考虑CCER与绿证、绿电交易的电-氢综合能源系统优化调度

李奇,  王泽群,  蒲雨辰,  门炜杰,  陈维荣

李奇, 王泽群, 蒲雨辰, 门炜杰, 陈维荣. 考虑CCER与绿证、绿电交易的电-氢综合能源系统优化调度[J]. 西南交通大学学报, 2026, 61(5): 1454-1469. doi: 10.3969/j.issn.0258-2724.20260051
引用本文: 李奇, 王泽群, 蒲雨辰, 门炜杰, 陈维荣. 考虑CCER与绿证、绿电交易的电-氢综合能源系统优化调度[J]. 西南交通大学学报, 2026, 61(5): 1454-1469. doi: 10.3969/j.issn.0258-2724.20260051
LI Qi, WANG Zequn, PU Yuchen, MEN Weijie, CHEN Weirong. Optimized Dispatch of Electricity-Hydrogen Integrated Energy System Considering Chinese Certified Emission Reduction, Green Certificate, and Green Electricity Trading[J]. Journal of Southwest Jiaotong University, 2026, 61(5): 1454-1469. doi: 10.3969/j.issn.0258-2724.20260051
Citation: LI Qi, WANG Zequn, PU Yuchen, MEN Weijie, CHEN Weirong. Optimized Dispatch of Electricity-Hydrogen Integrated Energy System Considering Chinese Certified Emission Reduction, Green Certificate, and Green Electricity Trading[J]. Journal of Southwest Jiaotong University, 2026, 61(5): 1454-1469. doi: 10.3969/j.issn.0258-2724.20260051

考虑CCER与绿证、绿电交易的电-氢综合能源系统优化调度

doi: 10.3969/j.issn.0258-2724.20260051
基金项目: 国家自然科学基金项目(U2569204,52377123);四川省自然科学基金项目(2026NSFSC1206)
详细信息
    作者简介:

    李奇(1984—),男,教授,博士生导师,研究方向为分布式发电并网技术、综合能源系统等,E-mail:liqi0800@163.com

    通讯作者:

    蒲雨辰(1995—),男,讲师,博士,研究方向为综合能源系统优化调度,E-mail:yuchen_pu@126.com

  • 中图分类号: TM73;TK01

Optimized Dispatch of Electricity-Hydrogen Integrated Energy System Considering Chinese Certified Emission Reduction, Green Certificate, and Green Electricity Trading

  • 摘要:

    针对“双碳”目标下综合能源系统在电碳多元市场机制协同下经济与减排效益不明确的问题,面向含氢能子系统的综合能源系统,提出一种融合中国核证自愿减排量(CCER)、绿色电力证书与绿电交易的多元市场协同优化调度方法. 首先,构建电-氢综合能源系统架构,建立各设备的数学模型并深入分析系统内部能量流与碳流关系;其次,考虑系统可再生能源的内部消纳与外部供应,基于电-碳-氢耦合特性量化系统实际核证减排量,提出系统参与CCER、绿证与绿电多元市场的协同交易方法;基于全生命周期评估方法,建立了涵盖设备生产、运输建设、运行投产和退役处理全阶段的碳排放核算模型;最后,以系统运行成本最小为优化目标,构建考虑阶梯式碳交易成本的综合能源系统优化调度模型,采用混合整数线性规划方法求解,并通过算例验证所提方法的有效性. 研究结果表明:多元化市场交易实现了激励效应叠加,系统总成本较基准场景降低19.38%,达成了系统“降本-减排-消纳”的协同优化.



  • 图 1  综合能源系统内部结构

    Figure 1.  Internal structure of IES

    图 2  绿电-绿证交易框架

    Figure 2.  GE-GC trading framework

    图 3  多元交易策略框架

    Figure 3.  Multi-strategy trading framework

    图 4  终端用能LCA流程

    Figure 4.  LCA process for terminal energy use

    图 5  技术路线

    Figure 5.  Technical roadmap

    图 6  场景2各功率平衡调度

    Figure 6.  Power balance dispatch of scenario 2

    图 7  各场景下的系统碳量构成(单位:kg)

    Figure 7.  System carbon composition under various scenarios (unit: kg)

    图 8  场景5系统各功率平衡调度

    Figure 8.  Power balance dispatch of scenario 5

    图 9  各场景碳交易与总成本对比

    Figure 9.  Comparison of carbon trading costs and total costs across different scenarios

