Improvement in Numerical Solution of Probability Density Evolution Equation and Slope Stability Analysis
-
摘要:
为提升概率密度演化方法在高维结构随机响应分析中的计算精度与效率问题，提出基于总变差不增（TVD）格式的Van Leer通量限制器及超球体均匀选点方法. 首先，针对差分求解的TVD格式，分析Roe-Sweby通量限制器的不足，选取Van Leer通量限制器对数值求解精度进行优化，利用数值算例验证该方法的有效性；其次，基于现有数学证明结论，提出
n 维标准正态分布在超球体内与超立方体内的概率计算和量化证明超球体高维空间选点方法，进一步提出超球体-好格子选点法，实现超球体内生成均匀点集及概率计算；最后，以某在建高边坡工程为依托，建立边坡稳定性概率密度演化方程，采用本文改进方法对边坡稳定系数进行计算. 研究结果表明：在正常服役工况和降雨工况下，与10 000次蒙特卡洛模拟结果相比，边坡稳定系数的概率积分点最小误差分别为0.4%和0.2%，最大误差分别为2.9%和4.2%；在解决复杂高维结构随机问题时，本文提出的概率密度演化方程数值求解改进方法具有良好的计算精度和计算效率.Abstract:To improve the computational accuracy and efficiency of the probability density evolution method in analyzing high-dimensional stochastic responses of complex structures, a total variation diminishing (TVD) scheme using Van Leer’s flux limiter and a hypersphere-based uniform point selection method are proposed. First, for the TVD scheme in difference solving, the limitations of the Roe-Sweby flux limiter are analyzed. Van Leer’s flux limiter is selected to optimize numerical solution accuracy, and its effectiveness is verified through numerical examples. Second, based on existing mathematical findings, the probability calculation formulas for the n-dimensional standard normal distribution within hyperspheres and hypercubes are derived, by which the hypersphere-based high-dimensional point selection method is quantitatively validated. Furthermore, a hypersphere-based good lattice point method is developed to generate uniform point sets and perform probability calculations within hyperspheres. Finally, taking a high slope project under construction as a case study, a probability density evolution equation for slope stability is established, and the proposed improved method is applied to calculate the slope stability coefficient. The results show that under normal service conditions and rainfall conditions, compared with 10 000 Monte Carlo simulations, the minimum errors of the probability integral for the slope stability coefficient are 0.4% and 0.2%, and the maximum errors are 2.9% and 4.2%, respectively. When addressing high-dimensional stochastic structural problems, the proposed numerical solution method demonstrates satisfactory computational accuracy and efficiency.
-
表 1 不同风化层性能参数
Table 1. Material properties of various weathered layers
边坡结构 γ/kN C（kPa） $\varphi $/（°） 风化情况 平均值 变异系数 平均值 变异系数 平均值 变异系数 土状强风化 19.5 0.22 30 0.21 35 0.09 中等风化 27.0 0.01 2000 0.10 40 0.05 微风化 27.0 0.01 3500 0.06 42 0.03
下载: 导出CSV
表 2 正常工况下各概率积分点
Table 2. Probability integral points for normal conditions
积分值 0.01 0.05 0.1 0.2 0.5 0.8 0.9 0.95 0.99 MCS 1.709 1.869 1.954 2.057 2.254 2.452 2.555 2.640 2.801 Van Leer 1.685 1.832 1.923 2.038 2.245 2.464 2.592 2.693 2.887 相差率/% 1.404 1.984 1.596 0.927 0.408 0.493 1.417 1.984 2.986
下载: 导出CSV
表 3 降雨工况下各概率积分点
Table 3. Probability integral points for rainfall conditions
积分值 0.0001 0.001 0.01 0.02 0.05 0.1 0.5 0.90 0.99 MCS 1.246 1.379 1.611 1.667 1.755 1.835 2.144 2.487 2.832 Van Leer 1.248 1.375 1.542 1.605 1.705 1.799 2.139 2.520 2.865 相差率/% 0.246 0.266 4.277 3.676 2.841 1.958 0.243 1.335 1.157
下载: 导出CSV
-
