Pore Pressure Inversion Model for Tunnel Lining Concrete Spalling Driven by Fire Test Temperature
-
摘要:
为精确量化与预测隧道衬砌混凝土在火灾高温下爆裂发生临界时刻内部孔隙压力，开展隧道衬砌混凝土的火灾暴露试验，获取了衬砌混凝土试件在火灾过程中的瞬态温度场和孔隙压力演化规律；在试验基础上，以试验温度数据作为关键驱动，构建一个“准稳态”衬砌混凝土高温爆裂孔隙压力反演模型；通过与试验结果对比，验证模型的可靠性，并揭示衬砌混凝土高温爆裂时刻孔隙压力的空间分布特性. 研究结果表明：对于初始含水率为3.50%的典型隧道衬砌混凝土试件，在HC火灾条件下发生爆裂的临界时刻，其孔隙压力值为0.79～0.96 MPa，平均值为0.88 MPa；模型预测孔隙压力值为0.91～1.13 MPa，平均值为0.99 MPa，模型预测的孔隙压力峰值与试验数据吻合良好，误差为2.08～28.41%，平均误差为15.23%，低于20%；隧道衬砌混凝土高温爆裂时刻孔隙压力沿受热面纵深方向呈现“驼峰”型空间分布，其分布规律可解析为热裂损伤区、孔隙压力集中区和热力学平衡区.
Abstract:To accurately quantify and predict the internal pore pressure of tunnel lining concrete at the critical moment of spalling under high fire temperature, fire exposure tests on tunnel lining concrete were conducted. The evolution laws of the transient temperature field and pore pressure of lining concrete specimens during the fire process were obtained. Based on the tests, a “quasi-steady-state” pore pressure inversion model for high-temperature spalling of lining concrete was constructed, using experimental temperature data as the key driver. The reliability of the model was validated by comparing it with experimental results, and the spatial distribution characteristics of pore pressure at the moment of high-temperature spalling were revealed. The results show that for typical tunnel lining concrete specimens with an initial moisture content of 3.50%, at the critical moment of spalling under the HC fire condition, the pore pressure value ranges from 0.79 MPa to 0.96 MPa, with an average value of 0.88 MPa. The pore pressure value predicted by the model ranges from 0.91 MPa to 1.13 MPa, with an average of 0.99 MPa. The peak pore pressure predicted by the model agrees well with the experimental data, with errors ranging from 2.08% to 28.41% and an average error of 15.23%, which is lower than 20%. The pore pressure along the depth direction from the heated surface at the high-temperature spalling moment exhibits a “hump-shaped” spatial distribution, which can be resolved into the thermal cracking zone, the pore pressure concentration zone, and the thermodynamic equilibrium zone.
-
Key words:
- tunnel /
- tunnel lining /
- pore pressure /
- inversion model /
- quasi-steady-state /
- concrete spalling
-
图 6 多孔介质材料微观结构及其孔隙水汽平衡机理
Figure 6. Microstructure of porous media and mechanism of pore water-vapor equilibrium
图 8 衬砌混凝土爆裂时刻温度空间分布
Figure 8. Spatial temperature distribution of lining concrete at moment of spalling
表 2 混凝土试块的平均含水率及抗压强度
Table 2. Average moisture content and compressive strength of concrete specimens
类型 龄期/d 含水率 抗压强度/MPa C30 54 3.50% 30
下载: 导出CSV
表 3 爆裂时刻孔隙压力
Table 3. Pore pressure at moment of spalling
试块编号 爆裂部位/
cm孔隙压力/
MPa含水率/% 平均值/
MPaTest-1 1 0.79 3.50 0.88 Test-1 2 0.96 Test-2 1 0.88
下载: 导出CSV
表 4 模型参数
Table 4. Model parameters
含水率/% 孔隙率 孔隙半径/μm 渗透系数/m2 pb/MPa Bs/MPa 3.50 0.20 23.40 1.35 × 10−17 19.29 30
下载: 导出CSV
表 5 爆裂部位孔隙压力实测与预测结果
Table 5. Measured and predicted results of pore pressure at spalling locations
编号 深度/cm 预测值/MPa 试验值/MPa 误差/% 含水率/% 试验均值/MPa 预测均值/MPa 误差均值/% Test-1 1 0.91 0.79 15.19 3.50 0.88 0.99 15.23 Test-1 2 0.94 0.96 2.08 Test-2 1 1.13 0.88 28.41
下载: 导出CSV
-
