Dynamic Response and Deformation and Failure Modes of Reservoir Bank Deposit Slopes Based on Shaking Table Tests
-
摘要:
为揭示蓄水与地震共同作用下库岸堆积体斜坡的动力失稳机理，以两河口水电站白龙堆积体岸坡为原型开展振动台模型试验，分析耦合工况下岸坡的动力响应、能量演化与变形破坏全过程；采用逐级加载汶川地震波的方式开展激振试验；结合加速度、孔隙水压力监测与希尔伯特-黄变换时频分析手段，识别坡体内部损伤演化特征. 结果表明：1）蓄水条件下坡体除坡顶存在动力放大效应外，水位线附近出现显著局部放大现象；水位线附近坡体低频能量明显高于坡体中部及上部，蓄水会加剧该区域低频能量聚集；地震动峰值加速度超过 0.5
g 后，软弱夹层处孔隙水压力发生突增，土体有效应力降低. 2）边际谱分析显示，岸坡损伤最先发生在水位线附近与坡顶位置，损伤随地震强度增大逐步向坡体上部扩展；蓄水-地震共同作用下，岸坡以水位线附近变形破坏为先导，上部坡体持续产生损伤，最终沿软弱夹层发生牵引式滑动失稳；坡体演化依次经历侵蚀变形、局部破坏累积、局部变形破坏、整体滑动失稳 4 个阶段. 研究结果可为西南库区同类堆积体岸坡抗震稳定性评价提供试验支撑.Abstract:Shaking table model tests were conducted on the Bailong deposit bank slope of the Lianghekou Hydropower Station to reveal the dynamic instability mechanism of reservoir bank deposit slopes under the combined action of impoundment and earthquakes. The dynamic response, energy evolution, and whole deformation-failure process of the bank slope in coupling conditions were analyzed. Wenchuan seismic waves with step-increased peak acceleration were adopted for excitation tests. Acceleration and pore water pressure monitoring, together with Hilbert-Huang transform time-frequency analysis, were applied to identify the internal damage evolution of the slope mass. The results show that significant local amplification occurs near the water level, besides the dynamic amplification at the slope crest in impoundment conditions. Low-frequency energy near the water level is obviously higher than that in the middle and upper slopes, and impoundment aggravates the accumulation of low-frequency energy in this zone. Pore water pressure in the weak interlayer rises sharply when seismic peak acceleration exceeds 0.5 g, which reduces the effective stress of the soil mass. Marginal spectrum analysis indicates that slope damage is initiated near the water level and slope crest, and propagates upward with the increasing earthquake strength. Under the combined action of impoundment and earthquakes, deformation and failure first take place near the water level. Continuous damage develops in the upper-slope mass, and traction-type sliding failure eventually occurs along the weak interlayer. The slope evolution includes four successive stages: erosion deformation, local damage accumulation, local deformation and failure, and overall sliding instability. The findings provide experimental support for seismic stability evaluation of similar deposit bank slopes in southwestern reservoir areas.
-
图 8 不同条件下斜坡加速度放大系数云图
Figure 8. Cloud map of slope acceleration amplification factor in different conditions
图 9 沿坡面加速度放大系数变化规律
Figure 9. Variation pattern of acceleration amplification factor along slope surface in X and Z directions
图 10 地震作用下孔隙水压力变化规律
Figure 10. Variation pattern of pore water pressure under the action of earthquakes
图 11 0.10g条件下典型测点处Hilbert谱