    图 10  各场景下的可再生能源消纳(单位:kg•h)

    Figure 10.  Renewable energy consumption under different scenarios (unit: kg•h)

    表  1  场景设置

    Table  1.   Setting of scenarios

    场景 考虑
    氢能
    考虑 GC
    和 GE
    考虑 CCER GC、GE 和
    CCER 交互
    1 × × × ×
    2 √ × × ×
    3 √ √ × ×
    4 √ × √ ×
    5 √ √ √ √
    下载: 导出CSV

    表  2  场景1、2成本对比分析

    Table  2.   Cost analysis for scenarios 1 and 2 元

    场景 运维 燃煤 碳封存 碳交易 购电 售电 购气 总成本/元
    场景 1 3587.99 19800.33 1350.22 7702.47 5724.92 −6427.90 18172.59 49910.63
    场景 2 5153.37 17855.82 1541.38 6445.25 5448.61 −5103.98 17492.64 48833.09
    下载: 导出CSV

    表  3  场景1、2碳排放对比分析

    Table  3.   Comparative analysis of carbon emissions for scenarios 1 and 2 kg

    场景 碳排放总量 碳交易净值
    场景 1 39795.62 25674.91
    场景 2 35604.87 21484.16
    下载: 导出CSV

    表  4  场景3、4、5成本对比分析

    Table  4.   Comparative analysis of cost for scenarios 3, 4, and 5 元

    场景 运维 燃煤 碳封存 碳交易 购电 售电 购气 绿证 CCER 总成本
    场景 3 5134.10 15217.04 1480.43 3460.10 5410.80 −3170.10 15933.92 −842.54 0 42623.78
    场景 4 5004.37 17429.14 1465.58 3148.41 5509.01 −2724.08 14938.12 0 −1446.39 43324.16
    场景 5 5133.44 16233.03 1615.54 2911.62 5685.22 −4371.90 15338.70 −949.71 −2219.98 39375.96
    下载: 导出CSV

    表  5  场景3、4、5碳捕集效益对比

    Table  5.   Comparison of carbon capture benefits for scenarios 3, 4, and 5

    场景 总发电量/(kW•h) 净发电量/(kW•h) 碳捕集耗电/(kW•h) CO2 生成量/kg CO2 捕获量/kg 碳捕集率/%
    场景 3 40135.81 11523.04 28612.77 39098.52 29449.01 75.32
    场景 4 41497.96 8996.72 32501.24 42327.92 33608.65 79.40
    场景 5 45792.92 12176.31 33616.61 45708.78 38354.28 83.91
    下载: 导出CSV

    表  6  场景3、4、5碳排放对比分析

    Table  6.   Comparison of carbon emissions for scenarios 3, 4, and 5 kg

    场景 碳排放总量 碳交易净值
    场景 3 25654.39 11533.65
    场景 4 23698.96 9578.22
    场景 5 20948.78 6828.04
    下载: 导出CSV
  • [1] Li Y, Liu Z H, Sang Y F, et al. Optimization of integrated energy system for low-carbon community considering the feasibility and application limitation[J]. Applied Energy, 2023, 348: 121528. doi: 10.1016/j.apenergy.2023.121528
    [2] Yang T, Wang Q C, Wang X D, et al. Low-carbon economic distributed dispatch for district-level integrated energy system considering privacy protection and demand response[J]. Applied Energy, 2025, 383: 125389. doi: 10.1016/j.apenergy.2025.125389
    [3] Zhao N X, Gu W B, Zheng Z P, et al. Multi-objective bi-level planning of the integrated energy system considering uncertain user loads and carbon emission during the equipment manufacturing process[J]. Renewable Energy, 2023, 216: 119070. doi: 10.1016/j.renene.2023.119070
    [4] Lu X, Fan X Z, Lu S, et al. An operation model for integrated electricity and heat systems emphasizing modeling of both networks and uncertainties[J]. Applied Energy, 2024, 370: 123595. doi: 10.1016/j.apenergy.2024.123595
    [5] 王成山, 吕超贤, 李鹏, 等. 园区型综合能源系统多时间尺度模型预测优化调度[J]. 中国电机工程学报, 2019, 39(23): 6791-6803. doi: 10.13334/j.0258-8013.pcsee.181058

