干湿−冻融-盐侵作用下再生混凝土的寿命预测及敏感性分析

王晨霞; 张炜泽; 曹芙波; 韩慧超; 苏天; 肖胜先; 秦士杰

doi:10.3969/j.issn.0258-2724.20240403

干湿−冻融-盐侵作用下再生混凝土的寿命预测及敏感性分析

doi: 10.3969/j.issn.0258-2724.20240403

王晨霞^{1, 2,},
张炜泽¹,
曹芙波^{1, 2, ,},
韩慧超³,
苏天⁴,
肖胜先¹,
秦士杰⁵

1.
内蒙古科技大学土木工程学院，内蒙古包头 014010
2.
内蒙古科技大学内蒙古自治区建筑结构防灾减灾工程技术研究中心，内蒙古包头 014010
3.
中国二冶集团有限公司，内蒙古包头 014060
4.
山东理工大学建筑工程与空间信息学院，山东淄博 255000
5.
河海大学河海里尔学院，江苏南京 211100

基金项目: 国家自然科学基金项目（51868061，52368024）；内蒙古自治区自然科学基金项目（2022LHMS05011，2024MS05028）

详细信息

作者简介:
王晨霞（1977—），女，教授，研究方向为固体废弃物资源化及其耐久性，E-mail：wangchenxia77@139.com

通讯作者:
曹芙波（1976—），男，教授，研究方向为固废资源化和钢与混凝土组合结构，E-mail：caofubo@139.com

中图分类号: TU398.1
计量
- 文章访问数: 52
- HTML全文浏览量: 36
- PDF下载量: 9
- 被引次数: 0
出版历程
- 收稿日期: 2024-08-27
- 录用日期: 2026-03-02
- 修回日期: 2025-04-20
- 网络出版日期: 2026-03-16

Life Prediction and Sensitivity Analysis of Recycled Concrete Under Dry, Wet, Freeze-Thaw, and Salt Intrusion

WANG Chenxia^{1, 2
,},
ZHANG Weize¹,
CAO Fubo^{1, 2
, ,},
HAN Huichao³,
SU Tian⁴,
XIAO Shengxian¹,
QIN Shijie⁵

1.
School of Civil Engineering, Inner Mongolia University of Science & Technology, Baotou 014010, China
2.
Inner Mongolia Autonomous Region Building Structure Disaster Prevention and Mitigation Engineering Technology Research Center, Baotou 014010, China
3.
China Second Metallurgy Group Co., Ltd., Baotou 014060, China
4.
School of Civil Engineering and Geomatics, Shandong University of Technology, Zibo 255000, China
5.
Hohai-Lille College, Hohai University, Nanjing 211100, China

