Electrical Coupling Effects and Dynamic Control Strategy for Urban Rail Transit Power Supply Systems and Buried Pipelines
-
摘要:
为研究城市轨道交通线路供电系统泄漏的杂散电流对城轨周边埋地金属管道的干扰及控制，对城轨供电系统与埋地管道电气耦合影响及动态控制策略进行分析. 首先，提出计及动态控制策略的城轨供电系统与埋地金属管道动态耦合参数计算模型，并基于实际线路参数对不同耦合场景下城轨供电系统参数及管道参数的动态分布进行仿真分析，阐明多回流路径耦合影响规律；其次，为解决城轨供电系统与管道电气耦合干扰问题，提出城轨供电系统与管道电气耦合动态控制策略，设计动态控制装置的结构，分析其控制特性；最后，以国内某城轨线路参数为例进行仿真分析，验证管道杂散电流及管地电位动态控制效果. 研究结果表明：城轨供电系统与周边管道电气耦合会造成城轨回流系统参数及管道安全参数升高，以仿真情况3为例，管道电位最大瞬时值可达16.2V，并且耦合效应与走行轨绝缘状态、管道绝缘状态及耦合位置处钢轨电位有关；动态控制策略能有效抑制城轨供电系统对管道的电气耦合影响，将管道电压钳位在标准限值范围内，并将管道杂散电流引回至城轨供电系统.
Abstract:To investigate the interference of stray currents from the power supply system of urban rail transit lines on adjacent buried metal pipelines and their control, the electrical coupling effects and dynamic control strategies between the urban rail transit power supply system and buried pipelines were analyzed. First, a dynamic coupling parameter calculation model integrating dynamic control strategies was proposed for the urban rail transit power supply system and buried metal pipelines. Based on actual line parameters, simulations were conducted to analyze the dynamic distribution of power supply system parameters and pipeline parameters under different coupling scenarios, clarifying the influence of multi-return-path coupling interactions. Second, to address the electrical coupling interference between the urban rail transit power supply system and pipelines, a dynamic control strategy was proposed, and the structure of a dynamic control device was designed, with its control characteristics analyzed. Finally, by using parameters from an actual urban rail transit line in China as an example, simulation analysis was performed to verify the dynamic control effect on pipeline stray current and pipe-to-soil potential. The results indicate that electrical coupling between the urban rail transit power supply system and adjacent pipelines leads to an increase in both the return system parameters of the urban rail transit and the pipeline safety parameters. By taking simulation case 3 as an example, the maximum instantaneous pipeline potential reaches 16.2 V. The coupling effect is related to the insulation condition of the running rails, the insulation condition of the pipeline, and the rail potential at the coupling location. The proposed dynamic control strategy can effectively suppress the electrical coupling impact of the urban rail transit power supply system on pipelines, clamp the pipeline voltage within the standard limits, and redirect the stray current on the pipeline back to the urban rail transit power supply system.