Figure 11. Hilbert spectrum at typical measurement points under 0.10g
图 12 地震作用下堆积体与基岩的PMSA沿高程变化规律
Figure 12. Variation pattern of PMSA between deposits and bedrock along elevation under the action of earthquakes
图 14 蓄水与地震作用下库岸堆积体斜坡变形破坏模式
Figure 14. Deformation and failure mode of reservoir bank deposit slope under the combined action of impoundment and earthquakes
表 1 振动台试验的相似关系
Table 1. Similarity relations for shaking table tests
序号 物理量 量纲 相似比 1 几何尺寸L [L] 10 2 重度γ [M] [L]−2[T]−2 1 3 重力加速度g [L][T]−2 1 4 内摩擦角φ / 1 5 黏聚力c [M] [L]−1[T]−2 10 6 压缩模量E [M] [L]−1[T]−2 10 7 边坡倾角θ / 1 8 渗透系数k [L]2[T]−1 1 9 峰值加速度a [L][T]2 1 10 泊松比μ / 1 11 振动频率f [T]−1 0.316 12 时间t [T] 3.16
下载: 导出CSV
表 2 原型与模型关键物理力学参数
Table 2. Key physical mechanical parameters of prototypes and similar materials
类型 项目 密度/（g•cm−3） 弹性模量/MPa 泊松比 渗透系/（cm•s−1） 黏聚力/kPa 内摩擦角/（°） 堆积体 原型值 2.10 800 0.30 4.3 × 10−4 45.0 28.1 相似计算值 2.10 80 0.30 4.3 × 10−4 4.5 28.1 模型值 2.10 75 0.28 3.6 × 10−4 4.2 27.6 软弱夹层 原型值 1.78 300 0.32 1.8 × 10−3 17.1 22.1 相似计算值 1.78 30 0.32 1.8 × 10−3 1.7 22.1 模型值 1.78 33 0.31 2.4 × 10−3 2.2 20.1 基岩 原型值 2.50 10000 0.26 2.1 × 10−7 510.0 38.1 相似计算值 2.43 1000 0.26 2.1 × 10−7 51.0 38.1 模型值 2.43 890 0.24 2.4 × 10−7 50.0 40.2
下载: 导出CSV
表 3 振动台试验加载工况
Table 3. Loading conditions of shaking table test
工况 峰值
加速度/
（×g）地震波
类型振动
方向工况 峰值
加速度/
（×g）地震波
类型振动
方向1 0.05 白噪声 15 0.50 汶川波 Y 2 0.10 汶川波 X 16 0.05 白噪声 3 0.10 汶川波 Y 17 0.60 汶川波 X 4 0.05 白噪声 18 0.60 汶川波 Y 5 0.20 汶川波 X 19 0.05 白噪声 6 0.20 汶川波 Y 20 0.70 汶川波 X 7 0.05 白噪声 21 0.70 汶川波 Y 8 0.30 汶川波 X 22 0.05 白噪声 9 0.30 汶川波 Y 23 0.80 汶川波 X 10 0.05 白噪声 24 0.80 汶川波 Y 11 0.40 汶川波 X 25 0.05 白噪声 12 0.40 汶川波 Y 26 0.90 汶川波 X 13 0.05 白噪声 27 0.90 汶川波 Y 14 0.50 汶川波 X
下载: 导出CSV
-
[1] 胥杰. 我国水电建设现状及其发展前景[J]. 工程技术研究, 2019, 4(5): 246, 254.Xu Jie. Present situation and development prospect of hydropower construction in China[J]. Engineering and Technological Research, 2019, 4(5): 246, 254. [2] 夏敏, 任光明, 马鑫磊, 等. 库水位涨落条件下滑坡地下水渗流场动态特征[J]. 西南交通大学学报, 2014, 49(3): 399-405. doi: 10.3969/j.issn.0258-2724.2014.03.005Xia Min, Ren Guangming, Ma Xinlei, et al. Dynamic responses of groundwater seepage of landslide influenced by fluctuation of reservoir water level[J]. Journal of Southwest Jiaotong University, 2014, 49(3): 399-405. doi: 10.3969/j.issn.0258-2724.2014.03.005 [3] 石豫川, 冯文凯, 刘汉超, 等. 某水电站高边坡变形破坏模式及机制分析[J]. 西南交通大学学报, 2004, 39(5): 609-613. doi: 10.3969/j.issn.0258-2724.2004.05.012Shi Yuchuan, Feng Wenkai, Liu Hanchao, et al. Patterns and mechanisms of high slope deformation and failure of hydropower station in southwest China[J]. Journal of Southwest Jiaotong University, 2004, 39(5): 609-613. doi: 10.3969/j.issn.0258-2724.2004.05.012 [4] 黄润秋. 汶川8.0级地震触发崩滑灾害机制及其地质力学模式[J]. 