Optimal Configuration Scheme of Active Stray Current Mitigation Devices in Rail Transit
-
摘要:
杂散电流主动治理装置在轨道交通领域具有良好的应用前景，但其在供电区间内的配置方案难以有效适应动态杂散电流分布规律，致使在列车牵引或制动的峰值电流冲击下系统中杂散电流治理效能仍然面临着严峻的挑战. 为此，本文以直流自耦变压器（DCAT）型牵引供电系统为例，提出杂散电流主动治理装置在供电区间内的优化配置策略. 首先，建立轨道交通牵引供电系统模型，推导杂散电流和轨道电位抑制比，揭示主动治理装置对系统中杂散电流和轨道电位分布的影响规律；其次，结合列车运行特性，提出包含偏移强化、对称分布和峰值响应的优化配置原则，定义优化偏移率确定各主动治理装置的最优安装位置，开展配置优化前后系统中杂散电流和轨道电位治理效能的对比研究；最后，以北京地铁亦庄线为例进行仿真验证. 研究结果表明：所提优化配置策略在不增加主动治理装置数量的前提下显著提升了治理效能；仿真结果与理论计算的误差控制在3%以内；系统优化配置后，牵引变电所处最大轨道电位在牵引和制动工况下分别由传统系统的19.4%和24.5%降至5.9%和8.1%，最大杂散电流分别由53.1%和66.5%降至19.7%和26.6%.
Abstract:Active stray current mitigation devices show considerable potential for application in rail transit systems. However, the arrangement of these mitigation devices within power supply sections cannot effectively accommodate dynamic changes in stray current distribution, making it difficult to maintain effective stray current mitigation under peak current conditions during train traction or braking. Therefore, an optimal configuration strategy for these active stray current mitigation devices within power supply sections was proposed, using a DC autotransformer (DCAT)-based traction power supply system as an example. First, the rail transit traction power supply system model was established, and the suppression ratios of stray current and rail potential were derived to reveal the influence of these active devices on both stray current and rail potential distributions. Second, based on train operating characteristics, the optimal configuration principles incorporating offset enhancement, symmetric distribution, and peak response were proposed. The optimal installation positions of these active devices were determined by defining the optimized offset ratio, and the mitigation performance for stray current and rail potential in the system was compared before and after configuration optimization. Finally, the Beijing Metro Yizhuang Line was selected as a case study to validate the proposed strategy through simulations. The results show that the optimal configuration strategy significantly improves the mitigation performance without increasing the number of active devices. The error between simulation results and theoretical calculations is controlled within 3%. After configuration optimization, under traction and braking conditions, the maximum rail potential at the traction substation drops from 19.4% and 24.5% to 5.9% and 8.1%, respectively, while the maximum stray current drops from 53.1% and 66.5% to 19.7% and 26.6%, respectively, relative to the corresponding values in the conventional system.
-
Key words:
- rail transit /
- stray current /
- rail potential /
- active mitigation /
- optimal configuration
-
图 1 直流自耦变压器型牵引供电系统拓扑
Figure 1. Topology of DC autotransformer-based traction power supply system
图 3 主动治理装置现有配置方案下新型直流牵引供电系统中杂散电流和轨道电位抑制比
Figure 3. Suppression ratios of stray current and rail potential in novel DC traction power supply system under existing configuration of active stray current mitigation devices
