis, adaptive decomposition, and deconvolution[J]. Algorithms, 2025, 18(6): 318. [66] ZHANG C W, MOUSAVI A A, HERNANDEZ GARCIA M R, et al. Vibration feature extraction using signal processing techniques for structural health monitoring: a review[J]. Mechanical Systems and Signal Processing, 2022, 177: 109175. [67] HE F, YE Q. A bearing fault diagnosis method based on wavelet packet transform and convolutional neural network optimized by simulated annealing algorithm[J]. Sensors, 2022, 22(4): 1410. [68] ZHANG Y L, XIE X Y, LI H Q, et al. An unsupervised tunnel damage identification method based on convolutional variational auto-encoder and wavelet packet analysis[J]. Sensors, 2022, 22(6): 2412. [69] WANG J K, HUO L S, LIU C G, et al. Theoretical and experimental study on homologous acoustic emission signal recognition based on synchrosqueezed wavelet transform coherence[J]. Structural Control and Health Monitoring, 2023, 2023(1): 6968338. [70] DE CARVALHO MONSON P M, DE OLIVEIRA CONCEIÇÃO P J, LOFRANO DOTTO F R, et al. Structural damage classification in composite materials using the Wigner-Ville distribution and convolutional neural networks[J]. Materials Letters, 2024, 369: 136734. [71] REDDY A S S, PACHORI R B. Dynamic mode decomposition-based technique for cross-term suppression in the Wigner-Ville distribution[J]. Digital Signal Processing, 2025, 156: 104833. [72] ÇELEBI M, ÖZTÜRK S, KAPLAN K. An enhanced deep learning model based on smoothed pseudo Wigner-Ville distribution technique for emotion recognition with channel selection[J]. Ain Shams Engineering Journal, 2025, 16(2): 103264. [73] GOMEZ-CABRERA A, ESCAMILLA-AMBROSIO P J. Review of machine-learning techniques applied to structural health monitoring systems for building and bridge structures[J]. Applied Sciences, 2022, 12(21): 10754. [74] WONG V K, RABEEK S M, LAI S C, et al. Active ultrasonic structural health monitoring enabled by piezoelectric direct-write transducers and edge computing process[J]. Sensors, 2022, 22(15): 5724. [75] 郭师峰, 李叶海, 李振, 等. 柔性超声传感结构健康监测技术现状与展望[J]. 振动、测试与诊断, 2020, 40(3): 427-436, 620.GUO Shifeng, LI Yehai, LI Zhen, et al. The status and prospects of flexible transducers in ultrasonic waves-based structural health monitoring[J]. Journal of Vibration, Measurement & Diagnosis, 2020, 40(3): 427-436, 620. [76] 张继轩, 豆涵杰, 刘涛, 等. 基于MEMS声发射传感器的齿轮故障检测系统[J]. 压电与声光, 2024, 46(5): 638-643.ZHANG Jixuan, DOU Hanjie, LIU Tao, et al. Gear fault detection system based on MEMS acoustic emission sensor[J]. Piezoelectrics & Acoustooptics, 2024, 46(5): 638-643. [77] 杨俊涛, 左文建, 张文龙, 等. 压电陶瓷传感器监测混凝土内部缺陷的可行性研究[J]. 硅酸盐通报, 2023, 42(1): 111-122.YANG Juntao, ZUO Wenjian, ZHANG Wenlong, et al. Feasibility study on internal defect monitoring of concrete structure based on piezoceramics transducer[J]. Bulletin of the Chinese Ceramic Society, 2023, 42(1): 111-122. [78] 许凯, 黄艳, 鲁光涛, 等. 爆炸荷载作用下BFRC梁的压电骨料损伤评估研究[J]. 爆破, 2022, 39(4): 17-24, 79.XU Kai, HUANG Yan, LU Guangtao, et al. Damage evaluation of BFRC beams under blast loadings using piezoelectric smart aggregates[J]. Blasting, 2022, 39(4): 17-24, 79. [79] 熊飞, 苏波, 王岗. 基于压电波动法的混凝土梁裂缝深度与位置监测[J]. 江苏大学学报(自然科学版), 2022, 43(3): 359-365.XIONG Fei, SU Bo, WANG Gang. Monitoring of crack depth and location of concrete beam based on piezoelectric wave method[J]. Journal of Jiangsu University (Natural Science Edition), 2022, 43(3): 359-365. [80] 常琦, 贺代兵, 徐勇, 等. 基于环形阵列相控阵的结构损伤扫描定位方法研究[J]. 