Seismic Performance of CFSST Column-H-Shaped Steel Beam Joints with External Stiffening Rings
-
摘要:
为研究装配式方钢管混凝土外加强环梁柱节点的抗震性能，对3个不同构造方钢管混凝土柱——H型钢梁外加强环节点进行拟静力试验，研究节点的承载力、破坏过程与破坏模式、节点区应力分布以及各抗震性能指标等. 试验研究表明：节点的破坏均出现在梁端连接区域，表现为环板外梁截面的屈曲和断裂破坏；节点的滞回曲线均呈现“梭形”，伴有明显的捏拢效应；正向与负向加载过程基本对称，在滞回曲线上可观察到转动刚度为0的“滑移段”；节点延性系数在2.55～4.20，极限转角在0.032～0.062 rad，均超过抗震规范要求；相较于整体式节点，分离式节点的延性和累积耗能分别提高60.7%和209.0%，而悬臂耗能式节点的承载力、延性和耗能能力较整体式节点分别提高38.1%、64.7%和400.3%； “分离式多层传力”与“悬臂段-耗能盖板双阶段耗能”的构造形式能有效优化节点的抗震性能；模拟与试验的滞回曲线、破坏模式吻合良好，验证了模型的有效性.
Abstract:Quasi-static tests were conducted on three types of concrete-filled square steel tube (CFSST) column-H-shaped steel beam joints with external stiffening rings featuring different structures to investigate the seismic performance of prefabricated CFSST column—H-shaped steel beam joints with external stiffening rings. The bearing capacity, failure processes and modes, stress distribution in joint zones, and various seismic performance indicators were studied. The experimental results show that joint failures all occur near the beam ends, characterized by buckling and fracture failure of the beam sections outside the diaphragm. The hysteresis curves of the joints all exhibit a “spindle shape” with significant pinching effects. The loading process is essentially symmetric in the positive and negative directions, with a sliding segment of zero rotational stiffness observed in the curves. The ductility coefficient of joints ranges from 2.55 to 4.20, and the ultimate angle of rotation is between 0.032 rad and 0.062 rad, both exceeding the requirements specified in seismic codes. Compared to the integral external stiffening rings, the separate external stiffening rings exhibit increases of 60.7% in ductility and 209.0% in cumulative energy dissipation. Meanwhile, the cantilever energy-dissipating external stiffening rings show improvements of 38.1% in bearing capacity, 64.7% in ductility, and 400.3% in energy dissipation capacity over the integral connection. This indicates that the structural configuration of “separate multi-layer force transfer” and “dual-stage energy dissipation via cantilever segments and energy-dissipating cover plates” can effectively optimize the seismic performance of joints. There is sound agreement between the simulated and experimental hysteresis curves and failure modes, validating the numerical analysis reliability.
-
图 13 累积耗能-位移关系
Figure 13. Relations between cumulative energy dissipation and displacement
表 1 钢材力学性能
Table 1. Mechanical properties of steel
取样位置 厚度/mm fy/（N·mm−1） ft/（N·mm−1） Es/（ × 105 N·mm−1） ν 钢梁腹板 6 294.3 424.6 2.05 0.29 钢梁翼缘/腹板连接板/拼接板 8 346.5 457.3 2.02 0.32 方钢管柱 10 304.2 460.5 2.06 0.30 水平连接板/耗能盖板 12 276.6 444.3 2.10 0.29 整体式外环板/外环单板 16 295.3 452.5 2.06 0.31 注：fy、ft分别为钢材屈服强度与抗拉强度，Es为钢材弹性模量，ν为泊松比.