图 4 三区段新型直流牵引供电系统内主动治理装置在不同配置方案下杂散电流和轨道电位抑制比
Figure 4. Suppression ratios of stray current and rail potential under different configurations of active stray current mitigation devices in three-section novel DC traction power supply system
图 5 北京地铁亦庄线宋家庄站至肖村站列车动态特性
Figure 5. Train dynamic characteristics from Songjiazhuang Station to Xiaocun Station on Beijing Subway Yizhuang Line
图 6 杂散电流和轨道电位的仿真与理论结果对比
Figure 6. Comparison of simulation and theoretical results for stray current and rail potential
表 1 牵引供电系统仿真参数
Table 1. Simulation parameters of traction power supply system
仿真参数 数值 仿真参数 数值 牵引变电所电压Us/V 750 走行轨电阻R/（mΩ•km−1） 10 牵引变电所功率P/MW 3 轨地过渡电阻Rg/（Ω•k•m） 15 供电区间长度L/m 2631 接触网电阻MR/（mΩ•km−1） 8.5 列车运行时间T/s 150 区间数量n/个 3 列车最大速度vmax/（km•h−1） 80 优化偏移率p/% 50
下载: 导出CSV
-
[1] 高仕斌, 罗嘉明, 陈维荣, 等. 轨道交通 “网-源-储-车” 协同供能技术体系[J]. 西南交通大学学报, 2024, 59(5): 959-979, 989. doi: 10.3969/j.issn.0258-2724.20220210Gao Shibin, Luo Jiaming, Chen Weirong, et al. Rail transit “network-source-storage-vehicle” collaborative energy supply technology system[J]. Journal of Southwest Jiaotong University, 2024, 59(5): 959-979,989. doi: 10.3969/j.issn.0258-2724.20220210 [2] 韩宝明, 李卓一, 靳雨馨, 等. 2024年世界城市轨道交通运营统计与分析综述[J]. 都市快轨交通, 2025, 38(1): 1-12. doi: 10.3969/j.issn.1672-6073.2025.01.001Han Baoming, Li Zhuoyi, Jin Yuxin, et al. Statistical analysis of urban rail transit operations worldwide in 2024: a review[J]. Urban Rapid Rail Transit, 2025, 38(1): 1-12. doi: 10.3969/j.issn.1672-6073.2025.01.001 [3] Li M Y, Yu H R, Geng Q Q, et al. Dynamic bidirectional relationship between urban rail transit and urban economy agglomeration: a case study in China[J]. KSCE Journal of Civil Engineering, 2024, 28(1): 375-385. doi: 10.1007/s12205-023-1221-7 [4] 王爱民, 林圣, 李俊逸, 等. 城市轨道交通长线路杂散电流仿真模型[J]. 高电压技术, 2020, 46(4): 1379-1386. doi: 10.13336/j.1003-6520.hve.20200430030Wang Aimin, Lin Sheng, Li Junyi, et al. Stray current simulation model of the long line of DC metro systems[J]. High Voltage Engineering, 2020, 46(4): 1379-1386. doi: 10.13336/j.1003-6520.hve.20200430030 [5] 郑鑫, 杜贵府, 李巧月, 等. 城轨直流牵引供电多回流路径耦合建模及回流安全参数动态分布[J]. 电工技术学报, 2024, 39(15): 4630-4642. doi: 10.19595/j.cnki.1000-6753.tces.232147Zheng Xin, Du Guifu, Li Qiaoyue, et al. Multiple reflux paths coupling modeling for urban rail DC traction power supply and dynamic distribution of reflux safety parameters[J]. Transactions of China Electrotechnical Society, 2024, 39(15): 4630-4642. doi: 10.19595/j.cnki.1000-6753.tces.232147 [6] Du G F, Wang J, Jiang X X, et al. Evaluation of rail potential and stray current with dynamic traction networks in multitrain subway systems[J]. IEEE Transactions on Transportation Electrification, 2020, 6(2): 784-796. doi: 10.1109/TTE.2020.2980745 [7] 周奇, 林圣, 邹全德, 等. 土壤结构对城轨中杂散电流分布的影响分析[J]. 都市快轨交通, 2022(2): 10-16. doi: 10.3969/j.issn.1672-6073.2022.02.002Zhou Qi, Lin Sheng, Zou Quande, et al. Influence of soil structure on stray current distribution in urban rail transit[J]. Urban Rapid Rail Transit, 2022(2): 10-16. doi: 10.3969/j.issn.1672-6073.2022.02.002 [8] 陈民武, 付浩纯, 谢崇豪, 等. 