Analysis of Shear Strength Parameters of Waste SoilBased on Field and Laboratory Tests
-
摘要:
现阶段关于垃圾土抗剪强度参数的研究大多基于室内垃圾土试样开展，通过室内试验获得的参数往往与实际参数有较大差别，导致垃圾填埋场变形计算误差较大. 针对室内试验引起的误差问题，依托在建垃圾填埋场封场修复工程，通过开展垃圾土现场大型直剪试验和室内小尺寸直剪试验，与文献试验结果相比较，分析垃圾土抗剪强度参数的影响因素和变化规律. 结果表明：垃圾土抗剪能力高于传统土体，随着剪切位移增加，剪切应力持续上升并趋于稳定；垃圾土密度与抗剪强度呈线性正相关，当密度从 750 kg/m3 增至 950 kg/m3 时，黏聚力从 22.5 kPa 增至 34.5 kPa，摩擦角从 36.7°降至 30.2°；室内小尺寸剪切盒试验所得黏聚力均值（14.91 kPa）较现场大尺寸试验（21.18 kPa）低 6.27 kPa，而摩擦角均值（35.17°）较现场试验（28.56°）高 6.61°.
Abstract:At present, most of the studies on the shear strength parameters of waste soil are carried out based on laboratory waste soil samples, and the parameters obtained through laboratory tests are often quite different from the actual parameters, resulting in a large error in the calculation of waste landfill deformation. In view of the error problem caused by the laboratory test, by relying on the closure and restoration project of the waste landfill under construction, the influencing factors and change laws of the shear strength parameters of the waste soil were analyzed by carrying out the large-scale field direct shear test and the small-size laboratory direct shear test of the waste soil and making a comparison with the literature test results. The results show that the shear capability of waste soil is higher than that of traditional soil, and the shear stress continues to rise and tends to be stable with the increase of shear displacement. The density of waste soil is linearly and positively correlated with its shear strength. When the density increases from 750 kg/m3 to 950 kg/m3, the cohesion increases from 22.5 kPa to 34.5 kPa, and the friction angle decreases from 36.7° to 30.2°. The mean cohesion value (14.91 kPa) obtained by the small-size laboratory shear box test is 6.27 kPa lower than that of the large-size field test (21.18 kPa), and the mean friction angle (35.17°) is 6.61° higher than that of the field test (28.56°).
-
Key words:
- waste landfill /
- shear strength /
- field test /
- laboratory test /
- soil parameter
-
图 8 不同室内直剪试验剪切位移-剪应力关系曲线
Figure 8. Shear displacement–shear stress relationship curves of different laboratory direct shear tests
图 10 不同尺寸下抗剪强度参数分布图
Figure 10. Distribution of shear strength parameters at different sizes
表 1 现场直剪试验结果
Table 1. Field direct shear test results
编号 竖向压力/kPa 密度/
（kg·m−3）黏聚力/
kPa摩擦角/
（°）100 200 300 X1 52.33 70.15 87.82 955.68 34.1 10.1 X2 52.55 70.06 87.66 951.70 35.0 10.0 X3 52.23 69.90 87.74 946.13 34.5 10.5 X4 57.12 76.51 97.31 964.44 36.8 11.4
下载: 导出CSV
表 2 生活垃圾土分拣试验结果
Table 2. Results of domestic waste soil sorting test
序号 塑料/
g布料/
g植物和
厨余/g橡胶和
玻璃/g其他/
g干重量/
g湿重量/
g1 130.3 39.8 90.1 23.9 238 522.1 1059.2 2 100.8 25.6 72 10.4 340.1 548.9 1023.9 3 95.9 2.5 89.1 63.2 438.6 689.3 1131.2 4 66.9 95.5 65.9 63 339.9 631.2 1001.6 5 88.8 30.6 89.8 85.2 384.8 679.2 1056.8 合计 482.7 194 406.9 245.7 1741.4 3070.7 5272.7
下载: 导出CSV