振动与冲击, 2025, 44(18): 284-290, 325.CHANG Qi, HE Daibing, XU Yong, et al. Structural damage scanning and localization method based on annular array phased array[J]. Journal of Vibration and Shock, 2025, 44(18): 284-290, 325. [81] 田亮, 王宇宁, 樊立龙, 等. 单模态Lamb波检测板类结构损伤识别成像方法[J]. 交通运输工程学报, 2024, 24(6): 121-134.TIAN Liang, WANG Yuning, FAN Lilong, et al. Imaging method for damage inentification of plate structures detected by single mode Lamb waves[J]. Journal of Traffic and Transportation Engineering, 2024, 24(6): 121-134. [82] 齐宝欣, 李茉, 刘东, 等. 基于压电主动传感技术的高温后PVA-ECC梁冲击损伤监测研究[J]. 建筑科学与工程学报, 2018, 35(5): 233-240.QI Baoxin, LI Mo, LIU Dong, et al. Research on impact damage monitoring of PVA-ECC beam after high temperature based on piezoelectric active sensing technology[J]. Journal of Architecture and Civil Engineering, 2018, 35(5): 233-240. [83] 房芳, 郑辉, 汪玉, 等. 机械结构健康监测综述[J]. 机械工程学报, 2021, 57(16): 269-292.FANG Fang, ZHENG Hui, WANG Yu, et al. Mechanical structural health monitoring: a review[J]. Journal of Mechanical Engineering, 2021, 57(16): 269-292. [84] 周少杰, 廖明浩, 李湘明, 等. 基于机电阻抗法的套筒灌浆缺陷检测试验研究[J]. 压电与声光, 2021, 43(6): 809-813.ZHOU Shaojie, LIAO Minghao, LI Xiangming, et al. Experimental study on grouting defect detection for grouted splice sleeve connector based on electro-mechanical impedance method[J]. Piezoelectrics & Acoustooptics, 2021, 43(6): 809-813. [85] JIAO P C, EGBE K I, XIE Y W, et al. Piezoelectric sensing techniques in structural health monitoring: a state-of-the-art review[J]. Sensors, 2020, 20(13): 3730. [86] ZHANG Z Y, LIU Y, BAI Y X, et al. Intelligent debonding detection in GFRP rock bolts via piezoelectric time reversal and CNN-SVM model[J]. Sensors, 2025, 25(23): 1-17. [87] SUN Z G, WU K T, KRÜGER S E, et al. An ultrasonic rock bolt sensing technology (I): methodology and laboratory studies[J]. Rock Mechanics and Rock Engineering, 2024, 57(9): 7387-7406. [88] VARELIJA M, HARTLIEB P. Designing intelligent rock support systems to detect gravity-driven wedges[J]. Rock Mechanics and Rock Engineering, 2025, 58(4): 4527-4541. [89] JIANG G D, CAI L Y, ZHANG G Z. Applicability evaluation of piezoelectric sensing for measuring shield tunnel segment joints openings during operation[J]. Measurement, 2025, 253: 117468. [90] GODIO A, OGGERI C, SECCATORE J. An analysis of rock bolt dynamic responses to evaluate the anchoring degree of fixation[J]. Applied Sciences, 2025, 15(3): 1513. [91] YAN Q X, XIONG Z Y, ZHANG C, et al. Piezoelectric-enabled wave propagation method for detecting and assessing corrosion damage evolution in reinforced concrete shield tunnel lining[J]. Construction and Building Materials, 2025, 481: 141546. [92] JIANG G D, DAI M H, ZHANG G Z, et al. Piezoelectric sensing method for segmental joint contact stress during shield tunnel construction[J]. Underground Space, 2024, 17: 82-99. [93] XU H B, LIU Q C, LI B T, et al. Identification of shield tunnel segment joint opening based on annular seam pressure monitoring[J]. Sensors, 2024, 24(12): 3924. [94] LI C, LI J Q, LUO C, et al. Diagnosis and monitoring of tunnel lining defects by using comprehensive geophysical prospecting and fiber Bragg grating strain sensor[J]. Sensors, 2024, 24(6): 1749. [95] YANG W B, MA G Y, TU J L, et al. Effects of voids on the dynamic response of tunnels under train-induced vibration loads[J]. International Journal of Physical Modelling In Geotechnics, 2023, 23(2): 77-91. [96] TANG H X, LONG S G, LI