Energy Storage-Based Co-Phase Power Supply System Considering Photovoltaic Integration and Its Cooperative Control Strategy
-
摘要:
为促进电气化铁路节能减排、绿色低碳化发展，首先提出光伏接入储能式同相供电系统的两种技术方案；接着，分析系统运行工况，并制定负序补偿原则；在此基础上，依据光伏发电出力和锂电池荷电状态（SOC），以实现负荷削峰填谷和能源高效利用为控制目标，构建双层协调控制策略，其中，上层负责能量管理与负序控制，下层则实时控制变流器运行；最后，通过案例分析，在综合考虑负荷所处牵引和再生工况下的负荷大小、光辐照度和锂电池充放电等多维因素的情况下，对弃光、充放电和负序补偿进行控制. 结果表明：该系统在不同工况下均表现出良好的适应性和稳定性，所提控制策略的正确性和有效性得到验证；光伏接入方案取消50%电分相，实现负序可控，促进多能融合与互补，推动光伏就地就近消纳，缓和牵引负荷的剧烈波动.
Abstract:To promote energy conservation and emission reduction, as well as green and low-carbon development of electrified railways, two technical schemes for a photovoltaic-integrated energy storage-based co-phase power supply system were first proposed. Then, the operating conditions of the system were analyzed, and the negative sequence compensation principle was formulated. On this basis, according to the photovoltaic power generation output and lithium battery state of charge (SOC), a two-layer cooperative control strategy was constructed with the control objectives of achieving load peak shaving and valley filling and efficient energy utilization. The upper layer was responsible for energy management and negative sequence control, while the lower layer controlled the converter operation in real time. Finally, through case analysis, the curtailment of photovoltaic generation, charging and discharging, and negative sequence compensation were controlled under comprehensive consideration of multi-dimensional factors, such as load magnitude under traction and regeneration conditions, solar irradiance, and lithium battery charging and discharging. The results indicate that the system exhibits good adaptability and stability under different operating conditions, and the correctness and effectiveness of the proposed control strategy are verified. The photovoltaic integration scheme eliminates 50% of electrical phase separations, realizes controllable negative sequence, promotes multi-energy integration and complementarity, facilitates local and nearby consumption of photovoltaics, and mitigates severe fluctuations of traction load.
-
图 1 光伏接入储能式同相供电系统方案
Figure 1. Scheme of photovoltaic-integrated energy storage-based co-phase power supply system
图 6 牵引工况同相供电系统电压电流
Figure 6. Voltage and current of co-phase power supply system under traction condition
图 7 牵引工况光伏发电波形
Figure 7. Waveform of photovoltaic power generation under traction condition
图 8 牵引工况锂电池充放电波形
Figure 8. Waveforms of lithium battery charging and discharging under traction condition
图 9 再生工况系统功率出力波形
Figure 9. Waveform of system power output under regeneration condition
表 1 系统运行工况
Table 1. System operating conditions
负荷
状态运行
方式负荷关系 功率流向 再生 M1 s<−$ {{S}}_{\mathrm{B}} $ 锂电充电 + 反馈电网 M2 −$ {{S}}_{\mathrm{B}} $≤s≤0 光伏发电 + 锂电充电 牵引 M3 0≤s<$ {{S}}_{\mathrm{G}} $ 光伏发电 + 锂电充电 M4 $ {{S}}_{\mathrm{G}} $≤s<$ {{S}}_{\mathrm{G}} $ + $ {{S}}_{\mathrm{B}} $ 光伏发电 + 锂电放电 M5 s≥$ {{S}}_{\mathrm{G}} $ + $ {{S}}_{\mathrm{B}} $
光伏发电 + 锂电放电 + 电网取电
下载: 导出CSV
表 2 变流器容量配置
Table 2. Converter capacity configuration
