Research on Shear Property of Special Shear Keys in Composite Structures of Double-Layer Plate Truss
-
摘要:
为研究双层板桁组合结构中特殊剪力键的抗剪力学性能，通过推出试验探讨混凝土强度和横向带孔加劲肋的孔径对特殊剪力键抗剪性能的影响，对精细化数值模拟分析进行验证，揭示了试件破坏形态和特殊剪力键协同工作机理；基于数值模拟进行参数化分析，提出适用特殊剪力键的抗剪承载力计算公式. 结果表明：双层板桁组合结构由横向带孔加劲肋和栓钉承担剪力，混凝土强度增大，剪力键抗剪承载力逐渐提高；混凝土强度从C30提高至C50，剪力键的抗剪承载力从341.16 kN增至448.09 kN，提高了31.34%；剪力键在孔径为25 × 20 mm的延性为2.06 mm，比无孔径的提高了89.0%，且混凝土强度越大对剪力键延性的影响越大；栓钉根部应力首先到达屈服强度，随即横向带孔加劲肋到达屈服强度；栓钉直径、栓钉极限抗拉强度、混凝土强度以及横向带孔加劲肋的厚度等参数影响特殊剪力键的抗剪承载力，基于参数分析提出适用于特殊剪力键抗剪承载力计算公式，其预测结果与有限元结果吻合度良好，为工程设计提供参考依据.
Abstract:To study the shear mechanical properties of special shear keys in composite structures of a double-layer plate truss, the influence of concrete strength and the hole diameter of transverse perforated stiffening ribs on the shear property of special shear keys was explored through push-out tests. The refined numerical simulation analysis was verified, revealing the failure mode of specimens and the collaborative working mechanism of special shear keys. Based on numerical simulation for parameter analysis, a calculation formula for shear bearing capacity suitable for special shear keys was proposed. The results show that the composite structure of a double-layer plate truss bears the shear force by the transverse perforated stiffening ribs and studs. As the concrete strength increases, the shear bearing capacity of the shear keys gradually improves. The concrete strength increases from C30 to C50, and the shear bearing capacity of the shear key rises from 341.16 kN to 448.09 kN, an increase of 31.34%. The ductility of the shear key with a hole diameter of 25 × 20 mm is 2.06 mm, which is 89.0% higher than that without a hole. Moreover, the greater strength of the concrete leads to a greater influence on the ductility of the shear key. The stress at the root of the stud first reaches the yield strength, and then the transverse perforated stiffening rib reaches the yield strength. Parameters, such as the diameter of the stud, the ultimate tensile strength of the stud, the strength of the concrete, and the thickness of the transverse perforated stiffening rib, affect the shear bearing capacity of the special shear key. Based on the parameter analysis, a calculation formula suitable for the shear bearing capacity of the special shear key is proposed. The prediction results are in good agreement with the finite element results, providing a reference basis for engineering design.
-
图 7 试验与数值模拟荷载-滑移曲线
Figure 7. Comparison of load–slip curves between test and numerical simulation
图 10 不同参数对连接键抗剪性能的影响
Figure 10. Influence of different parameters on shear property of connection keys
表 1 试件参数
Table 1. Specimen parameters
编号 混凝土等级 横向带孔加劲肋
孔径/mmSSC01 C30 20 × 25 SSC02 15 × 20 SSC03 SSC04 C40 20 × 25 SSC05 15 × 20 SSC06 SSC07 C50 20 × 25 SSC08 15 × 20 SSC09
下载: 导出CSV
表 2 推出试验结果
Table 2. Push-out test results
编号 极限承载力/kN 对应的滑移量/mm SSC01 341.16 1.07 SSC02 339.95 0.98 SSC03 337.40 0.93 SSC04 390.50 1.36 SSC05 389.18 1.21 SSC06 390.44 1.11 SSC07 448.09 2.06 SSC08 447.28 1.66 SSC09 444.85 1.09
下载: 导出CSV
表 3 推出试验与数值模拟结果对比
Table 3. Comparison of push-out test and numerical simulation results
试件编号 试验值/kN 模拟值/kN 误差/% SSC01 341.06 321.41 5.76 SSC02 339.95 333.38 1.93 SSC03 337.40 338.58 −0.35 SSC04 390.50 385.48 1.29 SSC05 389.18 377.73 2.94 SSC06 390.44 379.85 2.71 SSC07 448.09 431.52 3.70 SSC08 447.26 420.62 5.96 SSC09 444.85 422.67 4.99 注：$ \text{误差}=\frac{\left| \text{试验值}-\text{模拟值}\right| }{\text{试验值}}\times 100{\text{%}} $.
下载: 导出CSV
-