[1] 李杰, 陈建兵. 随机结构动力反应分析的概率密度演化方法[J]. 力学学报, 2003, 35(4): 437-442. doi: 10.3321/j.issn:0459-1879.2003.04.008Li Jie, Chen Jianbing. Probability density evolution method for analysis of stochastic structural dynamic response[J]. Chinese Journal of Theoretical and Applied Mechanics, 2003, 35(4): 437-442. doi: 10.3321/j.issn:0459-1879.2003.04.008 [2] 陈建兵, 李杰. 概率密度演化理论的基本原理与若干进展[J]. 力学与实践, 2026, 48(2): 203-216. doi: 10.6052/1000-0879-25-313Chen Jianbing, Li Jie. The fundamental principle and recent a{\mathrm{d}}Vances of the probability density evolution theory[J]. Mechanics in Engineering, 2026, 48(2): 203-216. doi: 10.6052/1000-0879-25-313 [3] Zhou H, Fan X P, Liu Y F. Dynamic reliability analysis of the existing bridges based on probability density evolution method[J]. Structures, 2023, 57105245. [4] Xu L, Zhai W M, Gao J M. A probabilistic model for track random irregularities in vehicle/track coupled dynamics[J]. Applied Mathematical Modelling, 2017, 51145-158. [5] 余志武, 张鹏, 丁叁叁. 轨道梁参数随机的磁悬浮列车-轨道梁系统概率密度演化分析[J]. 铁道学报, 2023, 45(12): 138-147. doi: 10.3969/j.issn.1001-8360.2023.12.015Yu Zhiwu, Zhang Peng, Ding Sansan. Probability density evolution analysis of maglev train-guideway system with random guideway parameters[J]. Journal of the China Railway Society, 2023, 45(12): 138-147. doi: 10.3969/j.issn.1001-8360.2023.12.015 [6] Zai D Z, Pang R, Xu B, et al. Slope system stability reliability analysis with multi-parameters using generalized probability density evolution method[J]. Bulletin of Engineering Geology and the Environment, 2021, 80(11): 8419-8431. doi: 10.1007/s10064-021-02399-9 [7] Li J, Chen J B, Fan W L. The equivalent extreme-value event and evaluation of the structural system reliability[J]. Structural Safety, 2007, 29(2): 112-131. doi: 10.1016/j.strusafe.2006.03.002 [8] Chen J B, Li J. Strategy for selecting representative points via tangent spheres in the probability density evolution method[J]. International Journal for Numerical Methods in Engineering, 2008, 74(13): 1988-2014. doi: 10.1002/nme.2246 [9] 朱志辉, 刘禹兵, 高雪萌, 等. 概率密度演化方程差分格式的计算精度及初值条件改进[J]. 工程力学, 2022, 39(11): 13-21. doi: 10.6052/j.issn.1000-4750.2021.06.0477Zhu Zhihui, Liu Yubing, Gao Xuemeng, et al. The calculation precision of probability density evolution equation difference scheme and the improvement of initial condition[J]. Engineering Mechanics, 2022, 39(11): 13-21. doi: 10.6052/j.issn.1000-4750.2021.06.0477 [10] 石晟, 杜东升, 王曙光, 等. 概率密度演化方程TVD格式的自适应时间步长技术及其初值条件改进[J]. 力学学报, 2019, 51(4): 1223-1234. doi: 10.6052/0459-1879-18-446Shi Sheng, Du Dongsheng, Wang Shuguang, et al. Non-uniform time step tvd scheme for probability density evolution function with improvement of initial condition[J]. Chinese Journal of Theoretical and Applied Mechanics, 2019, 51(4): 1223-1234. doi: 10.6052/0459-1879-18-446 [11] Papadopoulos V, Kalogeris I. A Galerkin-based formulation of the probability density evolution method for general stochastic finite element systems[J]. Computational Mechanics, 2016, 57(5): 701-716. doi: 10.1007/s00466-015-1256-9 [12] 陈建兵, 李杰. 基于概率空间剖分的结构非线性随机反应分析[J]. 华中科技大学学报(城市科学版), 2008(4): 1-5. doi: 10.3969/j.issn.2095-0985.2008.04.001Chen Jianbing, Li Jie. Stochastic nonlinear response analysis of structures based on partition of probability-assigned space[J]. Journal of Huazhong University of Science and Technology, 2008(4): 1-5. doi: 10.3969/j.issn.2095-0985.2008.04.001 [13] 陈建兵, 李杰. 