-
Key words:
- urban rail transit /
- buried metal pipeline /
- stray current /
- electrical coupling /
- dynamic control
-
图 1 城轨供电系统与管道耦合结构
Figure 1. Coupling structure of urban rail transit power supply system and pipeline
图 2 动态控制装置原理图及控制特性图
Figure 2. Principle of dynamic control device and control characteristic
图 3 城轨直流牵引供电系统多回流路径耦合仿真模型
Figure 3. Simulation model of multi-return-path coupling in direct current traction power supply system for urban rail transit
图 4 计及动态控制策略的多回流路径耦合参数计算流程
Figure 4. Calculation flow of multi-return-path coupling parameters considering dynamic control strategy
图 6 不同管道绝缘状态耦合时回流参数分布对比
Figure 6. Comparison of return system parameters under coupling with different pipeline insulation states
图 7 城轨回流参数及管道安全参数动态分布（情况3）
Figure 7. Dynamic distribution of return system parameters and pipeline safety parameters of urban rail transit （Case 3）
图 8 Sn为−1.5V时动态控制装置工作特性（情况5）
Figure 8. Operating characteristics of dynamic control device when sfn is −1.5 V （Case 5）
图 9 Sn为−1.5V治理前后系统参数动态分布（情况5）
Figure 9. Dynamic distribution of parameters before and after mitigation when Sn is −1.5 V （Case 5）
图 10 Sn=−1.0V时动态控制装置工作特性（情况5）
Figure 10. Operating characteristics of dynamic control device when sfn is −1.0 V （Case 5）
图 11 Sn=−1.0V治理前后管道参数动态分布（情况5）
Figure 11. Dynamic distribution of pipeline parameters before and after mitigation when Sn is −1.0 V （Case 5）
图 12 Sn=−1.5V治理前后系统参数动态分布（情况2、4）
Figure 12. Dynamic distribution of parameters before and after mitigation when Sn is −1.5 V （cases 2 and 4）
表 1 城轨直流牵引供电系统仿真参数设置
Table 1. Simulation parameters of direct current traction power supply system for urban rail transit
参数 数值 列车发车间隔/s 180 每站停留时间/s 30 仿真步长/s 1 整流机组空载电压/V 1 593 整流机组等效内阻/mΩ 16 再生制动能耗装置触发电压/V 1 800 单位长度接触网纵向电阻/（mΩ•km−1） 20 单位长度走行轨纵向电阻/（mΩ•km−1） 20 单位长度排流网纵向电阻/（mΩ•km−1） 20 单位长度走行轨对排流网电导/（S•km−1） 1/15 单位长度排流网对地电导/（S•km−1） 1/15 节点电压收敛精度/V 10−5 系统功率平衡收敛精度/kW 10−5
下载: 导出CSV
表 2 城轨与管道耦合时仿真参数设置
Table 2. Simulation parameters for coupling between urban rail transit and pipeline
情况 耦合位置/km yo1n/（S•km−1） yo2n/（S•km−1） yo3n/（S•km−1） 1 1 ～ 2 1/90 1/60 1/30 2 1 ～ 2 1/65 1/35 1/5 3 1 ～ 2 1/15 1/10 1/5 4 4 ～ 6 2/65 2/35 2/5 5 6 ～ 7 1/65 1/35 1/5
下载: 导出CSV
-
[1] 郑琼林, 杨晓峰, 吴命利, 等. 轨道交通牵引供电系统技术进展与思考[J]. 电气工程学报, 2025, 20(4): 399-428. doi: 10.11985/2025.04.028Zheng Trillion Q, Yang Xiaofeng, Wu Mingli, et al. Advances and reflections on rail transit traction power supply system technology[J]. Journal of Electrical Engineering, 2025, 20(4): 399-428. doi: 10.11985/2025.04.028 [2] 杨雯暄, 王爱民, 王军, 等. 基于过渡电阻灵敏度分析的地铁轨地绝缘劣化区域定位方法[J/OL]. 高电压技术, 2025-12-18. https://link.cnki.net/urlid/42.1239.tm.20251114.1648.005 [3] 杨晓峰, 郑琼林. 城市轨道交通牵引供电系统接触网和回流安全综述[J]. 都市快轨交通, 2022, 35(2): 1-9, 24. doi: 10.3969/j.issn.1672-6073.2022.02.001Yang Xiaofeng, Zheng Trillion Q. A review of studies on traction power supply catenary and reflux safety in urban rail transit[J]. Urban Rapid Rail Transit, 2022, 35(2): 1-9,24. doi: 10.3969/j.issn.1672-6073.2022.02.001 [4] 郑旭洋, 王竟宇, 崔桐瑞, 等. 输油管道缓解交直流干扰的方法与实践[J]. 