摘要

摘要:
针对河套灌溉盐渍土地区再生混凝土结构耐久性不足问题，模拟该地区典型地貌环境，将混凝土试件置于干湿−冻融环境中以探究硫酸钠侵蚀规律与机理. 以混凝土类型、水灰比及硫酸钠溶液浓度为试验变量，选取质量评价参数ƞ_a、动弹性模量评价参数ƞ_b作为关键评价参数，建立综合损伤评价指标，并基于此进行两参数Weibull可靠性分析，同时，采用灰色关联度对各影响因素进行敏感性分析. 结果表明：普通混凝土的抗侵蚀性能优于再生混凝土，在第四次循环结束后，普通混凝土的ƞ_b值为再生混凝土的4倍；适当降低水灰比可提高再生混凝土抗侵蚀性能；在复合因素影响下，再生混凝土损伤由硫酸钠结晶膨胀作用与化学腐蚀作用共同累积导致，硫酸钠浓度越高，损伤发展越快，在3次循环结束后，RC-0.46-0%组ƞ_b值仍有0.051，而RC-0.46-10%组ƞ_b值为−0.066，试件已发生破坏；Weibull分布函数能有效描述再生混凝土的侵蚀损伤过程，通过建立加速寿命可靠度函数可直观预测试件的服役寿命，且预测结果与试验结果较一致；根据灰色关联度分析结果，在4次循环结束后，水灰比为0.53试件的ƞ_a值分别比水灰比为0.46和0.39的试件降低了0.36和0.65，而后两组试件的ƞ_b值基本一致，因此，水灰比是影响再生混凝土耐久性的主要因素.
- 再生混凝土 /
- 干湿−冻融 /
- 硫酸钠侵蚀 /
- Weibull分布 /
- 敏感性分析
Abstract:
To address the insufficient durability of recycled concrete structures in the Hetao irrigated saline soil region, a typical geomorphological environment in the area was simulated, and concrete specimens were placed in a dry, wet, and freeze-thaw environment to investigate the erosion regularity and mechanism of sodium sulfate. Concrete type, water-cement ratio, and sodium sulfate solution concentration were employed as experimental variables. The quality evaluation parameter ƞ_a and the dynamic elastic modulus evaluation parameter ƞ_b were selected as key evaluation parameters to establish a comprehensive damage evaluation index. Based on this, a two-parameter Weibull reliability analysis was conducted, and a sensitivity analysis of each influencing factor was performed using grey relational grade. The results show that ordinary concrete exhibits better erosion resistance than recycled concrete; after the fourth cycle, the ƞ_b value of ordinary concrete is four times that of recycled concrete. Furthermore, appropriately reducing the water-cement ratio can improve the erosion resistance of recycled concrete. Under the influence of multiple factors, the damage to recycled concrete is caused by the cumulative effects of sodium sulfate crystallization expansion and chemical corrosion. The sodium sulfate with a higher concentration leads to faster damage development. After three cycles, the ƞ_b value of the RC-0.46-0% group is still 0.051, while the ƞ_b value of the RC-0.46-10% group is −0.066, indicating that the specimen has already been destroyed. The Weibull distribution function can effectively describe the erosion damage process of recycled concrete. By establishing an accelerated life reliability function, the service life of the specimen can be intuitively predicted, and the prediction results are consistent with the experimental results. According to the analysis results of the grey relational grade, after four cycles, the ƞ_a value of the specimen with a water-cement ratio of 0.53 is 0.36 and 0.65 lower than that of the specimens with water-cement ratios of 0.46 and 0.39, respectively, while the ƞ_b values of the latter two groups of specimens are basically the same, Therefore, the water-cement ratio is the main factor influencing the durability of recycled concrete.
- recycled concrete /
- dry, wet, and freeze-thaw /
- sodium sulfate erosion /
- Weibull distribution /
- sensitivity analysis

HTML全文

图 1 原混凝土强度检测

Figure 1. Original concrete strength testing

下载: 全尺寸图片幻灯片

图 2 模拟河套地区干湿−冻融循环实验制度

Figure 2. Experimental system for simulating dry, wet, and freeze-thaw cycles in Hetao region

下载: 全尺寸图片幻灯片

图 3 质量评价参数ƞ_a

Figure 3. Quality evaluation parameter ƞ_a

下载: 全尺寸图片幻灯片

图 4 动弹性模量评价参数ƞ_b

Figure 4. Dynamic elastic modulus evaluation parameter ƞ_b

下载: 全尺寸图片幻灯片

图 5 不同混凝土类型的微观形貌

Figure 5. Microscopic morphology of different types of concrete

下载: 全尺寸图片幻灯片

图 6 加速寿命数据概率图

Figure 6. Probability of accelerated life data

下载: 全尺寸图片幻灯片

图 7 退化分布曲线

Figure 7. Degradation distribution curves

下载: 全尺寸图片幻灯片

表 1 粗骨料性能

Table 1. Properties of coarse aggregate

类别	堆积密度（kg•m⁻³）	表观密度（kg•m⁻³）	针片状含量/%	压碎指标/%	吸水率/%
类别	堆积密度（kg•m⁻³）	表观密度（kg•m⁻³）	针片状含量/%	压碎指标/%	10 min	24 h
再生粗骨料	1396	2316	5.5	17.9	1.9	3.2
天然粗骨料	1516	2735	1.3	9.5	0.6	1.8

下载: 导出CSV

表 2 粗骨料的粒径与级配

Table 2. Particle size and grading of coarse aggregate

骨料级配	粒径/mm
骨料级配	4.750	9.500	16.000	19.000	26.500	31.500
再生粗骨料	1.000	0.803	0.525	0.275	0.112	0.000
天然粗骨料	1.000	0.831	0.409	0.217	0.039	0.000

