Influence of Grouting Point Layout Angles on Deformation of Shield Tunnel under Load
-
摘要:
针对传统的地层注浆整治盾构隧道横椭圆变形过程中变形恢复可控性差等问题，创新性地开展了囊袋法注浆整治盾构隧道横椭圆变形试验研究，试验采用2种不同的囊袋布设方案. 试验结果分析表明：隧道在注浆点附近产生了竖椭圆变形，且在注浆点附近的附加土压力、隧道直径和挠曲变形变化最大，沿着隧道两端呈现逐渐递减的趋势；等量注浆下，垂直注浆可以更好地整治既有隧道的横椭圆变形，侧底部注浆能在实现隧道的横椭圆变形恢复效果的同时，对隧道进行抬升，有效降低隧道在运行过程中产生的沉降；在隧道侧底部注浆时，囊袋在膨胀过程中，由于受到已建隧道重力的影响，使注浆导致的隧道变形较垂直注浆有所降低，因此，在注浆过程中建议适当加大注浆量，以达到预期的横椭圆变形恢复效果；注浆后囊袋呈现中间宽，两边窄的圆柱体形状，囊袋法注浆能有效限制浆液扩散路径，浆液在囊袋内发生挤密扩散，使隧道局部所受压力迅速增大，横椭圆变形恢复效果显著；在隧道侧部垂直注浆，横椭圆变形恢复效果显著，但注浆压力过大等原因易诱发盾构隧道管片错台等问题，建议在整治盾构隧道横椭圆变形超限时，宜将注浆点布设于隧道侧底部位置即偏离隧道两侧约30°～60°位置.
Abstract:Aiming at the problem of poor controllability of deformation recovery in the process of transverse elliptic deformation of shield tunnel treated by traditional stratum grouting, the experimental study on transverse elliptic deformation of shield tunnel treated by capsular bag grouting was carried out innovatively. Two different capsular bag layout schemes were adopted in the experiment. The analysis of the test results shows that the tunnel has a vertical elliptical deformation near the grouting point, and the additional earth pressure, tunnel diameter and deflection deformation near the grouting point change the most, showing a gradual decreasing trend along the two ends of the tunnel. Under the same amount of grouting, vertical grouting can better control the transverse elliptic deformation of the existing tunnel, and the side bottom grouting can realize the recovery effect of the transverse elliptic deformation of the tunnel while uplifting the tunnel and effectively reducing the settlement of the tunnel during operation. When grouting at the bottom of the tunnel side, due to the influence of the gravity of the built tunnel, the deformation of the tunnel caused by grouting is lower than that caused by vertical grouting during the expansion process of the bag. Therefore, it is suggested to increase the grouting amount appropriately in the grouting process to achieve the expected recovery effect of transverse ellipse deformation. After grouting, the capsular bag presents a cylindrical shape with wide middle and narrow sides. The capsular bag grouting method can effectively limit the slurry diffusion path, and the slurry is squeezed and diffused in the capsular bag, so that the local pressure of the tunnel increases rapidly, and the recovery effect of transverse ellipse deformation is remarkable. Vertical grouting at the side of the tunnel has a significant effect on the recovery of transverse ellipse deformation, but excessive grouting pressure and other reasons can easily induce problems such as dislocation of shield tunnel segments. It is suggested that when the transverse ellipse deformation of the shield tunnel exceeds the limit, the grouting point should be arranged at the bottom of the tunnel side, that is, about 30°～60°away from both sides of the tunnel.
