隧道掌子面强渗流裂隙对抗突体稳定性的影响

彭涛; 钱瑞; 袁飞云; 任东兴; 符文熹; 叶飞

doi:10.3969/j.issn.0258-2724.20240625

隧道掌子面强渗流裂隙对抗突体稳定性的影响

doi: 10.3969/j.issn.0258-2724.20240625

彭涛^{1, 2,},
钱瑞³,
袁飞云⁴,
任东兴²,
符文熹^3, ,,
叶飞³

1.
西南交通大学土木工程学院，四川成都 610031
2.
中冶成都勘察研究总院有限公司，四川成都 610023
3.
四川大学深地工程智能建造与健康运维全国重点实验室，四川成都 610065
4.
四川藏区高速公路有限责任公司，四川成都 610065

基金项目: 国家自然科学基金项目（42107172）；四川省重点研发计划（2020YFS0361，2024YFFK0112）

详细信息

作者简介:
彭涛（1981—），正高级工程师，研究方向为岩土体稳定、隧道灾害等，E-mail：zyckyx@163.com

通讯作者:
符文熹（1972—），教授，研究方向为岩土体稳定、地质灾害等，E-mail： wxf_lee@scu.edu.cn

中图分类号: U452
计量
- 文章访问数: 9
- HTML全文浏览量: 4
- PDF下载量: 1
- 被引次数: 0
出版历程
- 收稿日期: 2024-12-04
- 修回日期: 2025-02-12
- 网络出版日期: 2026-02-11

Influence of Strong Seepage Fractures on Stability of Water-Resistant Rock Mass at Tunnel Face

PENG Tao^{1, 2
,},
QIAN Rui³,
YUAN Feiyun⁴,
REN Dongxing²,
FU Wenxi^{3
, ,},
YE Fei³

1.
School of Civil Engineering, Southwest Jiaotong University, Chengdu 610031, China
2.
Chengdu Surveying Geotechnical Research Institute Co., Ltd., of MCC, Chengdu 610023, China
3.
State Key Laboratory of Intelligent Construction and Healthy Operation and Maintenance of Deep Underground Engineering, Sichuan University, Chengdu 610065, China
4.
Sichuan Tibetan Area Expressway Co., Ltd., Chengdu 610065, China

摘要

摘要:
涌水突泥是岩溶隧道常见的地质灾害之一，对隧道施工安全和长期运营构成严重威胁，确保掌子面抗突体的安全性是防控涌水突泥灾害的关键. 本文围绕强渗流作用下掌子面抗突体的稳定性问题，构建隧道掌子面强渗流裂隙抗突体的力学分析模型；充分考虑水流在贯通裂隙壁面上产生的拖曳力效应，系统推导强渗流作用下岩溶隧道抗突体的最小安全厚度公式；结合参数敏感性分析和工程实例，采用有限差分软件FLAC3D进一步分析掌子面前方含贯通裂隙和富水溶腔下隧道开挖围岩的稳定性，深入探讨关键参数对抗突体稳定性的影响机制. 研究结果表明：裂隙开度的增大显著增强了拖曳力的作用效果；强渗流条件下，裂隙拖曳力对抗突体最小安全厚度具有显著的不利影响，且其影响程度随着裂隙开度的增加非线性增强；在不同位置分布，裂隙对最小安全厚度的影响有显著差异，存在一个临界过渡点（悬臂梁Ⅰ、Ⅱ长度比= 5.07∶4.93），在该过渡点，裂隙上、下梁板发生同步破坏，进一步揭示了裂隙位置与结构失稳之间的内在关联. 研究成果可为岩溶隧道掌子面抗突体厚度设计、岩溶灾害治理（如注浆封堵、裂隙加固与渗流控制）以及施工期风险分级与监测预警指标选取提供理论依据与工程指导.
- 岩溶隧道 /
- 涌水突泥 /
- 强渗流裂隙 /
- 抗突体 /
- 拖曳力
Abstract:
Water and mud inrush is one of the common geological disasters in karst tunnels, which poses a severe threat to the safety of tunnel construction and long-term operation. Therefore, ensuring the safety of water-resistant rock mass at the face is the key to the prevention and control of water and mud inrush disasters. To ensure the stability of water-resistant rock mass at the face under the action of strong seepage, a mechanical analysis model of water-resistant rock mass in strong seepage fractures at the tunnel face was constructed. The drag force effect generated by the water flow on the wall of the penetrating fracture was fully considered, and the minimum safe thickness formula of the water-resistant rock mass in the karst tunnel under the action of strong seepage was systematically derived. Parameter sensitivity analysis and engineering examples were employed; the stability of the surrounding rock during tunnel excavation was further investigated by using the finite-difference software FLAC3D, considering penetrating fractures and water-rich karst cavities ahead of the tunnel face; the influence mechanism of key parameters on the stability of the water-resistant rock mass was discussed in depth. The results show that the increase of fracture opening significantly enhances the effect of the drag force. Under the condition of strong seepage, the fracture drag force has a significant adverse effect on the minimum safe thickness of the water-resistant rock mass, and its influence degree increases nonlinearly with the increase of fracture opening. In addition, the influence of fracture at different location distributions on the minimum safe thickness shows significant differences. It is found that there is a critical transition point (height ratio of cantilever beams I and II = 5.07∶4.93) at which the upper and lower beams and slabs of the fracture are destroyed synchronously, which further reveals the internal relationship between the fracture location and structural instability. The findings of this study can provide a theoretical basis and engineering guidance for designing the thickness of water-resistant rock mass in karst tunnel face, mitigating karst-related disasters (e.g., grouting sealing, fracture reinforcement, and seepage control), selecting monitoring and early-warning indicators, and conducting risk classification during construction.
- karst tunnel /
- water and mud inrush /
- strong seepage fracture /
- water-resistant rock mass /
- drag force