交直流双制式牵引供电系统钢轨电位特性分析[J]. 西南交通大学学报, 2022, 57(4): 729-736. doi: 10.3969/j.issn.0258-2724.20200597Chen Minwu, Fu Haochun, Xie Chonghao, et al. Analysis of rail potential characteristics of AC/DC dual-system traction power supply system[J]. Journal of Southwest Jiaotong University, 2022, 57(4): 729-736. doi: 10.3969/j.issn.0258-2724.20200597 [9] 黄晓鹏, 马庆安, 刘炜, 等. 城轨供电系统杂散电流对埋地金属管道的动态干扰研究[J]. 铁道科学与工程学报, 2023, 20(2): 735-744. doi: 10.19713/j.cnki.43-1423/u.T20220535Huang Xiaopeng, Ma Qing’an, Liu Wei, et al. Study on the dynamic interference of stray current in urban traction power supply system on buried metal pipelines[J]. Journal of Railway Science and Engineering, 2023, 20(2): 735-744. doi: 10.19713/j.cnki.43-1423/u.T20220535 [10] 唐雨杭, 喻锟, 曾祥君, 等. 基于地电位分布的地铁杂散电流引起埋地金属腐蚀计算方法[J]. 上海交通大学学报, 2025, 59(3): 424-434. doi: 10.16183/j.cnki.jsjtu.2023.334Tang Yuhang, Yu Kun, Zeng Xiangjun, et al. Calculation method for underground metal corrosion due to stray current based on ground potential distribution[J]. Journal of Shanghai Jiao Tong University, 2025, 59(3): 424-434. doi: 10.16183/j.cnki.jsjtu.2023.334 [11] 史云涛, 赵丽平, 林圣, 等. 城市电网中地铁杂散电流分布规律及影响因素分析[J]. 电网技术, 2021, 45(5): 1951-1957. doi: 10.13335/j.1000-3673.pst.2020.0244Shi Yuntao, Zhao Liping, Lin Sheng, et al. Analysis of distribution of metro stray current in urban power grid and its influencing factors[J]. Power System Technology, 2021, 45(5): 1951-1957. doi: 10.13335/j.1000-3673.pst.2020.0244 [12] 刘炜, 李松原, 唐宇宁. 轨道交通直流干扰的车-地-网动态耦合仿真[J]. 西南交通大学学报, 2025, 60(1): 156-165. doi: 10.3969/j.issn.0258-2724.20230052Liu Wei, Li Songyuan, Tang Yuning. Simulation of dynamic coupling of metro-earth-grid for DC interference in rail transit[J]. Journal of Southwest Jiaotong University, 2025, 60(1): 156-165. doi: 10.3969/j.issn.0258-2724.20230052 [13] 叶润峰, 魏应冬, 李占赫, 等. 城市轨道交通柔性直流牵引供电系统钢轨电位快速计算方法[J]. 中国电机工程学报, 2023, 43(14): 5311-5318. doi: 10.13334/j.0258-8013.pcsee.223222Ye Runfeng, Wei Yingdong, Li Zhanhe, et al. Fast calculation of rail potential of flexible DC traction power supply system for urban rail transit[J]. Proceedings of the Chinese Society for Electrical Engineering, 2023, 43(14): 5311-5318. doi: 10.13334/j.0258-8013.pcsee.223222 [14] 杨晓峰, 郑琼林. 城市轨道交通牵引供电系统接触网和回流安全综述[J]. 都市快轨交通, 2022, 35(2): 1-9, 24. doi: 10.3969/j.issn.1672-6073.2022.02.001Yang Xiaofeng, Zheng Trillion Q. A review of studies on traction power supply catenary and reflux safety in urban rail transit[J]. Urban Rapid Rail Transit, 2022, 35(2): 1-9,24. doi: 10.3969/j.issn.1672-6073.2022.02.001 [15] 陈民武, 赵鑫, 丁大鹏, 等. 城市轨道交通供电系统钢轨电位限制装置操作过电压研究[J]. 中国铁道科学, 2017, 38(6): 94-99. doi: 10.3969/j.issn.1001-4632.2017.06.13Chen Minwu, Zhao Xin, Ding Dapeng, et al. Research on switching surge of rail over-voltage protection device in power supply system for urban rail transit[J]. China Railway Science, 2017, 38(6): 94-99. doi: 10.3969/j.issn.1001-4632.2017.06.13 [16] Zaboli A, Vahidi B, Yousefi S, et al. Evaluation and control of stray current in DC-electrified railway systems[J]. IEEE Transactions on Vehicular Technology, 2017, 66(2): 974-980. doi: 10.1109/TVT.2016.2555485 [17] 蔡力, 王建国, 樊亚东, 等. 