岩石力学与工程学报, 2009, 28(6): 1239-1249. doi: 10.3321/j.issn:1000-6915.2009.06.021Huang Runqiu. Mechanism and geomechanical modes of landslide hazards triggered by Wenchuan 8.0 earthquake[J]. Chinese Journal of Rock Mechanics and Engineering, 2009, 28(6): 1239-1249. doi: 10.3321/j.issn:1000-6915.2009.06.021 [5] 殷跃平. 汶川八级地震地质灾害研究[J]. 工程地质学报, 2008, 16(4): 433-444. doi: 10.3969/j.issn.1004-9665.2008.04.001Yin Yueping. Researches on the geo-hazards triggered by Wenchuan earthquake, Sichuan[J]. Journal of Engineering Geology, 2008, 16(4): 433-444. doi: 10.3969/j.issn.1004-9665.2008.04.001 [6] 史培军, 杨文涛. 山区孕灾环境下地震和极端天气气候对地质灾害的影响[J]. 气候变化研究进展, 2020, 16(4): 405-414. doi: 10.12006/j.issn.1673-1719.2019.174Shi Peijun, Yang Wentao. Compound effects of earthquakes and extreme weathers on geo-hazards in mountains[J]. Climate Change Research, 2020, 16(4): 405-414. doi: 10.12006/j.issn.1673-1719.2019.174 [7] 朱淳, 龚逸非, 宋盛渊, 等. 滑坡多源监测技术及预警模型研究进展与展望[J/OL]. 西南交通大学学报, 2024: 1-19. (2024-09-29). https://kns.cnki.net/KCMS/detail/detail.aspx?filename=XNJT20240913001&dbname=CJFD&dbcode=CJFQ. [8] 唐红波, 王立纬, 蒋文鹏, 等. 库水位变化与地震作用下堆积体边坡动力稳定性研究[J]. 土工基础, 2024, 38(3): 496-502.Tang Hongbo, Wang Liwei, Jiang Wenpeng, et al. Study on dynamic stability of a colluvial slope under reservoir pooling water level varation and earthquake[J]. Soil Engineering and Foundation, 2024, 38(3): 496-502. [9] 李鹏飞, 余波, 吴述彧, 等. 库水位变动条件下某巨型堆积体失稳破坏机理及灾变过程研究[J]. 工程地质学报, 2025, 33(4): 1461-1472. doi: 10.13544/j.cnki.jeg.2022-0819Li Pengfei, Yu Bo, Wu Shuyu, et al. Research on instability failure mechanism and catastrophic process of a giant accumulation body under the condition of reservoir water level fluctuation[J]. Journal of Engineering Geology, 2025, 33(4): 1461-1472. doi: 10.13544/j.cnki.jeg.2022-0819 [10] 张强, 郑艳妮, 贾朝军, 等. 复杂水库调度及降雨条件下堆积体滑坡离心试验研究[J]. 岩石力学与工程学报, 2023, 42(10): 2427-2440. doi: 10.13722/j.cnki.jrme.2022.1223Zhang Qiang, Zheng Yanni, Jia Chaojun, et al. Centrifugal experimental study on accumulation body landslides under complex reservoir operation and rainfall conditions[J]. Chinese Journal of Rock Mechanics and Engineering, 2023, 42(10): 2427-2440. doi: 10.13722/j.cnki.jrme.2022.1223 [11] 卢书强, 易庆林, 易武, 等. 三峡库区树坪滑坡变形失稳机制分析[J]. 岩土力学, 2014, 35(4): 1123-1130, 1202. doi: 10.16285/j.rsm.2014.04.013Lu Shuqiang, Yi Qinglin, Yi Wu, et al. Analysis of deformation and failure mechanism of Shuping landslide in Three Gorges Reservoir area[J]. Rock and Soil Mechanics, 2014, 35(4): 1123-1130,1202. doi: 10.16285/j.rsm.2014.04.013 [12] 吴爽爽. 水位大变幅条件下呷爬滑坡变形演化特征与预测预警方法研究[D]. 武汉: 中国地质大学, 2022. [13] 周振凯. 金沙江白鹤滩水库蓄水初期岸坡变形破坏规律、机制与稳定性研究[D]. 北京: 中国地质大学(北京), 2023. [14] 郭宇, 卢波, 吴勇进, 等. 水动力作用下特大型堆积体滑坡变形的阶段性演进机制[J/OL]. 清华大学学报(自然科学版), 2025: 1-11. (2025-04-28). https://link.cnki.net/doi/10.16511/j.cnki.qhdxxb.2025.21.027. [15] 曾宇涵, 郑达, 吴章雷, 等. 高水位大涨幅条件下典型库岸堆积体复活机理研究[J/OL]. 人民长江, 2025: 1-13. (2025-04-15). https://kns.cnki.net/KCMS/detail/detail.aspx?filename=RIVE20250414002&dbname=CJFD&dbcode=CJFQ. [16] 陈龙, 李厚芝, 陈欢, 等. 