运行方式 直流侧接入变流器容量配置 交流侧接入变流器容量配置 ADC1 ADC2 ADC1 ADC2 ADC3 M1 $ {|s| + {s}_{\mathrm{B}}-{\mathrm{S}}_{{\text{ε}} }}/{2} $ $ {|s|-{s}_{\mathrm{B}}-{\mathrm{S}}_{{\text{ε}} }}/{2} $ $ {|s| + {s}_{\mathrm{B}}-{\mathrm{S}}_{{\text{ε}} }}/{2} $ $ {|s|-{s}_{\mathrm{B}}-{\mathrm{S}}_{{\text{ε}} }}/{2} $ 0 M2 |$ s| $ 0 $ {s}_{\mathrm{B}} $ 0 $ {s}_{\mathrm{G}} $ M3 $ s $ 0 $ {s}_{\mathrm{B}} $ 0 $ {s}_{\mathrm{G}} $ M4 $ s $ 0 $ s-{s}_{\mathrm{G}} $ 0 $ {s}_{\mathrm{G}} $ M5 $ {s + {s}_{\mathrm{G}} + {s}_{\mathrm{B}}-{\mathrm{S}}_{{\text{ε}} }}/{2} $ $ {s-{s}_{\mathrm{G}}-{s}_{\mathrm{B}}-{\mathrm{S}}_{{\text{ε}} }}/{2} $ $ {s-{s}_{\mathrm{G}} + {s}_{\mathrm{B}}-{\mathrm{S}}_{{\text{ε}} }}/{2} $ $ {s-{s}_{\mathrm{G}}-{s}_{\mathrm{B}}-{\mathrm{S}}_{{\text{ε}} }}/{2} $ $ {s}_{\mathrm{G}} $
下载: 导出CSV
表 3 上层控制功率分配
Table 3. Power allocation of upper layer control
工况 光伏 储能 M1 0 $ {s}_{\mathrm{B}}{f}_{\text{soc}} $ M2 min{$ {s}_{\mathrm{B}} $, |s| + $ {s}_{\mathrm{G}} $}−|s|$fSOC −min{$ {s}_{\mathrm{B}} $, |s| + $ {s}_{\mathrm{G}} $} $fsoc$ M3 s + min {$ {s}_{\mathrm{B}} $, $ {s}_{\mathrm{G}} $−s}$fSOC −min {$ {s}_{\mathrm{B}} $, $ {s}_{\mathrm{G}}-s $}$fsoc M4 $ {s}_{\mathrm{G}} $ $ ({s-s}_{\mathrm{G}}) {f}_{\text{soc}} $ M5 $ {s}_{\mathrm{G}} $ $ {s}_{\mathrm{G}} {f}_{\text{soc}} $
下载: 导出CSV
表 4 系统仿真参数
Table 4. System simulation parameters
名称 参数 MT1、MT2变比 10∶1 电感/mH 0.6 系统频率/Hz 50 直流侧电压/Udc/V 3000 直流侧电容/C/uF 8000 直流侧滤波电感/mH 0.42 直流侧滤波电容/uF 1500
下载: 导出CSV
表 5 光伏仿真参数
Table 5. Photovoltaic simulation parameters
名称 参数 PV 模块 SunPower SPR-315E-WHT-D 并联数目/个 224 串联数目/个 30 最大辐照度 /（W·m−2） 1000 最高温度/℃ 45
下载: 导出CSV
-
[1] 国家铁路局. 2023年铁道统计公报[R/OL]. (2024-06-28) [2025-03-09]. https://www.nra.gov.cn/xwzx/zlzx/hytj/202406/P020240628556175674080.pdf. [2] 高仕斌, 罗嘉明, 陈维荣, 等. 轨道交通“网-源-储-车”协同供能技术体系[J]. 西南交通大学学报, 2024, 59(5): 959-979, 989. doi: 10.3969/j.issn.0258-2724.20220210Gao Shibin, Luo Jiaming, Chen Weirong, et al. Rail transit “network-source-storage-vehicle” collaborative energy supply technology system[J]. Journal of Southwest Jiaotong University, 2024, 59(5): 959-979,989. doi: 10.3969/j.issn.0258-2724.20220210 [3] 张育维, 胡海涛, 耿安琪, 等. 考虑削峰填谷的电气化铁路混合储能系统容量优化配置[J]. 电力自动化设备, 2023, 43(2): 44-50. doi: 10.16081/j.epae.202207012Zhang Yuwei, Hu Haitao, Geng Anqi, et al. Capacity optimization configuration of hybrid energy storage system for electrified railway considering peak load shifting[J]. Electric Power Automation Equipment, 2023, 43(2): 44-50. doi: 10.16081/j.epae.202207012 [4] 黄小红, 赵艺, 李群湛, 等. 电气化铁路同相储能供电技术[J]. 西南交通大学学报, 2020, 55(4): 856-864. doi: 10.3969/j.issn.0258-2724.20181083Huang Xiaohong, Zhao Yi, Li Qunzhan, et al. Co-phase traction power supply and energy storage technology for electrified railway[J]. Journal of Southwest Jiaotong University, 2020, 55(4): 856-864. doi: 10.3969/j.issn.0258-2724.20181083 [5] 刘元立, 李群湛. 含光伏和混合储能的同相牵引供电系统日前优化调度[J]. 西南交通大学学报, 2023, 58(1): 30-39. doi: 10.3969/j.issn.0258-2724.20200534Liu Yuanli, Li Qunzhan. Day-ahead optimal scheduling of co-phase traction power supply system with photovoltaic and hybrid energy storage[J]. Journal of Southwest Jiaotong University, 2023, 58(1): 30-39. doi: 10.3969/j.issn.0258-2724.20200534 [6] 宋治东, 解绍锋, 彭友, 等. 