配置高强钢棒的混凝土框架结构抗震性能的试验研究

赵华; 袁维光; 魏丞瑾; 冷东航; 陈鹏

doi:10.3969/j.issn.0258-2724.20250036

配置高强钢棒的混凝土框架结构抗震性能的试验研究

doi: 10.3969/j.issn.0258-2724.20250036

赵华^1,,
袁维光^{1, 2, ,},
魏丞瑾^{1, 2},
冷东航³,
陈鹏⁴

1.
成都理工大学地质灾害防治与地质环境保护国家重点实验室，四川成都 610059
2.
成都理工大学环境与土木工程学院，四川成都 610059
3.
海南瑞泽双林建材有限公司，海南三亚 572011
4.
自贡高新区建设工程项目服务中心，四川自贡 643000

详细信息

作者简介:
赵华（1976—），女，副教授，博士，研究方向为混凝土结构抗震，E-mail：zhaohua@cdut.edu.cn

通讯作者:
袁维光（1986—），男，讲师，博士，研究方向为混凝土结构抗震研究，E-mail：yuanweiguang19@cdut.edu.cn

中图分类号: TU398.203
计量
- 文章访问数: 88
- HTML全文浏览量: 67
- PDF下载量: 15
- 被引次数: 0
出版历程
- 收稿日期: 2025-01-22
- 修回日期: 2025-04-23
- 网络出版日期: 2025-07-18

Experimental Study on Seismic Performance of Concrete Frame Structures Reinforced with High-Strength Steel Bars

ZHAO Hua^1
,,
YUAN Weiguang^{1, 2
, ,},
WEI Chengjin^{1, 2},
LENG Donghang³,
CHEN Peng⁴

1.
State Key Laboratory of Geohazard Prevention and Geoenvironment Protection, Chengdu University of Technology, Chengdu 610059, China
2.
College of Environment and Civil Engineering, Chengdu University of Technology, Chengdu 610059, China
3.
Hainan Ruize Shuanglin Building Materials Co., Ltd., Sanya 572011, China
4.
Zigong High-tech Zone Construction Project Service Center, Zigong 643000, China

摘要

摘要:
为实现钢筋混凝土框架结构震后损伤小、快速修复及恢复其使用功能的要求，设计3榀1/2缩尺的混凝土框架（1榀为普通钢筋混凝土框架，2榀为配置高强钢棒的混凝土框架）进行拟静力试验，研究混凝土框架结构在往复荷载作用下的破坏形态，探讨梁柱等构件配置高强钢棒后对框架结构的滞回曲线、骨架曲线、残余变形、可修复性等抗震性能指标和自复位能力的影响. 研究结果表明：框架梁柱中配置高强钢棒可有效提高框架结构的整体承载能力和变形能力, 与普通钢筋混凝土框架相比，试件NHGS2.5A15和试件HGHGS2.5A15表现出良好的位移硬化效应，其极限承载分别提高23%和57%，极限荷载对应的位移也分别提高50%和60%；其残余变形小，可修复率高，具有良好的自复位能力和可修复性.
- 高强钢棒 /
- 混凝土框架 /
- 残余变形 /
- 抗震性能 /
- 拟静力试验
Abstract:
To realize the requirements of minor post-earthquake damage, rapid repair, and functional recovery of reinforced concrete frame structures, three 1/2 scaled concrete frames were designed. One was an ordinary reinforced concrete frame, and two were concrete frames reinforced with high-strength steel bars (HG bars). Quasi-static tests were carried out to study the failure modes of the frames under cyclic loading. The effects of beams and columns with HG bars on seismic performance indexes including hysteretic curves, skeleton curves, residual deformation, repairability, and self-centering ability, were discussed. The results show that the use of HG bars in beams and columns effectively improves the overall bearing capacity and deformation capacity of the frame. Compared with the ordinary reinforced concrete frame, specimens NHGS2.5A15 and HGHGS2.5A15 show good displacement hardening effects. Their ultimate bearing capacities increase by 23% and 57%, respectively, and the displacement corresponding to ultimate load increases by 50% and 60%, respectively. These specimens have smaller residual deformations and higher reparability, and they demonstrate good self-centering capability and repairability performance.
- high-strength steel bar /
- concrete frame /
- residual deformation /
- seismic performance /
- quasi-static test