新铺滑坡变形演化特征及成因机制分析[J/OL]. 工程地质学报, 2024: 1-15. (2024-07-02). https://link.cnki.net/doi/10.13544/j.cnki.jeg.2023-0248. [17] 徐湘涛, 汪家林, 黄润秋. 紫坪铺水利枢纽工程左岸坝前堆积体变形破坏机制研究[J]. 岩石力学与工程学报, 2008, 27(增刊 1): 2642-2650.Xu Xiangtao, Wang Jialin, Huang Runqiu. Research on deformation and failure mechanism of the talus slope located at left riverbank ahead of the dam of zipingpu hydraulic project[J]. Chinese Journal of Rock Mechanics and Engineering, 2008, 27(S1): 2642-2650. [18] Jia C J, Chen F L, Zhang Q, et al. Centrifuge modeling and numerical analysis of reservoir bank landslides triggered by a fast two-step drop in water level[J]. Bulletin of Engineering Geology and the Environment, 2023, 82(12): 465. doi: 10.1007/s10064-023-03490-z [19] 董金玉, 杨继红, 孙文怀, 等. 库水位升降作用下大型堆积体边坡变形破坏预测[J]. 岩土力学, 2011, 32(6): 1774-1780. doi: 10.3969/j.issn.1000-7598.2011.06.029Dong Jinyu, Yang Jihong, Sun Wenhuai, et al. Prediction of deformation and failure of a large-scale deposit slope during reservoir water level fluctuation[J]. Rock and Soil Mechanics, 2011, 32(6): 1774-1780. doi: 10.3969/j.issn.1000-7598.2011.06.029 [20] 唐学武, 王晨, 郭明珠, 等. 青藏高原东南三江流域黄土类堆积体斜坡地震作用下的动力响应试验研究: 以四川巴塘下归洼滑坡为例[J]. 地震工程学报, 2024, 46(3): 536-547. doi: 10.20000/j.1000-0844.20230127001Tang Xuewu, Wang Chen, Guo Mingzhu, et al. Experimental study on the dynamic response of accumulation slopes under earthquake action in Three-rivers Basin, southeast Tibetan Plateau: a case study of the Xiaguiwa landslide in Batang, Sichuan Province[J]. China Earthquake Engineering Journal, 2024, 46(3): 536-547. doi: 10.20000/j.1000-0844.20230127001 [21] 仝霄金, 唐建政, 付艳青, 等. 双向地震作用下崩塌堆积体边坡动力模糊可靠性分析[J]. 地震工程学报, 2024, 46(2): 343-348. doi: 10.20000/j.1000-0844.20220617003Tong Xiaojin, Tang Jianzheng, Fu Yanqing, et al. Dynamic fuzzy reliability analysis of collapse accumulation slopes under bidirectional earthquakes[J]. China Earthquake Engineering Journal, 2024, 46(2): 343-348. doi: 10.20000/j.1000-0844.20220617003 [22] Ma K, Zhang Y M, Wu H G, et al. Shaking table test study of accumulation layer landslide under earthquake action[J]. Arabian Journal of Geosciences, 2022, 15(2): 161. doi: 10.1007/s12517-021-08631-w [23] Chen J C, Wang L M, Wang P, et al. Failure mechanism investigation on loess–mudstone landslides based on the Hilbert–Huang transform method using a large-scale shaking table test[J]. Engineering Geology, 2022, 302: 106630. doi: 10.1016/j.enggeo.2022.106630 [24] Ning Y B, Zhang G C, Tang H M, et al. Process analysis of toppling failure on anti-dip rock slopes under seismic load in southwest China[J]. Rock Mechanics and Rock Engineering, 2019, 52(11): 4439-4455. doi: 10.1007/s00603-019-01855-z [25] Wu Z J, Zhang D, Wang S N, et al. Dynamic-response characteristics and deformation evolution of loess slopes under seismic loads[J]. Engineering Geology, 2020, 267: 105507. doi: 10.1016/j.enggeo.2020.105507 [26] 何梓雷, 蒋关鲁, 冯海洲, 等. 