高温磁悬浮轴承发展及其研究综述

曹正; 李贵林; 祝长生; 周天豪

doi:10.3969/j.issn.0258-2724.20250486

高温磁悬浮轴承发展及其研究综述

doi: 10.3969/j.issn.0258-2724.20250486

1.
浙江大学电气工程学院，浙江杭州 310027
2.
太行实验室，四川成都 610213

基金项目: 国家自然科学基金项目（12402060）；太行国家实验室研究项目（A2063）

详细信息

作者简介:
曹正（1997—），男，博士研究生，研究方向为电磁轴承振动控制，E-mail：czzyl@zju.edu.cn

通讯作者:
祝长生（1963—），男，教授，博士，研究方向为电磁轴承振动控制，E-mail： zhu_zhang@zju.edu.cn

中图分类号: TH113.1
计量
- 文章访问数: 87
- HTML全文浏览量: 121
- PDF下载量: 12
- 被引次数: 0
出版历程
- 收稿日期: 2025-09-20
- 修回日期: 2026-02-28
- 网络出版日期: 2026-03-20

Development and Research Review of High-Temperature Magnetic Bearings

1.
College of Electrical Engineering, Zhejiang University, Hangzhou 310027, China
2.
Taihang National Laboratory, Chengdu 610213, China

摘要

摘要:
高温主动磁悬浮轴承技术是替代传统轴承、实现在高温与高速工况下稳定运行的关键技术，其设计复杂度显著高于常温磁悬浮轴承. 基于国内外相关研究文献，系统综述高温主动磁悬浮轴承在材料选取、机械系统制造工艺与故障安全机制、高温位移传感器设计以及转子系统建模与动态特性分析4个方面的研究进展；进一步提出未来应重点开展多物理场耦合精细建模、振动主动控制策略、多场景应用适配性及材料-控制-结构协同优化等方向的深入研究，以提升高温磁轴承系统的可靠性与工程适用性，为其在极端环境下的稳定运行提供理论依据与技术支撑.
- 磁悬浮轴承 /
- 高温环境 /
- 关键技术 /
- 发展趋势
Abstract:
High-temperature active magnetic bearing technology is a key technology to replace traditional bearings and achieve stable operation under high-temperature and high-speed conditions. Its design complexity is significantly higher than that of ambient-temperature magnetic bearings. Based on relevant Chinese and international research literature, the research progress of high-temperature active magnetic bearings in four aspects, including material selection, mechanical system manufacturing processes and fail-safe mechanisms, high-temperature displacement sensor design, and rotor system modeling and dynamic characteristic analysis, was systematically reviewed. Furthermore, in-depth research in directions such as multi-physics coupled high-fidelity modeling, active vibration control strategies, multi-scenario application adaptability, and material-control-structure co-optimization was proposed as a future focus, to improve the reliability and engineering applicability of high-temperature magnetic bearing systems, and theoretical basis and technical support were provided for their stable operation in extreme environments.
- magnetic bearing /
- high-temperature environment /
- key technology /
- development trend