-
Key words:
- tunnel engineering /
- shield tunnel /
- bag grouting /
- model test
-
图 14 注浆过程中隧道与地层相互作用示意（90°）
Figure 14. Tunnel-stratum interaction in grouting process (90°)
图 16 注浆过程中隧道与地层相互作用示意（120°）
Figure 16. Tunnel-stratum interaction in grouting process (120°)
-
[1] 叶振威, 张东明, 张晋彰, 等. 注浆整治盾构隧道横向大变形下地层响应现场试验研究[J/OL]. 岩土工程学报, 1-9[2025-12-10]. https://link.cnki.net/urlid/32.1124.TU.20241218.2003.008. [2] 苏昂, 封坤, 何川, 等. 高水压大直径盾构隧道管片结构力学特性研究[J/OL]. 西南交通大学学报, 1-14[2025-06-24]. https://link.cnki.net/urlid/51.1277.U.20241204.1745.007. [3] 郭璇, 原森阳, 李志通, 等. 盾构隧道管片超弹性密封垫临界错位研究[J]. 铁道学报, 2024, 46(12): 170-179. doi: 10.3969/j.issn.1001-8360.2024.12.019GUO Xuan, YUAN Senyang, LI Zhitong, et al. Study on critical dislocation of hyperelastic sealing gasket for segmental linings of shield tunnels[J]. Journal of the China Railway Society, 2024, 46(12): 170-179. doi: 10.3969/j.issn.1001-8360.2024.12.019 [4] 梁发云, 袁强, 李家平, 等. 堆载作用下土体分层特性对地铁隧道纵向变形的影响研究[J]. 岩土工程学报, 2020, 42(1): 63-71.LIANG Fayun, YUAN Qiang, LI Jiaping, et al. Influences of soil characteristics on longitudinal deformation of shield tunnels induced by surface surcharge[J]. Chinese Journal of Geotechnical Engineering, 2020, 42(1): 63-71. [5] 魏纲, 洪文强, 魏新江, 等. 基坑开挖引起邻近盾构隧道转动与错台变形计算[J]. 岩土工程学报, 2019, 41(7): 1251-1259. doi: 10.11779/CJGE201907009WEI Gang, HONG Wenqiang, WEI Xinjiang, et al. Calculation of rigid body rotation and shearing dislocation deformation of adjacent shield tunnels due to excavation of foundation pits[J]. Chinese Journal of Geotechnical Engineering, 2019, 41(7): 1251-1259. doi: 10.11779/CJGE201907009 [6] 可文海, 管凌霄, 刘东海, 等. 盾构隧道下穿管道施工引起的管-土相互作用研究[J]. 岩土力学, 2020, 41(1): 221-228, 234. doi: 10.16285/j.rsm.2018.2317KE Wenhai, GUAN Lingxiao, LIU Donghai, et al. Research on upper pipeline-soil interaction induced by shield tunnelling[J]. Rock and Soil Mechanics, 2020, 41(1): 221-228, 234. doi: 10.16285/j.rsm.2018.2317 [7] 赵立财. 盾构隧道混凝土管片接头抗弯与抗剪性能试验研究[J]. 铁道学报, 2024, 46(10): 144-151.ZHAO Licai. Experimental research on bending and shear resistance of concrete segment joints in shield tunnels[J]. Journal of the China Railway Society, 2024, 46(10): 144-151. [8] 江学辉, 罗如平, 罗文俊, 等. 纵向槽钢对隧道力学性能影响的计算方法[J]. 铁道学报, 2025, 47(4): 165-173.JIANG Xuehui, LUO Ruping, LUO Wenjun, et al. Calculation method for mechanical properties of tunnels induced by longitudinal channel steel[J]. Journal of the China Railway Society, 2025, 47(4): 165-173. [9] 周子扬, 张景轩, 封坤, 等. 泥岩地层盾构隧道围岩荷载理论计算方法及现场试验优化研究[J/OL]. 西南交通大学学报, 1-10[2025-06-24]. https://link.cnki.net/urlid/51.1277.u.20250325.1002.002. [10] 张冬梅, 邹伟彪, 闫静雅. 软土盾构隧道横向大变形侧向注浆控制机理研究[J]. 岩土工程学报, 2014, 36(12): 2203-2212. doi: 10.11779/CJGE201412007ZHANG Dongmei, ZOU Weibiao, YAN Jingya. Effective control of large transverse deformation of shield tunnels using grouting in soft deposits[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(12): 2203-2212. doi: 10.11779/CJGE201412007 [11] 王如路, 张冬梅. 超载作用下软土盾构隧道横向变形机理及控制指标研究[J]. 岩土工程学报, 2013, 35(6): 1092-1101.WANG Rulu, ZHANG Dongmei. Mechanism of transverse deformation and assessment index for shield tunnels in soft clay under surface surcharge[J]. Chinese Journal of Geotechnical Engineering, 2013, 35(6): 1092-1101. [12] 郦亮, 刘干斌, 陆幸, 等. 邻近基坑开挖地铁隧道的注浆保护试验与数值模拟[J]. 地下空间与工程学报, 2021, 17(增1): 387-396.LI Liang, LIU Ganbin, LU Xing, et al. Grouting protection test and numerical simulation of subway tunnel excavated near foundation pit[J]. Chinese Journal of Underground Space and Engineering, 2021, 17(S1): 387-396. [13] 黄大维, 陈后宏, 赵梽錡, 等. 侧部注浆点布设对盾构隧道受荷变形影响分析[J]. 