表 3 各地区填埋场城市生活垃圾含水率
Table 3. Moisture contents of municipal solid waste in landfills of each region
序号 来源 填埋场地点 时间 含水率（%） 1 文献[15] 北京市部分城区生活垃圾处理站 2018年 46.85～52.36 2 文献[16] 广东省始兴、仁化和江门地区垃圾收集点 2013年 24.03～56.87 3 文献[17] 广东省海岛垃圾填埋场 2019年 48.26～60.22 4 文献[18] 上海市老港四期填埋场 2015年 52.60～71.20 5 文献[19] 上海市全市各垃圾处理站 2016年 54.27～64.59 6 文献[20] 杭州市典型地段垃圾中转站 2005年 48.80～65.10 7 文献[21] 大辛和老虎冲填埋场 2013年 46.54～74.90 8 文献[22] 湖北省铁门岗乡等生活垃圾处理站 2018年 30.01～72.60 9 文献[23] 天津滨海新区 2010年 52.04～56.59 10 文献[24] 四川省典型城市生活垃圾 2012年 55.83～59.41 11 文献[25] 芦家沟、寺儿沟等填埋场 2012年 29.20～55.64 12 文献[26] 湖南省重点典型城市垃圾处理站 2020年 36.25～47.75 13 文献[27] 西藏西藏乡村生活垃圾处理站 2020年 30.00～60.00 14 文献[28] 沈阳市大辛垃圾填埋场 2021年 57.88～63.11
下载: 导出CSV
表 4 密度对黏聚力的方差分析
Table 4. Variance analysis of effect of density on cohesion
变异来源 平方和 自由度 均方 F值 P值 显著 密度 182.56 4 45.64 28.32 <0.001 显著 误差 56.89 15 3.79 − − − 总和 239.45 19 − − − −
下载: 导出CSV
表 5 剪切强度参数的文献列表
Table 5. List of literature on shear strength parameters
来源 试样尺寸 填埋场地点 时间 黏聚力/kPa 摩擦角/（°） 文献[30] d=130 mm，h=76 mm 洛杉矶市垃圾填埋场 1990年 0 39.0～53.0 文献[31] d=63.5 mm − 1995年 0～28 20.0～39.0 文献[6] d=100 mm，h=200 mm − 2009年 0～33 14.0～39.0 文献[32] d=61.8 mm，h=20 mm 深圳某填埋场 2010年 4.5 30.6 文献[33] d=63 mm，h=34 mm − 2011年 16～40 28 文献[34] d=63.5 mm，h=40 mm 美国Tri−Cities填埋场 2011年 9 45.5 文献[35] d=61.8 mm，h=20 mm − 2012年 3.7 28.9 文献[36] d=180 mm，h=150 mm − 2015年 6.1～34.2 4.1～30.6 文献[37] d=434 mm，h=287 mm 加拿大填埋场 1986年 16～19 38.0～42.0 文献[38] d=1.5 m；l=1.5 m，h=1.5 m 纽约市垃圾填埋场 1995年 10 30 文献[39] d=250 mm，h=650 mm − 1995年 26 15 文献[40] d=200 mm，h=450 mm − 2003年 13 31 文献[41] d=618 mm，h=400 mm − 2015年 9.7～15.6 18.7～35.5 贺建清等[42] d=500 mm，l=500 mm，h=200 mm 湘潭市双马垃圾填埋场 2018 41.9 26.5
下载: 导出CSV
-
[1] 李修磊, 施建勇, 李玉萍. 三轴试验条件下城市生活垃圾土的变形强度特性[J]. 应用基础与工程科学学报, 2022, 30(6): 1428-1440.LI Xiulei, SHI Jianyong, LI Yuping. Investigation of the deformation and strength properties of municipal solid waste using triaxial tests[J]. Journal of Basic Science and Engineering, 2022, 30(6): 1428-1440. [2] 李丽华, 李孜健, 肖衡林, 等. 土工格栅加筋建筑垃圾土循环剪切试验[J]. 吉林大学学报(工学版), 2024, 54(6): 1612-1623. doi: 10.13229/j.cnki.jdxbgxb.20220930LI Lihua, LI Zijian, XIAO Henglin, et al. Experiment on cyclic shear of geosynthetic reinforced construction waste soil[J]. Journal of Jilin University (Engineering and Technology Edition), 2024, 54(6): 1612-1623. doi: 10.13229/j.cnki.jdxbgxb.20220930 [3] 高睿, 石知政, 刘洋泽鹏, 等. 土工格栅对受污道砟直剪特性影响的试验研究[J]. 西南交通大学学报, 2021, 56(6): 1185-1191.GAO Rui, SHI Zhizheng, LIU Yangzepeng, et al. Experimental study on effect of geogrid on direct shear behavior of contaminated ballast[J]. Journal of Southwest Jiaotong University, 2021, 56(6): 1185-1191. [4] 王伟, 金鹏, 张芳. 短龄期城市固体垃圾直剪试验及应力位移模型[J]. 岩土力学, 2011, 32(增1): 166-170.WANG Wei, JIN Peng, ZHANG Fang. Direct shear test of short-fill-age municipal solid wastes and its shear stress-deformation model[J]. Rock and Soil Mechanics, 2011, 32(S 1): 166-170. [5] 孙秀丽, 孔宪京, 邹德高, 等. 城市固体垃圾应力-应变-时间关系试验研究[J]. 