随机结构反应概率密度演化分析的切球选点法[J]. 振动工程学报, 2006, 19(1): 1-8. doi: 10.3969/j.issn.1004-4523.2006.01.001Chen Jianbing, Li Jie. Strategy of selecting points via sphere of contact in probability density evolution method for response analysis of stochastic structures[J]. Journal of Vibration Engineering, 2006, 19(1): 1-8. doi: 10.3969/j.issn.1004-4523.2006.01.001 [14] 陈建兵, 李杰. 结构随机响应概率密度演化分析的数论选点法[J]. 力学学报, 2006, 38(1): 134-140. doi: 10.3321/j.issn:0459-1879.2006.01.019Chen Jianbing, Li Jie. Strategy of selecting points via number theoretical method in probability density evolution analysis of stochastic response of structures[J]. Chinese Journal of Theoretical and Applied Mechanics, 2006, 38(1): 134-140. doi: 10.3321/j.issn:0459-1879.2006.01.019 [15] Li J, Chen J B. The number theoretical method in response analysis of nonlinear stochastic structures[J]. Computational Mechanics, 2007, 39(6): 693-708. doi: 10.1007/s00466-006-0054-9 [16] 陈建兵, 张圣涵. 非均布随机参数结构非线性响应的概率密度演化[J]. 力学学报, 2014, 46(1): 136-144.Chen Jianbing, Zhang Shenghan. Probability density evolution analysis of nonlinear response of structures with non-uniform random parameters[J]. Chinese Journal of Theoretical and Applied Mechanics, 2014, 46(1): 136-144. [17] Gao K, Liu G, Tang W. High-dimensional reliability analysis based on the improved number-theoretical method[J]. Applied Mathematical Modelling, 2022, 107: 151-164. doi: 10.1016/j.apm.2022.02.030 [18] 唐树江. 几类高精度高分辨率格式的构造与应用[D]. 湘潭: 湘潭大学, 2019. [19] Li J, Chen J B. Stochastic Dynamics of Structures[M]. New York: John Wiley & Sons, 2009. [20] 赵一飞, 刘浪. 广义概率密度演化方程差分解法的计算精度比较与改进[J]. 南昌大学学报(工科版), 2025, 47(1): 38-43, 48. doi: 10.3969/j.issn.1006-0456.2025.01.005Zhao Yifei, Liu Lang. Comparison and improvement of the calculation accuracy of the difference decomposition method of the generalized probability density evolution equation[J]. Journal of Nanchang University (Engineering & Technology), 2025, 47(1): 38-43,48. doi: 10.3969/j.issn.1006-0456.2025.01.005 [21] 高凯. 基于概率密度演化方法的斜拉索多幅级非线性疲劳可靠度评估[D]. 重庆: 重庆大学, 2021. [22] Barthe F, Guedon O, Mendelson S, et al. A Probabilistic approach to the geometry of the $ l_{p}^{n} $-Ball[J]. Ann. Probability, 2005, 33: 480-513. [23] 杨兵, 杨斐, 盘友峰, 等. 考虑土层倾角影响的层状堆积体基覆型边坡动力失稳研究[J/OL]. 西南交通大学学报, 2025-11-06. | https://kns.cnki.net/kcms/detail/detail.aspx?dbcode=CJFD&dbname=CJFD&filename=XNJT20251105001. [24] GB 50330—2013 建筑边坡工程技术规范[S]. [25] 张继周, 缪林昌. 岩土参数概率分布类型及其选择标准[J]. 岩石力学与工程学报, 2009, 28(增刊2): 3526-3532. doi: 10.3321/j.issn:1000-6915.2009.z2.034Zhang Jizhou, Miao Linchang. Types and selection criteria of probability distribution of rock and soil parameters[J]. Chinese Journal of Rock Mechanics and Engineering, 2009, 28(S2): 3526-3532. doi: 10.3321/j.issn:1000-6915.2009.z2.034 [26] 朱淳, 龚逸非, 宋盛渊, 等. 滑坡多源监测技术及预警模型研究进展与展望[J]. 西南交通大学学报, 2025, 60(6): 1373-1389. doi: 10.3969/j.issn.0258-2724.20230547Zhu Chun, Gong Yifei, Song Shengyuan, et al. Progress and prospects of landslide multi-source monitoring technology and early warning model[J]. Journal of Southwest Jiaotong University, 2025, 60(6): 1373-1389. doi: 10.3969/j.issn.0258-2724.20230547 -