石油化工腐蚀与防护, 2025, 42(5): 24-29.Zheng Xuyang, Wang Jingyu, Cui Tongrui, et al. Methods and practice for mitigating AC/DC interference in oil pipelines[J]. Corrosion & Protection in Petrochemical Industry, 2025, 42(5): 24-29. [5] 张坤, 田庆, 张豪, 等. 独立四轨回流系统对埋地管道直流干扰测试[J]. 电气化铁道, 2024, 35(1): 79-83. doi: 10.19587/j.cnki.1007-936x.2024.01.015Zhang Kun, Tian Qing, Zhang Hao, et al. DC interference test on buried pipeline by independent four-rail return system[J]. Electric Railway, 2024, 35(1): 79-83. doi: 10.19587/j.cnki.1007-936x.2024.01.015 [6] 刘炜, 李松原, 唐宇宁. 轨道交通直流干扰的车-地-网动态耦合仿真[J]. 西南交通大学学报, 2025, 60(1): 156-165.Liu Wei, Li Songyuan, Tang Yuning. Simulation of dynamic coupling of metro-earth-grid for DC interference in rail transit[J]. Journal of Southwest Jiaotong University, 2025, 60(1): 156-165. [7] 于海鹏, 鲍鸣, 刘帅, 等. 城轨屏蔽门绝缘状态对回流安全参数的影响研究[J]. 都市快轨交通, 2022, 35(2): 17-24.Yu Haipeng, Bao Ming, Liu Shuai, et al. Influence of the insulation state of shield doors on the reflux safety parameters in urban rail transit[J]. Urban Rapid Rail Transit, 2022, 35(2): 17-24. [8] Zheng Z X, Du G F, Huang W G, et al. Coupling effect of reflux safety parameters in main line and depot of multitrain DC traction power systems[J]. IEEE Transactions on Transportation Electrification, 2022, 8(1): 527-541. doi: 10.1109/TTE.2021.3095951 [9] 周奇, 林圣, 邹全德, 等. 土壤结构对城轨中杂散电流分布的影响分析[J]. 都市快轨交通, 2022, 35(2): 10-16. doi: 10.3969/j.issn.1672-6073.2022.02.002Zhou Qi, Lin Sheng, Zou Quande, et al. Influence of soil structure on stray current distribution in urban rail transit[J]. Urban Rapid Rail Transit, 2022, 35(2): 10-16. doi: 10.3969/j.issn.1672-6073.2022.02.002 [10] 蔡智超, 张献伟. 地铁杂散电流腐蚀评估及建模分析的研究现状[J]. 华东交通大学学报, 2020, 37(3): 27-36.Cai Zhichao, Zhang Xianwei. A comprehensive survey of subway stray current corrosion assessment and modeling analysis[J]. Journal of East China Jiaotong University, 2020, 37(3): 27-36. [11] 刘炜, 潘哲, 周林杰, 等. 场路耦合的直流牵引供电系统杂散电流扩散模型[J]. 高电压技术, 2023, 49(11): 4594-4603. doi: 10.13336/j.1003-6520.hve.20222075Liu Wei, Pan Zhe, Zhou Linjie, et al. Stray current diffusion model of field-circuit coupled DC traction power supply system[J]. High Voltage Engineering, 2023, 49(11): 4594-4603. doi: 10.13336/j.1003-6520.hve.20222075 [12] Hu Q, Zhang Z, Zhang Y, et al. Unraveling mechanisms and failures of stray current corrosion in urban Subway adjacent pipeline networks through statistical insights and 3D simulation[J]. Science of the Total Environment, 2024, 927: 172407-172417. doi: 10.1016/j.scitotenv.2024.172407 [13] 王爱民. 城市电网主变直流偏磁电流分析评估及抑制方法[D]. 成都: 西南交通大学, 2021. [14] 王承涛, 申冠一, 许少毅, 等. 基于物理场耦合的交流干扰作用下埋地金属管线腐蚀数值仿真[J]. 