HTML全文

图 1 高强钢棒

Figure 1. HG bars

下载: 全尺寸图片幻灯片

图 2 试件的尺寸及配筋详图

Figure 2. Dimensions and reinforcement details of specimens

下载: 全尺寸图片幻灯片

图 3 位移计布置

Figure 3. Displacement gauge arrangement

下载: 全尺寸图片幻灯片

图 4 应变片布置

Figure 4. Strain gauge arrangement

下载: 全尺寸图片幻灯片

图 5 试件加载装置及加载制度

Figure 5. Loading setup and loading program of specimen

下载: 全尺寸图片幻灯片

图 6 各试件的破坏形态

Figure 6. Failure modes of specimens

下载: 全尺寸图片幻灯片

图 7 荷载-位移角滞回曲线

Figure 7. Load–displacement hysteretic curves

下载: 全尺寸图片幻灯片

图 8 骨架曲线

Figure 8. Skeleton curves

下载: 全尺寸图片幻灯片

图 9 各试件的刚度退化

Figure 9. Stiffness degradation of specimens

下载: 全尺寸图片幻灯片

图 10 各试件柱主筋应变

Figure 10. Main bar strain of columns in each specimen

下载: 全尺寸图片幻灯片

图 11 各试件梁主筋应变

Figure 11. Main bar strain of beams in each specimen

下载: 全尺寸图片幻灯片

图 12 各试件的等效黏滞阻尼系数

Figure 12. Equivalent viscous damping ratio of each specimen

下载: 全尺寸图片幻灯片

图 13 各试件的残余变形

Figure 13. Residual deformation of each specimen

下载: 全尺寸图片幻灯片

图 14 各试件的可修复概率

Figure 14. Repairable probability of each specimen

下载: 全尺寸图片幻灯片

图 15 各试件的可修复概率

Figure 15. Repairable probability of each specimen

下载: 全尺寸图片幻灯片

表 1 试件主要参数

Table 1. Main parameters of specimens

试件编号	柱配筋		梁配筋
试件编号	纵筋	箍筋	纵筋	箍筋
NNS2.5A15	8ϕ16 （2.6%）	ϕ8@80 （1.25%）	2ϕ16 （0.8%）	ϕ8@90/180 （1.12%）
NHGS2.5A15	14HG12.6 （2.8%）		2ϕ16 （0.8%）
HGHGS2.5A15	14HG12.6 （2.8%）		3HG12.6 （0.83%）
注：括号内的数字为配筋率.

下载: 导出CSV

表 2 高强钢棒和普通钢筋的力学性能

Table 2. Mechanical properties of HG bars and ordinary reinforcing bars

钢筋类型	直径/ mm	屈服强度/MPa	屈服应变/×10⁻⁶	极限抗拉强度 /MPa	断后伸长率 /%	弹性模量/MPa
HRB400e	8	446.5	2500	657.1	14.1	2.07 × 10⁵
HRB400e	16	422.3	2400	587.0	15.3	2.05 × 10⁵
高强钢棒	12.6	1343.3	7600	1434.8	3.8	1.97 × 10⁵

下载: 导出CSV

表 3 混凝土的力学性能

Table 3. Mechanical properties of concrete

混凝土强度等级	立方体抗压强度/MPa	轴心抗压强度/MPa	弹性模量/GPa
C40	39.44	26.38	32.4

下载: 导出CSV

表 4 各试件的极限荷载和极限位移

Table 4. Ultimate loads and displacement of specimens

试件编号	$ {V}_{\mathrm{e}\mathrm{x}\mathrm{p}}^{ + } $/kN	$ {R}_{\mathrm{e}\mathrm{x}\mathrm{p}}^{ + } $/%	$ {V}_{\mathrm{e}\mathrm{x}\mathrm{p}}^{-} $/kN	$ {R}_{\mathrm{e}\mathrm{x}\mathrm{p}}^{-} $/%	$ {V}_{\mathrm{e}\mathrm{x}\mathrm{p}} $/kN	$ {V}_{\mathrm{e}\mathrm{x}\mathrm{p}} $ 相对值	$ {R}_{\mathrm{e}\mathrm{x}\mathrm{p}} $/%	$ {R}_{\mathrm{e}\mathrm{x}\mathrm{p}} $ 相对值
NNS2.5A15	297.70	2.49	−270.60	−2.49	284.20	1.00	2.49	1.00
NHGS2.5A15	369.10	3.48	−333.60	−4.00	349.80	1.23	3.74	1.50
HGHGS2.5A15	469.20	3.99	−422.90	−3.98	446.00	1.57	3.99	1.60
注：$ {V}_{\mathrm{e}\mathrm{x}\mathrm{p}}^{ + } $（$ {V}_{\mathrm{e}\mathrm{x}\mathrm{p}}^{-} $）为推（拉）方向最大水平荷载， $ {R}_{\mathrm{e}\mathrm{x}\mathrm{p}}^{ + } $（$ {R}_{\mathrm{e}\mathrm{x}\mathrm{p}}^{-} $）为 $ {V}_{\mathrm{e}\mathrm{x}\mathrm{p}}^{ + } $（$ {V}_{\mathrm{e}\mathrm{x}\mathrm{p}}^{-} $）对应的位移角， $ {V}_{\mathrm{e}\mathrm{x}\mathrm{p}} $ 为 $ {V}_{\mathrm{e}\mathrm{x}\mathrm{p}}^{ + } $ 和 $ {V}_{\mathrm{e}\mathrm{x}\mathrm{p}}^{-} $的平均值.

下载: 导出CSV