含氢储装置的同相供电系统控制方法[J]. 机车电传动, 2024(3): 173-181.Song Zhidong, Xie Shaofeng, Peng You, et al. A control method for co-phase power supply system of hydrogen containing energy storage device[J]. Electric Drive for Locomotives, 2024(3): 173-181. [7] 张丽艳, 贾瑛, 韩笃硕, 等. 电气化铁路同相储能供电系统能量管理及容量配置策略[J]. 西南交通大学学报, 2023, 58(1): 22-29. doi: 10.3969/j.issn.0258-2724.20210247Zhang Liyan, Jia Ying, Han Dushuo, et al. Energy management and capacity allocation scheme for co-phase traction power supply and energy storage system in electrified railways[J]. Journal of Southwest Jiaotong University, 2023, 58(1): 22-29. doi: 10.3969/j.issn.0258-2724.20210247 [8] Chen M W, Cheng Z, Liu Y L, et al. Multitime-scale optimal dispatch of railway FTPSS based on model predictive control[J]. IEEE Transactions on Transportation Electrification, 2020, 6(2): 808-820. doi: 10.1109/TTE.2020.2992693 [9] 陈冲, 贾利民, 赵天宇, 等. 光伏和储能植入铁路牵引供电系统的拓扑架构与控制策略研究综述[J]. 电工技术学报, 2024, 39(24): 7874-7901. doi: 10.19595/j.cnki.1000-6753.tces.232167Chen Chong, Jia Limin, Zhao Tianyu, et al. Research review on topology and control strategy of PV and energy storage connected to railway traction power supply systems[J]. Transactions of China Electrotechnical Society, 2024, 39(24): 7874-7901. doi: 10.19595/j.cnki.1000-6753.tces.232167 [10] 邓文丽, 戴朝华, 张涵博, 等. 复杂电气化铁路牵引用光伏发电系统综合优化控制方法研究[J]. 中国电机工程学报, 2020, 40(18): 5849-5865.Deng Wenli, Dai Chaohua, Zhang Hanbo, et al. Research on comprehensive optimization control method for traction photovoltaic generation system of complex electrified railway[J]. Proceedings of the CSEE, 2020, 40(18): 5849-5865. [11] 杨健维, 冯素华, 郭惠斌, 等. 多变电所互联牵引供电系统光储容量优化配置[J]. 西南交通大学学报, 2025, 60(6): 1537-1549. doi: 10.3969/j.issn.0258-2724.20240028Yang Jianwei, Feng Suhua, Guo Huibin, et al. Optimal configuration of photovoltaic and hybrid energy storage system capacity in multi-substation interconnected traction power supply system[J]. Journal of Southwest Jiaotong University, 2025, 60(6): 1537-1549. doi: 10.3969/j.issn.0258-2724.20240028 [12] 李群湛. 电气化铁路贯通供电对电网的影响与解决方案[J]. 西南交通大学学报, 2025, 60(3): 533-540, 549. doi: 10.3969/j.issn.0258-2724.20240503Li Qunzhan. Impact of interconnected power supply for electrified railways on power grids and its solutions[J]. Journal of Southwest Jiaotong University, 2025, 60(3): 533-540,549. doi: 10.3969/j.issn.0258-2724.20240503 [13] 李群湛, 王辉, 黄文勋, 等. 电气化铁路牵引变电所群贯通供电系统及其关键技术[J]. 电工技术学报, 2021, 36(5): 1064-1074. doi: 10.19595/j.cnki.1000-6753.tces.191740Li Qunzhan, Wang Hui, Huang Wenxun, et al. Interconnected power supply system of traction substation group and its key technologies for the electrified railway[J]. Transactions of China Electrotechnical Society, 2021, 36(5): 1064-1074. doi: 10.19595/j.cnki.1000-6753.tces.191740 [14] Lian J R, Dai C H, Yao Z G, et al. A novel interphase-bridging single-phase inverter for photovoltaic and energy storage connected to railway traction power supply system[J]. IEEE Transactions on Transportation Electrification, 2025, 11(1): 570-581. doi: 10.1109/TTE.2024.3393510 [15] 陈民武, 陈垠宇, 徐烈, 等. 