中国腐蚀与防护学报, 2024, 44(6): 1573-1580. doi: 10.11902/1005.4537.2024.016Wang Chengtao, Shen Guanyi, Xu Shaoyi, et al. Numerical simulation of corrosion of buried metal pipeline under AC interference based on physical field coupling[J]. Journal of Chinese Society for Corrosion and Protection, 2024, 44(6): 1573-1580. doi: 10.11902/1005.4537.2024.016 [15] Ogunsola A, Mariscotti A, Sandrolini L. Estimation of stray current from a DC-electrified railway and impressed potential on a buried pipe[J]. IEEE Transactions on Power Delivery, 2012, 27(4): 2238-2246. doi: 10.1109/TPWRD.2012.2211623 [16] Yu K, Ni Y R, Zeng X J, et al. Modeling and analysis of transformer DC bias current caused by metro stray current[J]. IEEJ Transactions on Electrical and Electronic Engineering, 2020, 15(10): 1507-1519. doi: 10.1002/tee.23221 [17] SY/T 0017—2006 埋地钢质管道直流排流保护技术标准[S]. [18] 柯甜甜, 方江敏, 钱瑶虹, 等. 地铁杂散电流对埋地金属管道阴极保护的影响[J]. 城市轨道交通研究, 2017, 20(3): 90-93. doi: 10.16037/j.1007-869x.2017.03.020Ke Tiantian, Fang Jiangmin, Qian Yaohong, et al. Effect of metro stray current on cathode protection for buried metal pipelines[J]. Urban Mass Transit, 2017, 20(3): 90-93. doi: 10.16037/j.1007-869x.2017.03.020 [19] 梁进学, 韩鹏, 刘敏军, 等. 地铁杂散电流防护技术研究[J]. 中国设备工程, 2024(17): 217-219. doi: 10.3969/j.issn.1671-0711.2024.17.089 [20] Wang S K, Zhou L M, Xiong D Y, et al. Zero-resistance-branch electrical drainage system to solve the adverse influence of stray current on buried pipelines[J]. IEEE Transactions on Industrial Electronics, 2024, 71(5): 4618-4628. doi: 10.1109/TIE.2023.3283675 [21] Bhagat S, 杨晓峰, 王淼, 等. 城市轨道交通杂散电流治理的综述与评估[J]. 电工技术学报, 2021, 36(23): 4851-4863. doi: 10.19595/j.cnki.1000-6753.tces.210923Bhagat S, Yang Xiaofeng, Wang Miao, et al. Review and evaluation of stray current mitigation for urban rail transit[J]. Transactions of China Electrotechnical Society, 2021, 36(23): 4851-4863. doi: 10.19595/j.cnki.1000-6753.tces.210923 [22] 魏来, 赵亚忠. 腐蚀缺陷对储罐接管阴极保护效果影响的数值模拟研究[J]. 石油化工腐蚀与防护, 2024, 41(1): 11-15, 24. doi: 10.3969/j.issn.1007-015X.2024.01.003Wei Lai, Zhao Yazhong. Numerical simulation study on influence of corrosion defects on cathodic protection effect for tank connections[J]. Corrosion & Protection in Petrochemical Industry, 2024, 41(1): 11-15,24. doi: 10.3969/j.issn.1007-015X.2024.01.003 [23] 钟志宏, 李炎, 米佳雨, 等. 基于牵引网电压和空载电压的多储能系统区间能量管理策略[J]. 电工技术学报, 2024, 39(15): 4583-4598.Zhong Zhihong, Li Yan, Mi Jiayu, et al. Interval energy management strategy for multiple energy storage systems based on traction network voltage and No-load voltage[J]. Transactions of China Electrotechnical Society, 2024, 39(15): 4583-4598. [24] 倪砚茹, 曾祥君, 喻锟, 等. 地铁杂散电流引起动态地电位分布建模及影响因素分析[J]. 中国电机工程学报, 2023, 43(23): 9059-9071. doi: 10.13334/j.0258-8013.pcsee.221759Ni Yanru, Zeng Xiangjun, Yu Kun, et al. Modeling and influencing factors analysis of dynamic potential distribution caused by metro stray current[J]. Proceedings of the CSEE, 2023, 43(23): 9059-9071. doi: 10.13334/j.0258-8013.pcsee.221759 [25] 郑鑫, 杜贵府, 李巧月, 等. 城轨直流牵引供电多回流路径耦合建模及回流安全参数动态分布[J]. 电工技术学报, 2024, 39(15): 4630-4642. doi: 10.19595/j.cnki.1000-6753.tces.232147Zheng Xin, Du Guifu, Li Qiaoyue, et al. Multiple reflux paths coupling modeling for urban rail DC traction power supply and dynamic distribution of reflux safety parameters[J]. Transactions of China Electrotechnical Society, 2024, 39(15): 4630-4642. doi: 10.19595/j.cnki.1000-6753.tces.232147 -