    Wang Chengshan, Lü Chaoxian, Li Peng, et al. Multiple time-scale optimal scheduling of community integrated energy system based on model predictive control[J]. Proceedings of the CSEE, 2019, 39(23): 6791-6803. doi: 10.13334/j.0258-8013.pcsee.181058
    [6] Li Y X, Zhang J L, Wu X, et al. Stochastic-robust planning optimization method based on tracking-economy extreme scenario tradeoff for CCHP multi-energy system[J]. Energy, 2023, 283: 129025. doi: 10.1016/j.energy.2023.129025
    [7] 孙雯, 陈紫薇, 张玉琼, 等. 基于动态规划的SOFC冷热电三联供综合能源系统日前经济调度[J]. 中国电机工程学报, 2022, 42(21): 7775-7783. doi: 10.13334/j.0258-8013.pcsee.211743

    Sun Wen, Chen Ziwei, Zhang Yuqiong, et al. Economic day-ahead scheduling of SOFC-based integrated tri-generation energy system using dynamic programming[J]. Proceedings of the CSEE, 2022, 42(21): 7775-7783. doi: 10.13334/j.0258-8013.pcsee.211743
    [8] Xing X T, Lin J, Song Y H, et al. Modeling and operation of the power-to-gas system for renewables integration: a review[J]. CSEE Journal of Power and Energy Systems, 2018, 4(2): 168-178. doi: 10.17775/CSEEJPES.2018.00260
    [9] 李红伟, 吴佳航, 王佳怡, 等. 计及P2G及碳捕集的风光氢储综合能源系统低碳经济调度[J]. 电力系统保护与控制, 2024, 52(16): 26-36. doi: 10.19783/j.cnki.pspc.240247

    Li Hongwei, Wu Jiahang, Wang Jiayi, et al. Low-carbon economic dispatch of a wind, solar, and hydrogen storage integrated energy system considering P2G and carbon capture[J]. Power System Protection and Control, 2024, 52(16): 26-36. doi: 10.19783/j.cnki.pspc.240247
    [10] Cavana M, Mazza A, Chicco G, et al. Electrical and gas networks coupling through hydrogen blending under increasing distributed photovoltaic generation[J]. Applied Energy, 2021, 290: 116764. doi: 10.1016/j.apenergy.2021.116764
    [11] Ma Y M, Wang H X, Hong F, et al. Modeling and optimization of combined heat and power with power-to-gas and carbon capture system in integrated energy system[J]. Energy, 2021, 236: 121392. doi: 10.1016/j.energy.2021.121392
    [12] 郭静蓉, 向月, 吴佳婕, 等. 考虑CCUS电转气技术及碳市场风险的电–气综合能源系统低碳调度[J]. 中国电机工程学报, 2023, 43(4): 1290-1302. doi: 10.13334/j.0258-8013.pcsee.221255

    Guo Jingrong, Xiang Yue, Wu Jiajie, et al. Low-carbon optimal scheduling of integrated electricity-gas energy systems considering CCUS-P2G technology and risk of carbon market[J]. Proceedings of the CSEE, 2023, 43(4): 1290-1302. doi: 10.13334/j.0258-8013.pcsee.221255
    [13] 刘妍, 胡志坚, 陈锦鹏, 等. 含碳捕集电厂与氢能多元利用的综合能源系统低碳经济调度[J]. 电力系统自动化, 2024, 48(1): 31-40. doi: 10.7500/AEPS20230221001

    Liu Yan, Hu Zhijian, Chen Jinpeng, et al. Low-carbon economic dispatch of integrated energy system considering carbon capture power plant and multi-utilization of hydrogen energy[J]. Automation of Electric Power Systems, 2024, 48(1): 31-40. doi: 10.7500/AEPS20230221001
    [14] Wang T H, Hua H C, Shi T Y, et al. A bi-level dispatch optimization of multi-microgrid considering green electricity consumption willingness under renewable portfolio standard policy[J]. Applied Energy, 2024, 356: 122428. doi: 10.1016/j.apenergy.2023.122428
    [15] 黄铭浩, 唐坤杰, 董树锋, 等. 基于碳流理论考虑用户侧碳排放配额的最优潮流[J]. 电网技术, 2023, 47(7): 2703-2712.