基于机会约束的贯通式同相牵引供电系统分布式优化运行策略[J]. 中国电机工程学报, 2024, 44(24): 9583-9594. doi: 10.13334/j.0258-8013.pcsee.231428Chen Minwu, Chen Yinyu, Xu Lie, et al. Distributed optimal operation of continuous co-phase traction power system via chance-constraint[J]. Proceedings of the CSEE, 2024, 44(24): 9583-9594. doi: 10.13334/j.0258-8013.pcsee.231428 [16] 李群湛. 牵引供电系统分析[M]. 4版. 成都: 西南交通大学出版社, 2024: 129-158, 183-203. [17] 王辉, 李群湛, 李晋, 等. 基于YNd变压器与静止无功发生器的电气化铁路同相供电综合补偿方案[J]. 电工技术学报, 2020, 35(17): 3739-3749. doi: 10.19595/j.cnki.1000-6753.tces.190957Wang Hui, Li Qunzhan, Li Jin, et al. Comprehensive compensation schemes of cophase power supply of electrified railway based on YNd transformer and static var generator[J]. Transactions of China Electrotechnical Society, 2020, 35(17): 3739-3749. doi: 10.19595/j.cnki.1000-6753.tces.190957 [18] 王翰林, 黄小红, 李昊洋, 等. 含分布式光伏接入的三相牵引供电系统电压协调控制方法[J]. 高电压技术, 2024, 50(4): 1645-1654. doi: 10.13336/j.1003-6520.hve.20221667Wang Hanlin, Huang Xiaohong, Li Haoyang, et al. Voltage coordination control method of three-phase traction power supply system with distributed photovoltaic integration[J]. High Voltage Engineering, 2024, 50(4): 1645-1654. doi: 10.13336/j.1003-6520.hve.20221667 [19] Ge Y B, Huang Y, Chen J Y, et al. Two-stage power flow management for flexible section posts of electric railways considering NSC and voltage control[J]. IEEE Transactions on Smart Grid, 2025, 16(2): 1261-1272. doi: 10.1109/TSG.2024.3458918 [20] 陈灵, 陈郑平, 李军良, 等. 基于深度卷积神经网络和合作博弈的多微网实时能量管理策略[J]. 电气工程学报, 2022, 17(2): 215-225. doi: 10.11985/2022.02.025Chen Ling, Chen Zhengping, Li Junliang, et al. Real-time energy management strategy for micro-grid clusters based on deep convolutional neural network and cooperative game[J]. Journal of Electrical Engineering, 2022, 17(2): 215-225. doi: 10.11985/2022.02.025 [21] 李俊豪, 涂春鸣, 王鑫, 等. 基于“规则 + 优化”的电气化铁路站点实时能量管控策略[J]. 电工技术学报, 2024, 39(11): 3339-3352.Li Junhao, Tu Chunming, Wang Xin, et al. Real-time energy management strategy for electrified railroad stations based on “rules + optimization”[J]. Transactions of China Electrotechnical Society, 2024, 39(11): 3339-3352. [22] Ying Y C, Tian Z B, Wu M L, et al. A real-time energy management strategy of flexible smart traction power supply system based on deep Q-learning[J]. IEEE Transactions on Intelligent Transportation Systems, 2024, 25(8): 8938-8948. doi: 10.1109/TITS.2024.3414446 [23] 李光耀, 袁佳歆, 甘栋良, 等. 高铁新能源混合储能系统低碳经济优化运行研究[J]. 电气工程学报, 2024, 19(1): 67-78. doi: 10.11985/2024.01.007Li Guangyao, Yuan Jiaxin, Gan Dongliang, et al. Research on low-carbon economy optimization operation of high-speed railway new energy hybrid energy storage system[J]. Journal of Electrical Engineering, 2024, 19(1): 67-78. doi: 10.11985/2024.01.007 [24] Aguado J A, Sánchez Racero A J, de la Torre S. Optimal operation of electric railways with renewable energy and electric storage systems[J]. IEEE Transactions on Smart Grid, 2018, 9(2): 993-1001. doi: 10.1109/TSG.2016.2574200 [25] GB/T 15543—2008 电能质量 三相电压不平衡[S] -