HTML全文

图 1 溶腔型隧道掌子面抗突体破坏示意

Figure 1. Destruction of water-resistant rock mass with karst cavity at tunnel face

下载: 全尺寸图片幻灯片

图 2 含贯通裂隙岩体的流速分布计算模型

Figure 2. Calculation model of flow velocity distribution in rock mass with penetrating fractures

下载: 全尺寸图片幻灯片

图 3 抗突体力学简化模型

Figure 3. Simplified mechanical model of water-resistant rock mass

下载: 全尺寸图片幻灯片

图 4 最小安全厚度随拖曳力作用效果的变化

Figure 4. Variation of minimum safe thickness with effect of drag force

下载: 全尺寸图片幻灯片

图 5 最小安全厚度随悬臂梁Ⅰ、Ⅱ长度比的变化

Figure 5. Variation of minimum safe thickness with length ratio of cantilever beams Ⅰ and Ⅱ

下载: 全尺寸图片幻灯片

图 6 香坪山隧道电阻率测试结果

Figure 6. Resistivity test results of Xiangpingshan Tunnel

下载: 全尺寸图片幻灯片

图 7 地表岩溶洼地、溶蚀现象

Figure 7. Surface karst depression and dissolution phenomenon

下载: 全尺寸图片幻灯片

图 8 岩溶隧道简化模型

Figure 8. Simplified model of karst tunnel

下载: 全尺寸图片幻灯片

图 9 数值模型及网格划分

Figure 9. Numerical model and mesh division

下载: 全尺寸图片幻灯片

图 10 y方向位移云

Figure 10. Y direction displacement cloud

下载: 全尺寸图片幻灯片

图 11 不同监测点的位移曲线

Figure 11. Displacement curves at different monitoring points

下载: 全尺寸图片幻灯片

表 1 参数敏感性分析的计算参数^{[18, 24-26]}

Table 1. Calculation parameters of parameter sensitivity analysis ^{[18, 24–26]}

参数分类	参数	取值范围	取值
隧道	h₁/m	2～10	5
	h₂/m	2～10	5
	h₁∶h₂	1∶4～4∶1	1∶1
富水溶腔	γ_w/kN∙m^–3	/	10
富水溶腔	h/m	35～135	50
围岩	围岩等级	/	Ⅲ
围岩	[σ_t]/MPa	1～15	5
裂隙	b/m	0～0.1	0.04
裂隙	∆p/MPa	0.1～2	1
安全系数	k	/	2

下载: 导出CSV

表 2 隧道围岩物理、力学性质参数取值

Table 2. Parameter values of physical and mechanical properties of surrounding rock in tunnel

岩样性质	密度/ （kg∙m⁻³）	弹性模量/ GPa	抗压强度/ MPa	抗拉强度/ MPa	泊松比	粘聚力/MPa	摩擦角/（°）	渗透系数/（m²/Pa-s）
围岩	2670	3.15	32.5	1.0	0.23	1.27	36.22	1.0 × 10⁻¹⁰

下载: 导出CSV

表 3 3种模拟突水过程的方案

Table 3. Three schemes for simulating water inrush process

模拟方案	裂隙	拖曳力	b/m	岩溶水压
模拟方案	裂隙	拖曳力	b/m	q_m1/MPa	q_m2/MPa
Ⅰ	不考虑	不考虑	/	0.8	0.85
Ⅱ	考虑	不考虑	0.5
III	考虑	考虑	0.5

下载: 导出CSV