岩土力学, 2011, 32(8): 2331-2335, 2364.SUN Xiuli, KONG Xianjing, ZOU Degao, et al. Stress-strain-time relationship for municipal solid waste[J]. Rock and Soil Mechanics, 2011, 32(8): 2331-2335,2364. [6] 陈云敏, 林伟岸, 詹良通, 等. 城市生活垃圾抗剪强度与填埋龄期关系的试验研究[J]. 土木工程学报, 2009, 42(3): 111-117.CHEN Yunmin, LIN Weian, ZHAN Liangtong, et al. A study on the relationship between the shear strength of municipal solid waste and the fill age[J]. China Civil Engineering Journal, 2009, 42(3): 111-117. [7] BRAY J D, ZEKKOS D, KAVAZANJIAN E Jr, et al. Shear strength of municipal solid waste[J]. Journal of Geotechnical and Geoenvironmental Engineering, 2009, 135(6): 709-722. doi: 10.1061/(ASCE)GT.1943-5606.0000063 [8] GIRALDO E, CAICEDO B, YAMIN L, et al. The landslide of Dona Juana landfill in Bogota. A case study[C]//Proceedings of the Fourth International Congress on Environmental Geotechnics (4th ICEG). Lisse: A A Balkema, 2002: 171-175. [9] LANDVA A, KNOWLES G D. Geotechnics of waste fills: theory and practice[M]. Philadelphia: ASTM International, 1990: 1-375. [10] 张坤勇, 苏政凯, 聂美军, 等. 基于ISSA-ELM的土体参数反演与变形预测方法[J]. 应用基础与工程科学学报, 2024, 32(5): 1434-1448.ZHANG Kunyong, SU Zhengkai, NIE Meijun, et al. Soil parameter inversion and deformation prediction method based on ISSA-ELM[J]. Journal of Basic Science and Engineering, 2024, 32(5): 1434-1448. [11] 周小文, 蒋浩然, 周密, 等. 垂直扩容垃圾挡坝稳定性离心机试验与数值仿真[J]. 哈尔滨工业大学学报, 2020, 52(11): 157-166.ZHOU Xiaowen, JIANG Haoran, ZHOU Mi, et al. Centrifuge test and numerical simulation on stability of vertically extended earth dam in landfill project[J]. Journal of Harbin Institute of Technology, 2020, 52(11): 157-166. [12] 中华人民共和国国家质量监督检验检疫总局;中国国家标准化管理委员会. 《岩土工程仪器基本参数及通用技术条件》: GB/T 15406—2007. 北京: 中国标准出版社, 2007. [13] 中华人民共和国住房和城乡建设部. 生活垃圾土土工试验技术规程: CJJ/T 204—2013. 北京: 中国建筑工业出版社, 2013. [14] Wong A, Shi X. Inference for the normal coefficient of variation: an approximate marginal likelihood approach[J]. Statistical Papers, 2024, 66(1): 12. doi: 10.1007/s00362-024-01622-5 [15] 张旭. 北京市生活垃圾热值测定及计算模型评价 [C]//《环境工程》2018 年全国学术年会论文集. 北京: [s. n.], 2018: 574-579. [16] 段雄伟, 高海硕, 黎华寿, 等. 广东省农村生活垃圾组分及其污染特性分析[J]. 农业环境科学学报, 2013, 32(7): 1486-1492.DUAN Xiongwei, GAO Haishuo, LI Huashou, et al. Component analysis and pollution characteristics of domestic waste in rural area of Guangdong Province, China[J]. Journal of Agro-Environment Science, 2013, 32(7): 1486-1492. [17] 董瑞程, 丁志斌, 郭浩男, 等. 广东省海岛生活垃圾产量及理化特性[J]. 科学技术与工程, 2019, 19(18): 369-374. doi: 10.3969/j.issn.1671-1815.2019.18.056DONG Ruicheng, DING Zhibin, GUO Haonan, et al. Output and physico-chemical properties of island living solid waste in Guangdong[J]. Science Technology and Engineering, 2019, 19(18): 369-374. doi: 10.3969/j.issn.1671-1815.2019.18.056 [18] 王克虹, 叶剑, 兰吉武, 等. 城市垃圾田间持水量的试验研究[J]. 环境卫生工程, 2015, 23(1): 31-35.WANG Kehong, YE Jian, LAN Jiwu, et al. Experimental study on field capacity of municipal solid waste[J]. Environmental Sanitation Engineering, 2015, 23(1): 31-35. [19] 董晓丹, 张玉林. 