岩土工程学报, 2025, 47(8): 1595-1606.HUANG Dawei, CHEN Houhong, ZHAO Zhiqi, et al. Influence of lateral grouting points on deformation of shield tunnels under loads[J]. Chinese Journal of Geotechnical Engineering, 2025, 47(8): 1595-1606. [14] 蓝沐林, 沈梦芬, 何溯, 等. 注浆加固对盾构施工沉降控制成效的概率评估[J]. 城市轨道交通研究, 2024, 27(12): 167-175. doi: 10.16037/j.1007-869x.2024.12.027LAN Mulin, SHEN Mengfen, HE Su, et al. Probabilistic evaluation of grouting reinforcement on settlement control effectiveness in shield tunneling construction[J]. Urban Mass Transit, 2024, 27(12): 167-175. doi: 10.16037/j.1007-869x.2024.12.027 [15] 刘杰辉. 地铁盾构隧道注浆压力对地表沉降的影响分析[J]. 智能城市, 2024, 10(9): 115-117. doi: 10.19301/j.cnki.zncs.2024.09.036LIU Jiehui. Analysis of the influence of grouting pressure on surface subsidence in subway shield tunnel[J]. Intelligent City, 2024, 10(9): 115-117. doi: 10.19301/j.cnki.zncs.2024.09.036 [16] 朱旻, 龚晓南, 高翔, 等. 盾构隧道注浆纠偏模型试验研究[J]. 铁道科学与工程学报, 2020, 17(3): 660-667. doi: 10.19713/j.cnki.43-1423/u.T20190433ZHU Min, GONG Xiaonan, GAO Xiang, et al. Model tests of correction of displaced shield tunnel using grouting technique[J]. Journal of Railway Science and Engineering, 2020, 17(3): 660-667. doi: 10.19713/j.cnki.43-1423/u.T20190433 [17] 黄大维, 刘家璇, 谭满生, 等. 盾构隧道底部注浆抬升模拟试验研究[J]. 岩土力学, 2024, 45(增1): 371-381.HUANG Dawei, LIU Jiaxuan, TAN Mansheng, et al. Scaled model test on interaction between a shield tunnel and ground[J]. Rock and Soil Mechanics, 2024, 45(S1): 371-381. [18] 李明宇, 王越, 陈健, 等. 同步注浆上浮力作用下大盾构管片瞬时变形特征模型试验研究[J]. 铁道学报, 2025, 47(1): 171-182. doi: 10.3969/j.issn.1001-8360.2025.01.020LI Mingyu, WANG Yue, CHEN Jian, et al. Model test study on instantaneous deformation characteristics of large shield segments under synchronous grouting buoyancy effect[J]. Journal of the China Railway Society, 2025, 47(1): 171-182. doi: 10.3969/j.issn.1001-8360.2025.01.020 [19] 周俊宏, 宫全美, 周顺华, 等. 盾构隧道抬升作用下极限上覆土压力计算方法[J]. 岩土力学, 2016, 37(7): 1969-1976.ZHOU Junhong, GONG Quanmei, ZHOU Shunhua, et al. Calculation method of limit overlying earth pressure on shield tunnel during lifting[J]. Rock and Soil Mechanics, 2016, 37(7): 1969-1976. [20] GONG Q M, ZHAO Y, ZHOU J H, et al. Uplift resistance and progressive failure mechanisms of metro shield tunnel in soft clay[J]. Tunnelling and Underground Space Technology, 2018, 82: 222-234. doi: 10.1016/j.tust.2018.08.038 [21] 黄大维, 赵梽錡, 徐长节, 等. 侧部注浆对已建盾构隧道受荷变形影响试验研究[J]. 岩土工程学报, 2024, 46(3): 510-518.HUANG Dawei, ZHAO Zhiqi, XU Changjie, et al. Experimental study on influences of side grouting on deformation of shield tunnels under loads[J]. Chinese Journal of Geotechnical Engineering, 2024, 46(3): 510-518. [22] 黄大维, 刘家璇, 徐长节, 等. 浆液扩散模式对地层附加土压力影响试验研究[J]. 华中科技大学学报(自然科学版), 2024, 52(10): 20-26.HUANG Dawei, LIU Jiaxuan, XU Changjie, et al. Experimental study on influence of slurry diffusion mode on additional earth pressure of formation[J]. Journal of Huazhong University of Science and Technology (Natural Science Edition), 2024, 52(10): 20-26. [23] 曹占林, 周顺华, 刘建国, 等. 基于油脂逃逸试验的盾尾密封性能影响研究[J]. 铁道学报, 2025, 47(12): 198-205.CAO Zhanlin, ZHOU Shunhua, LIU Jianguo, et al. Research on influence of grease escape behavior on shield tail sealing performance[J]. Journal of the China Railway Society, 2025, 47(12): 198-205. [24] 余伟. 侧部多点位注浆对盾构隧道的影响分析[C]//2024年全国工程建设行业施工技术交流会论文集(上册). 北京: [出版社不详], 2024: 160-164. [25] 黄大维, 陈后宏, 徐长节, 等. 联络通道施工盾构机始发对已建盾构隧道影响试验研究[J]. 岩土工程学报, 2025, 47(5): 987-994.HUANG Dawei, CHEN Houhong, XU Changjie, et al. Impact of starting of tunnel boring machine during construction of connecting channel on existing shield tunnels[J]. Chinese Journal of Geotechnical Engineering, 2025, 47(5): 987-994. -