T. Quantitative evaluation of tunnel lining voids by acoustic spectrum analysis[J]. Construction and Building Materials, 2019, 228: 116762. [97] WANG J L, XU J M, FAN J Q, et al. Experimental study on anti-explosion performance of the cavern reinforced by recoverable deformation energy absorption bolt[J]. Applied Sciences, 2023, 13(15): 8656. [98] WANG M, DING W J, ZHAO D K, et al. Blasting vibration law and prediction in the near-field of tunnel[J]. Shock and Vibration, 2022, 2022(1): 7412777. [99] 许江波, 晏长根, 伍法权, 等. 罗沙隧道洞口爆破振动研究[J]. 科学技术与工程, 2016, 16(9): 93-98.XU Jiangbo, YAN Changgen, WU Faquan, et al. Research on blasting vibration of the Luosha tunnel entrance[J]. Science Technology and Engineering, 2016, 16(9): 93-98. [100] ZHANG C, YAN Q X, XIONG Z Y, et al. Diagnosis and assessment of cyclic freeze–thaw damage in tunnel lining concrete using piezoelectric-based electromechanical impedance technique[J]. Measurement, 2024, 238: 115370. [101] ZHANG C, YAN Q X, LIAO X L, et al. Smart monitoring of cyclic freeze–thaw damage of lining concrete using dual-channel feature fusion of piezoelectric conductance and stress wave signals[J]. Structural Control and Health Monitoring, 2025, 2025(1): 8554958. [102] LIAO X L, YAN Q X, SU L F, et al. Automatic assessment of freeze–thaw damage in concrete structures using piezoelectric-based active sensing approach and deep learning technique[J]. Engineering Structures, 2024, 302: 117453. [103] 全晓娟, 龚禹为, 汪波, 等. 冻融循环对青藏黏土抗剪强度影响试验研究[J]. 冰川冻土, 2023, 45(3): 1016-1025.QUAN Xiaojuan, GONG Yuwei, WANG Bo, et al. Experimental study on the shear strength of Qinghai-Tibet clay under freeze-thaw cycles[J]. Journal of Glaciology and Geocryology, 2023, 45(3): 1016-1025. [104] 辜世旺, 全晓娟, 龚禹为, 等. 低温环境下基于压电陶瓷监测技术的土体强度试验研究[J]. 冰川冻土, 2024, 46(6): 1860-1870.GU Shiwang, QUAN Xiaojuan, GONG Yuwei, et al. Experimental study on soil strength based on piezoelectric ceramic monitoring technology in low-temperature environment[J]. Journal of Glaciology and Geocryology, 2024, 46(6): 1860-1870. [105] LI W, LEI S, CAO M S, et al. Corrosion damage identification in concrete underwater based on time reversal of stress waves[J]. Mechanical Systems and Signal Processing, 2023, 194: 110281. [106] ZHANG M, XU W D, XIE Y G. A leak sensing method for offshore oil pipeline using acoustic emission signals and machine learning[J]. Ocean Engineering, 2025, 336: 121768. [107] HUO L S, WANG B, CHEN D D, et al. Monitoring of pre-load on rock bolt using piezoceramic-transducer enabled time reversal method[J]. Sensors, 2017, 17(11): 2467. [108] WANG B, HUO L S, CHEN D D, et al. Impedance-based pre-stress monitoring of rock bolts using a piezoceramic-based smart washer: A feasibility study[J]. Sensors, 2017, 17(2): 250. [109] LIAO X L, YAN Q X, QIAO M J, et al. Deep learning-assisted damage diagnosis of tunnel lining segments using GAN-augmented electromechanical impedance data[J]. NDT & E International, 2026, 157: 103518. [110] 韩晨希, 黄宏伟, 欧阳凌涵, 等. 软土地基下城市超长地铁隧道的沉降与变形监测及时空数据插补方法[J]. 地质科技通报, 2024, 43(6): 152-161.HAN Chenxi, HUANG Hongwei, OUYANG Linghan, et al. Settlement and deformation monitoring and spatio-temporal data interpolation method for urban ultra long subway tunnels under soft soil foundation[J]. Bulletin of Geological Science and Technology, 2024, 43(6): 152-161. [111] LAMA B, MOMAYEZ M. Review of non-destructive methods for rock bolts condition evaluation[J]. Mining, 2023, 3(1): 106-120. -