地铁走行轨对地过渡电阻杂散电流分布的影响[J]. 高电压技术, 2015, 41(11): 3604-3610. doi: 10.13336/j.1003-6520.hve.2015.11.012Cai Li, Wang Jianguo, Fan Yadong, et al. Influence of the track-to-earth resistance of subway on stray current distribution[J]. High Voltage Engineering, 2015, 41(11): 3604-3610. doi: 10.13336/j.1003-6520.hve.2015.11.012 [18] Zhou Q, Lin S, Zhang W J. Analysis and mitigation of stray current in modern metro systems with OVPD and PSD[J]. IEEE Transactions on Transportation Electrification, 2024, 10(2): 3153-3166. doi: 10.1109/TTE.2023.3300750 [19] 郑琼林, 杨晓峰, 吴命利, 等. 轨道交通牵引供电系统技术进展与思考[J]. 电气工程学报, 2025, 20(4): 399-428. doi: 10.11985/2025.04.028Zheng Trillion Q, Yang Xiaofeng, Wu Mingli, et al. Advances and reflections on rail transit traction power supply system technology[J]. Journal of Electrical Engineering, 2025, 20(4): 399-428. doi: 10.11985/2025.04.028 [20] Sahil Bhagat, 杨晓峰, 王淼, 等. 城市轨道交通杂散电流治理的综述与评估[J]. 电工技术学报, 2021, 36(23): 4851-4863. doi: 10.19595/j.cnki.1000-6753.tces.210923Bhagat Sahil, Yang Xiaofeng, Wang Miao, et al. Review and evaluation of stray current mitigation for urban rail transit[J]. Transactions of China Electrotechnical Society, 2021, 36(23): 4851-4863. doi: 10.19595/j.cnki.1000-6753.tces.210923 [21] Fabre J, Ladoux P, Solano E, et al. MVDC three-wire supply systems for electric railways: design and test of a full SiC multilevel chopper[J]. IEEE Transactions on Industry Applications, 2017, 53(6): 5820-5830. doi: 10.1109/TIA.2017.2747498 [22] 文天琦, 王滢, 刘学龙, 等. 电感强制吸流电路对地铁杂散电流抑制作用的研究[J]. 制造业自动化, 2022, 44(4): 200-204. doi: 10.3969/j.issn.1009-0134.2022.04.046Wen Tianqi, Wang Ying, Liu Xuelong, et al. A research on inductance forcedly absorbing current to reduce stray current in metro[J]. Manufacturing Automation, 2022, 44(4): 200-204. doi: 10.3969/j.issn.1009-0134.2022.04.046 [23] 顾靖达, 杨晓峰, 郑琼林, 等. 基于不同接地方式与列车工况的负阻变换器牵引供电系统轨道电位与杂散电流[J]. 电工技术学报, 2021, 36(8): 1703-1717.Gu Jingda, Yang Xiaofeng, Zheng Trillion Q, et al. Rail potential and stray current on negative resistance converter traction power system under different grounding schemes and train conditions[J]. Transactions of China Electrotechnical Society, 2021, 36(8): 1703-1717. [24] Wang M, Yang X F, Zheng T Q, et al. DC autotransformer-based traction power supply for urban transit rail potential and stray current mitigation[J]. IEEE Transactions on Transportation Electrification, 2020, 6(2): 762-773. doi: 10.1109/TTE.2020.2979020 [25] 王淼, 杨晓峰, 李世翔, 等. 城市轨道交通直流自耦变压器牵引供电系统故障保护研究[J]. 电工技术学报, 2022, 37(4): 976-989. doi: 10.19595/j.cnki.1000-6753tces.210880Wang Miao, Yang Xiaofeng, Li Shixiang, et al. Fault protection of DC auto-transformer traction power supply system for urban rail transit[J]. Transactions of China Electrotechnical Society, 2022, 37(4): 976-989. doi: 10.19595/j.cnki.1000-6753tces.210880 [26] GB 55033—2022 城市轨道交通工程项目规范[S]. [27] CJJ/T 49—2020 地铁杂散电流腐蚀防护技术标准[S]. [28] CJ/T 414—2012 城市轨道交通钢铝复合导电轨技术要求[S]. -