    Huang Minghao, Tang Kunjie, Dong Shufeng, et al. Optimal power flow considering user-side carbon emission allowances based on carbon flow theory[J]. Power System Technology, 2023, 47(7): 2703-2712.
    [16] 郭文凯, 王果, 闵永智. 计及阶梯式碳交易的牵引供电系统混合储能容量配置[J]. 西南交通大学学报, 2025, 60(3): 550-560.

    Guo Wenkai, Wang Guo, Min Yongzhi. Hybrid energy storage capacity configuration for traction power supply systems considering ladder-type carbon trading mechanism[J]. Journal of Southwest Jiaotong University, 2025, 60(3): 550-560.
    [17] 邹宇航, 曾艾东, 郝思鹏, 等. 阶梯式碳交易机制下综合能源系统多时间尺度优化调度[J]. 电网技术, 2023, 47(6): 2185-2195.

    Zou Yuhang, Zeng Aidong, Hao Sipeng, et al. Multi-time-scale optimal dispatch of integrated energy systems under stepped carbon trading mechanism[J]. Power System Technology, 2023, 47(6): 2185-2195.
    [18] 张笑演, 王橹裕, 黄蕾, 等. 考虑扩展碳排放流和碳交易议价模型的园区综合能源优化调度[J]. 电力系统自动化, 2023, 47(9): 34-46. doi: 10.7500/AEPS20220614001

    Zhang Xiaoyan, Wang Luyu, Huang Lei, et al. Optimal dispatching of park-level integrated energy system considering augmented carbon emission flow and carbon trading bargain model[J]. Automation of Electric Power Systems, 2023, 47(9): 34-46. doi: 10.7500/AEPS20220614001
    [19] 余洋, 吴千, 霍宇航, 等. 计及自适应阶梯碳势-碳价与供需双响应基于主从博弈的综合能源系统低碳经济调度[J]. 电网技术, 2024, 48(7): 2702-2714.

    Yu Yang, Wu Qian, Huo Yuhang, et al. Low-carbon economic dispatch for integrated energy system based on Stackelberg game considering adaptive stepped carbon potential-carbon price and dual response of supply and demand[J]. Power System Technology, 2024, 48(7): 2702-2714.
    [20] 李伊竹林, 韩肖清, 李廷钧, 等. 基于动态电-碳需求响应的综合能源系统日前多元低碳交易方法[J]. 电力系统自动化, 2024, 48(12): 24-35. doi: 10.7500/AEPS20231023003

    Li Yizhulin, Han Xiaoqing, Li Tingjun, et al. Multifaceted day-ahead low-carbon trading method for integrated energy systems based on dynamic electricity-carbon demand response[J]. Automation of Electric Power Systems, 2024, 48(12): 24-35. doi: 10.7500/AEPS20231023003
    [21] Zhou Y, Wu J, Long C, et al. Integrated energy system multi-objective optimization scheduling considering tradable green certificate and carbon trading mechanism[J]. Energy, 2023, 278: 127811.
    [22] Alcalde J, Flude S, Wilkinson M, et al. Estimating geological CO2 storage security to deliver on climate mitigation[J]. Nature Communications, 2018, 9: 2201. doi: 10.1038/s41467-018-04423-1
    [23] Vasudevan S, Farooq S, Karimi I A, et al. Energy penalty estimates for CO2 capture: comparison between fuel types and capture-combustion modes[J]. Energy, 2016, 103: 709-714. doi: 10.1016/j.energy.2016.02.154
    [24] 国家气候战略中心. 2023年减排项目中国区域电网基准线排放因子[R]. 北京: 国家气候战略中心, 2024.
    [25] Zhang Q, Wang D X, Zhao C J, et al. Low-carbon operation of smart distribution grid based on life cycle assessment and ladder-type carbon trading[J]. Renewable Energy, 2024, 231: 120816. doi: 10.1016/j.renene.2024.120816
    [26] Dong H Y, Fu Y B, Jia Q Q, et al. Low carbon optimization of integrated energy microgrid based on life cycle analysis method and multi time scale energy storage[J]. Renewable Energy, 2023, 206: 60-71. doi: 10.1016/j.renene.2023.02.034
    [27] Wu M, Xu J Z, Li Y, et al. Low carbon economic dispatch of integrated energy systems considering life cycle assessment and risk cost[J]. International Journal of Electrical Power & Energy Systems, 2023, 153: 109287. doi: 10.1016/j.ijepes.2023.109287