上海市生活垃圾理化特性调查分析[J]. 环境卫生工程, 2016, 24(6): 18-21.DONG Xiaodan, ZHANG Yulin. Investigation and analysis of physicochemical characteristics of municipal solid waste in Shanghai[J]. Environmental Sanitation Engineering, 2016, 24(6): 18-21. [20] 倪娜, 洪国才. 杭州市城市生活垃圾物理化学特性及处置对策[J]. 环境卫生工程, 2005, 13(5): 31-32, 36. doi: 10.3969/j.issn.1005-8206.2005.05.011NI Na, HONG Guocai. Physicochemical properties and treatment countermeasure of domestic waste in Hangzhou City[J]. Environmental Sanitation Engineering, 2005, 13(5): 31-32,36. doi: 10.3969/j.issn.1005-8206.2005.05.011 [21] 周晓强, 徐杰, 李彦龙, 等. 沈阳市生活垃圾能源化利用方式研究 [C]//能源高效清洁利用及新能源技术 ——2012 动力工程青年学术论坛暨第五届青年学术年会论文集. 北京: 中国电力出版社, 2013: 166-170. [22] 於俊颖, 岳波, 赵丹, 等. 华中地区典型农业型村镇生活垃圾的理化特性及季节变化分析[J]. 环境工程, 2018, 36(3): 127-132.YU Junying, YUE Bo, ZHAO Dan, et al. Physic-chemical properties and seasonal variation of rural living solid waste in typical agricultrual villages and towns in Central China[J]. Environmental Engineering, 2018, 36(3): 127-132. [23] 何俊宝, 姚庆军, 韩志梅, 等. 天津滨海新区(海河以南)生活垃圾调查及分析[J]. 环境卫生工程, 2010, 18(2): 7-10.HE Junbao, YAO Qingjun, HAN Zhimei, et al. Investigation and analysis of domestic waste within the south area of Haihe River in Tianjin Binhai new area[J]. Environmental Sanitation Engineering, 2010, 18(2): 7-10. [24] 黄明星, 刘丹. 四川省城市生活垃圾的组成及特性[J]. 中国环境监测, 2012, 28(5): 121-123.HUANG Mingxing, LIU Dan. Characteristic and composition of municipal solid waste in Sichuan Province[J]. Environmental Monitoring in China, 2012, 28(5): 121-123. [25] 苟剑锋, 曾正中, 姬爱民, 等. 兰州市生活垃圾物理成分及含水特性分析[J]. 环境工程, 2012, 30(6): 101-105.GOU Jianfeng, ZENG Zhengzhong, JI Aimin, et al. Physical composition and moisture characteristics of municipal solid waste of Lanzhou city[J]. Environmental Engineering, 2012, 30(6): 101-105. [26] 王壮丽, 周颖. 生活垃圾组成、理化特性对焚烧发电的意义[J]. 清洗世界, 2020, 36(8): 51-53.WANG Zhuangli, ZHOU Ying. Significance of composition and physical and chemical characteristics of domestic waste to incineration power generation[J]. Cleaning World, 2020, 36(8): 51-53. [27] 穷达卓玛. 西藏乡村生活垃圾热解试验研究[D]. 拉萨: 西藏大学, 2020. [28] 刘乙锐. 沈阳市垃圾场陈腐垃圾理化性质研究[J]. 清洗世界, 2021, 37(4): 70-73.LIU Yirui. Study on physical and chemical properties of stale garbage in Shenyang garbage dump[J]. Cleaning World, 2021, 37(4): 70-73. [29] 涂帆, 钱学德. 中美垃圾填埋场垃圾土的重度、含水量和相对密度[J]. 岩石力学与工程学报, 2008, 27(增1): 3075-3081.Tu Fan, Qian Xuede. Severity, water content and relative density of landfill soil in China and the United States[J]. Journal of Rock Mechanics and Engineering, 2008, 27(S1): 3075-3081. [30] SIEGEL R A, ROBERTSON R J, ANDERSON D G. Slope stability investigations at a landfill in southern California[M]//LANDVA A O, KNOWLES G D. Geotechnics of waste fills: theory and practice. West Conshohocken: ASTM International, 1990: 259-284. [31] GABR M A, VALERO S N. Geotechnical properties of municipal solid waste[J]. Geotechnical Testing Journal, 1995, 18(2): 241-251. [32] 施建勇, 朱俊高, 刘荣, 等. 