下载: 导出CSV
表 2 试件试验特征值
Table 2. Characteristic values of specimen test
试件编号 加载方向 Py/kN Δy/mm Pmax/kN Δmax/mm Pu/kN Δu/mm μ $ \overline{\mu } $ Ki/（kN·m·rad−1） $ \overline{K} $/（kN·m·rad−1） JD-1 正向 106.3 20.65 140.3 38.64 112.4 42.92 2.1 2.55 14157.4 14050.3 反向 −115.5 −14.27 −129.3 −34.03 −109.9 −42.70 3.0 13943.1 JD-2 正向 112.3 18.20 124.0 60.30 105.4 77.66 4.3 4.1 14320.1 13931.4 反向 −113.0 −18.31 −125.2 −58.31 −106.4 −72.23 3.9 13542.8 JD-3 正向 138.9 17.28 175.7 71.13 149.3 84.00 4.8 4.2 20970.3 21054.9 反向 −168.1 −22.51 −196.7 −79.4 −169.7 −80.59 3.6 21139.6 注：$ \overline{\mu } $为延性系数均值，Ki、$ \overline{K} $分别为初始转动刚度及其均值.
下载: 导出CSV
表 3 有限元与试验承载力对比
Table 3. Comparison of bearing capacities of finite elements and tests
试件编号 加载方向 Pmax,t/kN Pmax,f/kN Pmax, e/% JD-1 正向 140.3 154.6 10.19 反向 −129.3 −153.6 18.79 JD-2 正向 124 124.4 0.32 反向 −125.2 −126.9 1.36 JD-3 正向 175.7 182.2 3.70 反向 −196.7 −181.6 −7.68 注：Pmax,t为试验峰值荷载，Pmax,f为有限元峰值荷载，Pmax, e=（Pmax,f－Pmax,t）/Pmax,t × 100%.
下载: 导出CSV
-
[1] 韩林海, 杨有福, 杨华, 等. 基于全寿命周期的钢管混凝土结构分析理论及其应用[J]. 科学通报, 2020, 65(增2): 3173-3184. doi: 10.1360/TB-2020-0618HAN Linhai, YANG Youfu, YANG Hua, et al. Life-cycle based analytical theory of concrete-filled steel tubular structures and its applications[J]. Chinese Science Bulletin, 2020, 65(S2): 3173-3184. doi: 10.1360/TB-2020-0618 [2] 闻洋, 李兆建, 于蛟. 钢管混凝土风电塔架球式节点的力学性能分析[J]. 西南交通大学学报, 2023, 58(6): 1440-1448. doi: 10.3969/j.issn.0258-2724.20210583WEN Yang, LI Zhaojian, YU Jiao. Mechanical property analysis of spherical joints of concrete-filled steel tubular wind power towers[J]. Journal of Southwest Jiaotong University, 2023, 58(6): 1440-1448. doi: 10.3969/j.issn.0258-2724.20210583 [3] 欧智菁, 陈伟隆, 曹磊. UHPC预制管混凝土组合柱抗震性能[J]. 西南交通大学学报, 2025, 60(1): 63-71. doi: 10.3969/j.issn.0258-2724.20230073OU Zhijing, CHEN Weilong, CAO Lei. Seismic performance of concrete composite columns of ultra-high performance concrete precast pipe[J]. Journal of Southwest Jiaotong University, 2025, 60(1): 63-71. doi: 10.3969/j.issn.0258-2724.20230073 [4] 朱圣春, 崔冰, 宋颖彤, 等. UHPC预应力连接装配式桥墩抗震设计方法研究[J/OL]. 西南交通大学学报, 1-1(2025-06-10). https://link.cnki.net/urlid/51.1277.U.20250610.1231.002. [5] 管民生, 黄献奇, 杜宏彪, 等. 矩形钢管高强混凝土框架抗震性能分析[J]. 西南交通大学学报, 2019, 54(3): 483-491. doi: 10.3969/j.issn.0258-2724.20170809GUAN Minsheng, HUANG Xianqi, DU Hongbiao, et al. Seismic behavior of rectangular high-strength concrete-filled steel tube frame structure[J]. Journal of Southwest Jiaotong University, 2019, 54(3): 483-491. doi: 10.3969/j.issn.0258-2724.20170809 [6] ELSABBAGH A, SHARAF T, NAGY S, et al. Behavior of extended end-plate bolted connections subjected to monotonic and cyclic loads[J]. Engineering Structures, 2019, 190: 142-159. doi: 10.1016/j.engstruct.2019.04.016 [7] 赵均海, 樊军超, 高伟琪. H型钢梁与矩形钢管混凝土柱平齐式端板单边螺栓连接节点弯矩-转角分析模型[J]. 