HTML全文

图 1 HT-AMBs发展简要时间回顾

Figure 1. Brief chronological review of HT-AMB development

下载: 全尺寸图片幻灯片

图 2 Thermocoax公司耐温700 ℃产品轮廓

Figure 2. Outline drawing of 700 ℃-resistant product from Thermocoax

下载: 全尺寸图片幻灯片

图 3 NASA封装前、后的HT-AMBs定子线圈

Figure 3. NASA HT-AMB stator coils before and after encapsulation

下载: 全尺寸图片幻灯片

图 4 南航HT-AMBs定子线圈封装体

Figure 4. NUAA HT-AMB stator coil encapsulation

下载: 全尺寸图片幻灯片

图 5 利用线圈嵌入技术制成的陶瓷线圈

Figure 5. Ceramic coil fabricated by coil embedding technology

下载: 全尺寸图片幻灯片

图 6 多层迷宫型励磁线圈叠焊法

Figure 6. Multi-layer labyrinth-type excitation coil lamination welding method

下载: 全尺寸图片幻灯片

图 7 Synchrony公司，HT-AMBs冗余结构

Figure 7. HT-AMB redundant structure of Synchrony

下载: 全尺寸图片幻灯片

图 8 Texas A&M、NASA GRC, HT-AMBs悬浮试验台

Figure 8. HT-AMB levitation test rig of Texas A&M and NASA GRC

下载: 全尺寸图片幻灯片

图 9 Texas A&M、NASA GRC, HT-AMBs悬浮试验台

Figure 9. HT-AMB levitation test rig of Texas A&M and NASA GRC

下载: 全尺寸图片幻灯片

图 10 氮化硅与镀银滑道辅助轴承

Figure 10. Auxiliary bearing of silicon nitride and silver-plated race

下载: 全尺寸图片幻灯片

图 11 模块化径向滑动辅助轴承

Figure 11. Auxiliary bearing of modular radial sliding

下载: 全尺寸图片幻灯片

图 12 喷涂准晶涂层的辅助轴承

Figure 12. Auxiliary bearing sprayed with quasicrystal coating

下载: 全尺寸图片幻灯片

图 13 径向轴承力试验台

Figure 13. Radial bearing force test rig

下载: 全尺寸图片幻灯片

图 14 静压轴颈轴承详图

Figure 14. Detailed drawing of hydrostatic journal bearing

下载: 全尺寸图片幻灯片

图 15 用于热膨胀补偿的传感器支架，带/不带位置传感器

Figure 15. Sensor mount for thermal expansion compensation with/without position sensor

下载: 全尺寸图片幻灯片

图 16 HT-AMBs模拟转子试验台

Figure 16. Simulated rotor test rig of HT-AMB

下载: 全尺寸图片幻灯片

图 17 C型芯力-电流随温度的变化图

Figure 17. C-type core force and current variation with temperature

下载: 全尺寸图片幻灯片

图 18 538 ℃不同转速下，力与电流的关系

Figure 18. Relationship between force and current at different rotational speeds under 538 ℃

下载: 全尺寸图片幻灯片

图 19 温度变化对转子模态频率的影响

Figure 19. Effect of temperature variation on rotor modal frequency

下载: 全尺寸图片幻灯片

图 20 转子使用套筒和锁紧螺母装置通过平衡轮连接到轴上

Figure 20. Rotor connected to shaft via balance wheel using sleeve and locknut assembly

下载: 全尺寸图片幻灯片

表 1 高磁导率铁钴软磁合金

Table 1. High-permeability iron-cobalt soft magnetic alloys

国家	合金牌号	制造商
美国	Hiperco 50	Carpenter Technologies Corp
法国	AFK 502	Aperam Alloys Inchy
德国	Vacoflux 50	Vacuumschmelze GmbH Hanau
中国	1J22	嘉竞合金科技有限公司

下载: 导出CSV

表 2 高温用无机绝缘材料分类

Table 2. Classification of inorganic insulating materials for high-temperature applications

类型	代表材料	耐温范围/℃
陶瓷类	氧化铝、氧化硅	1 000～1 800
云母类	白云母、金云母	500～850
玻璃类	无碱玻璃纤维布	450～600

下载: 导出CSV

表 3 高温绕组导线结构方案

Table 3. Structural designs of high-temperature winding wires

区域	导线结构	工作温度/℃	图片
国外	陶瓷涂层绝缘导线	≤1000
国内	玻璃纤维绝缘导线	≤600
	多层绕包耐火导线	≤1000
	迷宫型励磁绕组	≤550

下载: 导出CSV

表 4 耐温550 ℃高温绕组导线供应情况

Table 4. Supply status of high-temperature winding wires with 550 ℃ thermal endurance

单位名称	高温电磁线规格	图片
重庆材料研究院有限公司	0.9 mm 绝缘绕包线（0.7 mm 芯线，0.2 mm 绝缘）
	1.4 mm 绝缘绕包线（1.1 mm 芯线，0.3 mm 绝缘）
	0.23 mm 陶瓷线
上海电缆研究所	THW600-1.0 （1.0 mm 芯线，0.3 mm 绝缘）
奇温线缆有限公司	GN800、GN1000（4.5 mm 外径）

下载: 导出CSV