垃圾土强度特性试验与双线强度包线研究[J]. 岩土工程学报, 2010, 32(10): 1499-1504.SHI Jianyong, ZHU Jungao, LIU Rong, et al. Tests on shear strength behavior and envelop of double lines of municipal solid waste[J]. Chinese Journal of Geotechnical Engineering, 2010, 32(10): 1499-1504. [33] REDDY K R, HETTIARACHCHI H, GANGATHULASI J, et al. Geotechnical properties of municipal solid waste at different phases of biodegradation[J]. Waste Management, 2011, 31(11): 2275-2286. [34] 原鹏博. 城市固体废弃物大型单剪试验研究[D]. 兰州: 兰州大学, 2011. [35] 朱兵见, 邱战洪, 何冬冬. 城市生活垃圾的力学性能测试与分析[J]. 济南大学学报(自然科学版), 2012, 26(4): 403-406.ZHU Bingjian, QIU Zhanhong, HE Dongdong. Analysis and measurement on mechanical properties of municipal solid waste[J]. Journal of University of Jinan (Science and Technology), 2012, 26(4): 403-406. [36] 张振营, 郭文强, 张宇翔, 等. MBT垃圾的三轴试验结果[J]. 岩土工程学报, 2019, 41(7): 1345-1353.ZHANG Zhenying, GUO Wenqiang, ZHANG Yuxiang, et al. Shear strength behavior of mechanically-biologically treated waste in triaxial tests[J]. Chinese Journal of Geotechnical Engineering, 2019, 41(7): 1345-1353. [37] Landva A, Clark J. Geotechnical testing of waste fill[C]//Proceedings of the 39th Canadian Geotechnical Conference. Ottawa, Ontario: Canadian Geotechnical Society, 1986: 86-103. [38] Withiam J L, Tarvin P A, Bushell T D, et al. Prediction and performance of municipal landfill slope[C]//Proceedings of Geoenvironment 2000: Characterization, Containment, Remediation, and Performance in Environmental Geotechnics. Orlando: ASCE (American Society of Civil Engineers), 1995: 1005-1019. [39] Grisolia M, Napoleoni Q, Tangredi G. The use of triaxial tests for the mechanical characterization of municipal solid waste[C]//Proceedings of the 5th International Landfill Symposium. Cagliari: National Research Council of Italy, 1995: 761-767. [40] 张季如, 陈超敏. 城市生活垃圾抗剪强度参数的测试与分析[J]. 岩石力学与工程学报, 2003, 22(1): 110-114.ZHANG Jiru, CHEN Chaomin. Measurement and analysis on shear strength parameters of municipal solid waste[J]. Chinese Journal of Rock Mechanics and Engineering, 2003, 22(1): 110-114. [41] 占秀娣, 严立俊, 吴大志, 等. 人工配制生活垃圾强度特性的超大型直接剪切试验[J]. 工程地质学报, 2015, 23(5): 930-936.ZHAN Xiudi, YAN Lijun, WU Dazhi, et al. Ultra-large direct shear test for shear strength properties of artificial municipal solid waste[J]. Journal of Engineering Geology, 2015, 23(5): 930-936. [42] 贺建清, 胡伟, 廖湘华, 等. 城市生活垃圾土的大型水平剪切试验研究[J]. 铁道科学与工程学报, 2018, 15(12): 3113-3119.HE Jianqing, HU Wei, LIAO Xianghua, et al. Experimental study on large scale horizontal push-shear test of municipal solid waste[J]. Journal of Railway Science and Engineering, 2018, 15(12): 3113-3119. [43] 邱忠平. 生物强化技术加速填埋场稳定化进程实验研究[J]. 西南交通大学学报, 2012, 47(3): 533-537.QIU Zhongping. Exprimental study on acceleration of landfill stabilization process using bioaugmentation technology[J]. Journal of Southwest Jiaotong University, 2012, 47(3): 533-537. -
