UHPC预应力连接装配式桥墩抗震的设计方法

朱圣春; 崔冰; 宋颖彤; 王康康; 韩永安; 赵灿晖

doi:10.3969/j.issn.0258-2724.20250103

UHPC预应力连接装配式桥墩抗震的设计方法

doi: 10.3969/j.issn.0258-2724.20250103

朱圣春^1,,
崔冰²,
宋颖彤²,
王康康^{1, 2},
韩永安^{1, 2},
赵灿晖^{1, 3, ,}

1.
西南交通大学土木工程学院，四川成都 611756
2.
中交公路规划设计院有限公司，北京，100088
3.
西南交通大学抗震工程技术四川省重点实验室，四川成都 611756

基金项目: 国家自然科学基金项目（U21A20154）；四川省重点研发计划（2023YFS0429）

详细信息

作者简介:
朱圣春（1997—），男，博士研究生，研究方向为桥梁与隧道工程，E-mail：zhushengchun0505@163.com

通讯作者:
赵灿晖（1970—），男，教授，博士，研究方向为桥梁工程抗震，E-mail：zch2887@163.com

中图分类号: U442.55
计量
- 文章访问数: 7
- HTML全文浏览量: 4
- PDF下载量: 1
- 被引次数: 0
出版历程
- 收稿日期: 2025-03-13
- 录用日期: 2026-01-09
- 修回日期: 2025-05-29
- 网络出版日期: 2026-01-20

Seismic Design Method of Ultra-High Performance Concrete Prestressed Connection of Prefabricated Bridge Pier

ZHU Shengchun^1
,,
CUI Bing²,
SONG Yingtong²,
WANG Kangkang^{1, 2},
HAN Yongan^{1, 2},
ZHAO Canhui^{1, 3
, ,}

1.
School of Civil Engineering, Southwest Jiaotong University, Chengdu 611752, China
2.
CCCC Highway Consultants Co., Ltd. (HPD), Beijing 100088, China
3.
Key Laboratory of Seismic Engineering Technology of Sichuan Province, Southwest Jiaotong University, Chengdu 611752, China

摘要

摘要:
为提升装配式桥墩的工业化水平，研发与超高性能混凝土（UHPC）桥墩性能相匹配的连接形式，提出一种外置式预应力连接接头及其张拉工艺，并通过足尺试验验证该构造和工艺的可行性；结合有限元分析，研究接头预应力和轴压比对UHPC桥墩性能的影响，并基于能力设计法提出预应力接头的设计方法. 研究结果表明：采用外置式预应力连接接头的装配式桥墩发生了典型的弯曲破坏，桥墩墩身UHPC混凝土被压溃，但桥墩与承台接缝处未出现界面分离；预应力高强钢筋的应力变化和桥墩水平荷载基本呈正比，并且变化幅度最大仅为9%，表明试件采用的外置式预应力连接接头的连接性能可靠，结构整体性能好；当桥墩高强钢筋张拉力较小时，桥墩和承台接缝处会出现接缝开口，装配式桥墩的刚度将减小，但对试件的峰值承载能力基本没有影响.
- 装配式桥墩 /
- 外置式预应力连接接头 /
- 足尺模型 /
- 有限元分析 /
- 连接性能
Abstract:
To enhance the industrialization level of the prefabricated bridge pier and develop connection forms compatible with the performance of the ultra-high performance concrete (UHPC) pier, an external prestressed connection joint and its tensioning process were proposed. The feasibility of this configuration and technique was validated through full-scale tests. Combined with finite element analysis, the influence of joint prestress and axial compression ratio on the performance of the UHPC pier was investigated, and a design method for prestressed joints based on the capacity design method was proposed. The research results have shown that the prefabricated pier with the external prestressed connection joint experiences typical bending failure, with the UHPC concrete of the pier body being crushed, but no interfacial separation occurs at the interface between the pier and the cap. The stress variation of the prestressed high-strength reinforcement is basically proportional to the horizontal load of the pier, with the maximum variation amplitude of only 9%, indicating that the connection performance of the external prestressed connection joint used in the specimen has reliable connection performance and good overall structural performance. When the tension force of the high-strength reinforcement in the pier is small, joint opening occurs at the interface between the pier and the cap, reducing the stiffness of the prefabricated bridge pier, but it has little effect on the peak load-bearing capacity of the specimen.
- prefabricated bridge pier /
- external prestressed connection joint /
- full-scale model /
- finite element analysis /
- connection performance

HTML全文

图 1 外置式预应力连接接头构造

Figure 1. Structure of external prestressed connection joint

下载: 全尺寸图片幻灯片

图 2 UHPC桥墩构造图

Figure 2. Configuration of UHPC bridge pier

下载: 全尺寸图片幻灯片

图 3 试验加载装置

Figure 3. Experimental loading system

下载: 全尺寸图片幻灯片

图 4 加载系统

Figure 4. Loading system

下载: 全尺寸图片幻灯片

图 5 传感器布置

Figure 5. Sensor layout

下载: 全尺寸图片幻灯片

图 6 破坏模式

Figure 6. Mode of failure

下载: 全尺寸图片幻灯片

图 7 试件裂缝分布（单位：m）

Figure 7. Crack distribution of specimen (unit: m)

下载: 全尺寸图片幻灯片

图 8 滞回水平力-位移曲线

Figure 8. Hysteretic lateral force–displacement curves

下载: 全尺寸图片幻灯片

图 10 预应力高强钢筋应力大小随加载位移变化

Figure 10. Stress changes of prestressed high-strength reinforcement with loading displacement

下载: 全尺寸图片幻灯片

图 11 装配式桥墩有限元模型

Figure 11. Finite element model of prefabricated bridge pier

下载: 全尺寸图片幻灯片

图 9 骨架曲线

Figure 9. Skeleton curves

下载: 全尺寸图片幻灯片

图 12 预应力高强钢筋应力随水平荷载变化

Figure 12. Stress changes of prestressed high-strength reinforcement with horizontal load

下载: 全尺寸图片幻灯片

图 13 F-100MPa工况下桥墩损伤变形图

Figure 13. Damage deformation of bridge pier under F-100 condition

下载: 全尺寸图片幻灯片

图 14 不同预应力下的骨架曲线

Figure 14. Skeleton curves under different prestress

下载: 全尺寸图片幻灯片

图 15 不同轴压比下骨架曲线对比

Figure 15. Comparison of skeleton curves under different axial compression ratios

下载: 全尺寸图片幻灯片

图 16 界面不出现分离时界面应力状态

Figure 16. Interface stress state without separation

下载: 全尺寸图片幻灯片

图 17 界面出现分离时界面应力状态

Figure 17. Interface stress state with separation

下载: 全尺寸图片幻灯片

图 18 外置式预应力连接接头设计方法

Figure 18. Design method of external prestressed connection joint

下载: 全尺寸图片幻灯片

表 1 实验材料力学性能主要参数

Table 1. Main mechanical parameters of test materials

试件材料	力学指标	测试值
UHPC（墩身）	弹性模量/MPa	48000
UHPC（墩身）	立方体抗压强度/MPa	140
C50 （承台 + 加载头）	弹性模量/MPa	36500
C50 （承台 + 加载头）	立方体抗压强度/MPa	54
HRB400 （墩身钢筋）	弹性模量/MPa	206000
	屈服强度/MPa	480
	抗拉强度/MPa	540
预应力高强钢筋	弹性模量/MPa	206000
	屈服强度/MPa	1080
	抗拉强度/MPa	1230

下载: 导出CSV