基于变形的降雨后地震基覆型边坡劣化特性与机制研究[J]. 岩土力学, 2024, 45(6): 1789-1802. doi: 10.16285/j.rsm.2023.0959He Zilei, Jiang Guanlu, Feng Haizhou, et al. Investigation of deterioration characteristics and mechanisms of bedrock and overburden layer slope under seismic conditions after rainfall based on deformation[J]. Rock and Soil Mechanics, 2024, 45(6): 1789-1802. doi: 10.16285/j.rsm.2023.0959 [27] 刘婧雯, 黄博, 邓辉, 等. 地震作用下堆积体边坡振动台模型试验及抛出现象分析[J]. 岩土工程学报, 2014, 36(2): 307-311.Liu Jingwen, Huang Bo, Deng Hui, et al. Shaking table tests and throwing phenomenon of deposit slopes under earthquakes[J]. Chinese Journal of Geotechnical Engineering, 2014, 36(2): 307-311. [28] Fan G, Zhang L M, Zhang J J, et al. Energy-based analysis of mechanisms of earthquake-induced landslide using Hilbert–Huang transform and marginal spectrum[J]. Rock Mechanics and Rock Engineering, 2017, 50(9): 2425-2441. doi: 10.1007/s00603-017-1245-8 [29] 杨兵, 孙明祥, 王润民, 等. 土体含水率对边坡动力破坏模式及动力响应影响的振动台试验研究[J]. 岩土工程学报, 2018, 40(4): 759-766, 725. doi: 10.11779/CJGE201804021Yang Bing, Sun Mingxiang, Wang Runmin, et al. Shaking table tests on influences of water content of soils on dynamic failure modes and dynamic responses of slopes[J]. Chinese Journal of Geotechnical Engineering, 2018, 40(4): 759-766,725. doi: 10.11779/CJGE201804021 [30] 杨长卫, 郭雪岩, 刘阳, 等. 基于振动台试验的含软弱夹层堆积体边坡动力响应规律与失稳破坏现象研究[J]. 工程科学与技术, 2021, 53(3): 43-52. doi: 10.15961/j.jsuese.202000935Yang Changwei, Guo Xueyan, Liu Yang, et al. Research on dynamic response and instability failure phenomenon of deposit slope with weak interlayer based on shaking table test[J]. Advanced Engineering Sciences, 2021, 53(3): 43-52. doi: 10.15961/j.jsuese.202000935 [31] 张祎, 李恒, 徐利军, 等. 地震作用下库区堆积层滑坡失稳机制[J]. 科学技术与工程, 2021, 21(5): 1982-1988.Zhang Yi, Li Heng, Xu Lijun, et al. Instability mechanism of accumulation layer landslide under earthquake action[J]. Science Technology and Engineering, 2021, 21(5): 1982-1988. [32] 董建辉. 地震作用下库岸堆积体斜坡动力响应及变形机理研究[D]. 成都: 成都理工大学, 2016. [33] Zhang L, Yang C W, Ma S J, et al. Seismic response time-frequency analysis of bedding rock slope[J]. Frontiers in Physics, 2020, 8: 558547. doi: 10.3389/fphy.2020.558547 [34] 杨长卫, 张良, 董陇军, 等. 基于振动台试验的顺层及反倾岩质斜坡地震动响应差异性研究[J]. 岩石力学与工程学报, 2022, 41(2): 271-281. doi: 10.13722/j.cnki.jrme.2021.0168Yang Changwei, Zhang Liang, Dong Longjun, et al. Research on the difference of dynamic responses between bedding and toppling rock slopes based on shaking table test[J]. Chinese Journal of Rock Mechanics and Engineering, 2022, 41(2): 271-281. doi: 10.13722/j.cnki.jrme.2021.0168 [35] Lei H, Qian J G, Wu H G. Dynamic response and failure mode of the twin tunnel-landslide using shaking table tests[J]. Acta Geotechnica, 2023, 18(8): 4329-4351. doi: 10.1007/s11440-023-01835-2 -