工程力学, 2021, 38(6): 91-102. doi: 10.6052/j.issn.1000-4750.2020.07.0436ZHAO Junhai, FAN Junchao, GAO Weiqi. Moment-rotation analysis model of flush end-plate bolted connections between H-shaped steel beams and rectangular CFST columns[J]. Engineering Mechanics, 2021, 38(6): 91-102. doi: 10.6052/j.issn.1000-4750.2020.07.0436 [8] 郏书朔, 王燕, 王修军, 等. 矩形钢管柱与H型钢梁单边螺栓连接节点的抗震性能与恢复力模型研究[J]. 建筑结构学报, 2020, 41(5): 168-179.JIA Shushuo, WANG Yan, WANG Xiujun, et al. Seismic behavior and restoring force model of connections between rectangular tubular columns and H-shaped beams using single direction bolts[J]. Journal of Building Structures, 2020, 41(5): 168-179. [9] 高春彦, 王延彬, 孙凯琦, 等. 改进型钢管混凝土柱-H型钢梁槽形端板节点抗震性能研究[J]. 建筑钢结构进展, 2025, 27(8): 1-12.GAO Chunyan, WANG Yanbin, SUN Kaiqi, et al. Seismic performance of improved conrete-filled steel tubular column to H-shaped steel beam groove end-plate joint[J]. Progress in Steel Building Structures, 2025, 27(8): 1-12. [10] DERAKHSHAN H, SHEKASTEHBAND B. Seismic performance of bolted T-stub Beam-to-Box column connection[J]. Structures, 2023, 56: 104873. doi: 10.1016/j.istruc.2023.104873 [11] 刘秀丽, 王燕, 李美红, 等. 钢结构T型连接节点受力性能试验研究[J]. 西安建筑科技大学学报(自然科学版), 2015, 47(6): 848-853.LIU Xiuli, WANG Yan, LI Meihong, et al. Experimental study on the T-stub connections in steel structure[J]. Journal of Xi’an University of Architecture & Technology (Natural Science Edition), 2015, 47(6): 848-853. [12] LIU X C, WU X T, CHEN X S. Seismic performance of joint between L-shaped CFST column and H-section beam with lower plate and extended flange plate[J]. Engineering Structures, 2022, 261: 114283. doi: 10.1016/j.engstruct.2022.114283 [13] LIU X C, WANG Y, CUI X X, et al. Seismic performance of bolted beam-to-column connection with rib-stiffened splicing plate[J]. Journal of Constructional Steel Research, 2020, 174: 106300. doi: 10.1016/j.jcsr.2020.106300 [14] LIU X C, LIU Y K, CHEN X S, et al. Analysis of bolted connection for H-section beam and square steel tube column[J]. Structures, 2024, 60: 105945. doi: 10.1016/j.istruc.2024.105945 [15] 王伟, 秦希, 王俊杰. 内隔板式与隔板贯通式方钢管混凝土柱-H形钢梁节点抗连续倒塌性能对比[J]. 建筑结构学报, 2017, 38(增1): 362-368.WANG Wei, QIN Xi, WANG Junjie. Comparison of progressive collapse resistance of concrete-filled square steel tubular column-H-shaped steel beam joints with internal diaphragm and diaphragm penetration[J]. Journal of Building Structures, 2017, 38(S1): 362-368. [16] 杨松森, 王燕, 马强强. 装配式外套筒-加强式外伸端板组件梁柱连接节点抗震性能试验研究[J]. 土木工程学报, 2017, 50(11): 76-86.YANG Songsen, WANG Yan, MA Qiangqiang. Experimental study on seismic behavior of prefabricated outer sleeve-overhang plate joint between column and beam[J]. China Civil Engineering Journal, 2017, 50(11): 76-86. [17] ZHAI S Y, LYU Y F, CAO K, et al. Seismic behavior of an innovative bolted connection with dual-slot hole for modular steel buildings[J]. Engineering Structures, 2023, 279: 115619. doi: 10.1016/j.engstruct.2023.115619 [18] YANG C, CHEN H, OU J P. Seismic behavior of composite bolted T-shaped exterior joints in modular steel construction[J]. Journal of Constructional Steel Research, 2024, 212: 108249. doi: 10.1016/j.jcsr.2023.108249 [19] 丁阳, 邓恩峰, 宗亮, 等. 模块化钢结构建筑连接节点研究进展[J]. 建筑结构学报, 2019, 40(3): 33-40.DING Yang, DENG Enfeng, ZONG Liang, et al. State-of-the-art on connection in modular steel construction[J]. Journal of Building Structures, 2019, 40(3): 33-40. [20] LU Y T, GUO Z X, BASHA S H, et al. Performance of steel beams with replaceable buckling restrained fuses under cyclic loading[J]. Journal of Constructional Steel Research, 2022, 194: 07310. doi: 10.1016/j.jcsr.2022.107310 [21] HE X Z, CHEN Y Y, KE K, et al. Development of a connection equipped with fuse angles for steel moment resisting frames[J]. Engineering Structures, 2022, 265: 114503. doi: 10.1016/j.engstruct.2022.114503 [22] 韩重庆, 杨瑞丰, 李向民, 等. 装配式矩形钢管混凝土柱-钢梁侧板连接节点抗震性能研究[J]. 建筑结构学报, 2024, 45(4): 50-60. doi: 10.14006/j.jzjgxb.2023.0199HAN Chongqing, YANG Ruifeng, LI Xiangmin, et al. Study on seismic performance of prefabricated CFST rectangular column to steel beam connections with side plate[J]. Journal of Building Structures, 2024, 45(4): 50-60. doi: 10.14006/j.jzjgxb.2023.0199 [23] 姜子钦, 杨晓峰, 张爱林, 等. 可恢复功能装配式中柱节点耗能装置试验研究[J]. 建筑结构学报, 2020, 41(1): 15-23. doi: 10.14006/j.jzjgxb.2018.0598JIANG Ziqin, YANG Xiaofeng, ZHANG Ailin, et al. Experimental study on energy consuming devices for earthquake-resilient prefabricated cross joints[J]. Journal of Building Structures, 2020, 41(1): 15-23. doi: 10.14006/j.jzjgxb.2018.0598 [24] 吴成龙, 潘运, 尚育卿, 等. 新型装配式人工塑性铰节点抗震性能试验研究[J]. 中南大学学报(自然科学版), 2024, 55(12): 4493-4504. doi: 10.11817/j.issn.1672-7207.2024.12.010WU Chenglong, PAN Yun, SHANG Yuqing, et al. Experimental study on seismic performance of a new type of prefabricated artificial plastic hinge joints[J]. Journal of Central South University (Science and Technology), 2024, 55(12): 4493-4504. doi: 10.11817/j.issn.1672-7207.2024.12.010 [25] 王文达, 安爱红, 袁玉杰, 等. 可更换H型钢梁柱仿生铰节点抗震及修复性能试验研究[J]. 建筑结构学报, 2025, 46(6): 47-59.WANG Wenda, AN Aihong, YUAN Yujie, et al. Experimental study on seismic and repair performance of H-shaped steel beam-column joints with replaceable bio-inspired hinges[J]. Journal of Building Structures, 2025, 46(6): 47-59. [26] CHEN P, PAN J R, HU F X, et al. Numerical investigation on seismic resilient steel beam-to-column connections with replaceable buckling-restrained fuses[J]. Journal of Constructional Steel Research, 2022, 199: 107598. doi: 10.1016/j.jcsr.2022.107598 [27] BAGHERI SABBAGH A, CHAN T M, MOTTRAM J T. Detailing of Ⅰ-beam-to-CHS column joints with external diaphragm plates for seismic actions[J]. Journal of Constructional Steel Research, 2013, 88: 21-33. doi: 10.1016/j.jcsr.2013.05.006 [28] KHADOR M, CHAN T M. Cyclic behaviour of external diaphragm joint to CHS column with built-in replaceable links[J]. Steel Construction, 2016, 9(4): 331-338. doi: 10.1002/stco.201610040 [29] RICHARDS P W, OH S S. Cyclic behavior of replaceable shear fuse connections for steel moment frames[J]. Journal of Structural Engineering, 2019, 145(12): 04019156. doi: 10.1061/(ASCE)ST.1943-541X.0002412 [30] RICHARDS P W. A repairable connection for earthquake-resisting moment frames[J]. Steel construction, 2019, 12(3): 191-197. doi: 10.1002/stco.201900015 [31] 王修军, 王燕, 安琦. 装配式梁柱外环板高强螺栓连接节点抗震性能试验研究[J]. 土木工程学报, 2020, 53(6): 53-63, 78.WANG Xiujun, WANG Yan, AN Qi. Experimental study on seismic behavior of prefabricated beam-to-column high-strength bolted joint with external diaphragms[J]. China Civil Engineering Journal, 2020, 53(6): 53-63, 78. [32] GB/T 228.1—2010金属材料 拉伸试验 第1部分: 室温试验方法[S]. [33] GB 50011—2001建筑抗震设计规范[S]. [34] CECS 28—2012钢管混凝土结构技术规程[S]. [35] FEMA-350 Recommended seismic design criteria for new steel moment frame buildings[S]. [36] 殷晓三. 无明显屈服特征构件屈服点的确定与评价[J]. 地震工程与工程振动, 2019, 39(3): 143-150. doi: 10.13197/j.eeev.2019.03.143.yinxs.014YIN Xiaosan. Evaluation and determination methods on yield point of structural components without obvious yield feature[J]. Earthquake Engineering and Engineering Dynamics, 2019, 39(3): 143-150. doi: 10.13197/j.eeev.2019.03.143.yinxs.014 [37] 张立平, 吴轶, 杨春, 等. 预制混凝土梁柱栓板机械连接节点抗震性能研究[J/OL]. 西南交通大学学报, 1-10[2026-01-15]. https://link.cnki.net/urlid/51.1277.U.20250618.1526.004. [38] 王坦, 杨帆, 周志杰, 等. 复合盐侵蚀下内置螺旋箍筋芯柱的混合配筋柱抗震性能[J/OL]. 西南交通大学学报, 1-11 (2025-04-03). https://link.cnki.net/urlid/51.1277.U.20250403.1346.002. [39] 李补拴, 张坤, 周伟, 等. 冷弯薄壁型钢部分包覆轻质混凝土十形柱的抗震性能[J]. 西南交通大学学报, 2026, 61(1): 136-146.Li Bushuan, Zhang Kun, Zhou Wei, et al. Seismic performance of cross-shaped columns partially encased with cold-formed thin-walled steel and filled with lightweight concrete[J]. Journal of Southwest Jiaotong University, 2026, 61(1): 136-146. [40] JGJ/T 101—2015建筑抗震试验规程[S]. [41] 赵华, 袁维光, 魏丞瑾, 等. 配置高强钢棒的混凝土框架结构抗震性能的试验研究[J/OL]. 西南交通大学学报, 1-10(2025-04-25). https://link.cnki.net/urlid/51.1277.U.20250425.1041.004. [42] 刘威. 钢管混凝土局部受压时的工作机理研究[D]. 福州: 福州大学, 2005. [43] 陈明, 胡云龙, 胡方琪, 等. 腹板加劲冷弯型钢T形拼合边柱受压性能研究[J/OL]. 西南交通大学学报, 1-12(2025-03-24). https://link.cnki.net/urlid/51.1277.u.20250324.1529.011. [44] 梁桓玮, 许春荣, 林昱, 等. 轴压比对钢壳混凝土索塔的滞回性能影响[J/OL]. 西南交通大学学报, 1-11(2025-06-19). https://link.cnki.net/urlid/51.1277.U.20250619.1547.004. -