下载: 导出CSV

表 3 配合比设计

Table 3. Concrete mix design

试件编号	水灰比	材料用量（kg•m⁻³）						高效引气减水剂/ %	28 d立方体抗压强度/ MPa
试件编号	水灰比	水泥	砂	普通粗骨料	再生粗骨料	水	附加水	高效引气减水剂/ %	28 d立方体抗压强度/ MPa
NC-0.46	0.46	391	804	1024	0	180	0	0.010	57.27
RC-0.53	0.53	340	827	0	1053	180	44.5	0.010	34.77
RC-0.46	0.46	391	804	0	1024	180	43.3	0.010	38.57
RC-0.39	0.39	461	773	0	984	180	41.7	0.010	44.84

下载: 导出CSV

表 4 试件分组

Table 4. Specimen grouping

试件分组	水灰比	溶液浓度/%	抗压强度/MPa
NC-0.46-5%	0.46	5	57.27
RC-0.53-5%	0.53	5	34.77
RC-0.46-5%	0.46	5	38.57
RC-0.39-5%	0.39	5	44.84
RC-0.46-0%	0.46	0	39.23
RC-0.46-10%	0.46	10	37.49
注：NC表示普通混凝土，RC表示再生混凝土，小数表示水灰比，百分数表示NaSO₄浓度.

下载: 导出CSV

表 5 K-S检验结果

Table 5. K-S test results

试件分组	ƞ_a	ƞ_b	D （5,0.05）
NC-0.46-5%	0.264	0.311	0.563
RC-0.53-5%	0.245	0.180
RC-0.46-5%	0.209	0.174
RC-0.39-5%	0.245	0.183
RC-0.46-0%	0.331	0.193
RC-0.46-10%	0.201	0.272

下载: 导出CSV

表 6 参数估计值

Table 6. Parameter estimate

试件编号	m	θ
NC-0.46-5%	5.025	33.197
RC-0.53-5%	2.155	13.488
RC-0.46-5%	1.699	16.907
RC-0.39-5%	2.141	21.092
RC-0.46-0%	1.800	11.354
RC-0.46-10%	3.510	19.184

下载: 导出CSV

表 7 评价指标关联度

Table 7. Correlation grade of evaluation indicators

评价指标	质量（排名）	动弹性模量（排名）
水灰比	0.858（1）	0.728（2）
抗压强度	0.790（2）	0.792（1）
盐溶液浓度	0.751（3）	0.702（3）
循环次数	0.582（4）	0.541（4）

下载: 导出CSV

参考文献(23)

[1]	ZHANG Z Y, ZOU Y, YANG J, et al. Capillary rise height of sulfate in Portland-limestone cement concrete under physical attack: Experimental and modelling investigation[J]. Cement and Concrete Composites, 2022, 125: 104299. doi: 10.1016/j.cemconcomp.2021.104299
[2]	NAJJAR M F, NEHDI M L, SOLIMAN A M, et al. Damage mechanisms of two-stage concrete exposed to chemical and physical sulfate attack[J]. Construction and Building Materials, 2017, 137: 141-152. doi: 10.1016/j.conbuildmat.2017.01.112
[3]	NEHDI M L, SULEIMAN A R, SOLIMAN A M. Investigation of concrete exposed to dual sulfate attack[J]. Cement and Concrete Research, 2014, 64: 42-53. doi: 10.1016/j.cemconres.2014.06.002
[4]	RAHMAN M M, BASSUONI M T. Thaumasite sulfate attack on concrete: mechanisms, influential factors and mitigation[J]. Construction and Building Materials, 2014, 73: 652-662. doi: 10.1016/j.conbuildmat.2014.09.034
[5]	余红发, 刘连新, 曹敬党, 等. 东西部氯盐环境中混凝土的耐久性和服役寿命[J]. 沈阳建筑大学学报(自然科学版), 2022, 25(2): 124-130. YU Hongfa, LIU Lianxin, CAO Jingdang, et al. Durability and service life of concrete exposed to chloride environment of eastern and western China[J]. Journal of Shenyang Jianzhu University (Natural Science), 2022, 25(2): 124-130.
[6]	赵燕茹, 刘芳芳, 王磊, 等. 基于孔结构的单面冻后混凝土抗压强度模型研究[J]. 建筑材料学报, 2020, 23(6): 1328-1336, 1344. ZHAO Yanru, LIU Fangfang, WANG Lei, et al. Modeling of compressive strength of concrete based on pore structure under single-side freeze-thaw condition[J]. Journal of Building Materials, 2020, 23(6): 1328-1336,1344.
[7]	刘燕, 王泽坤, 李忠献, 等. 冻融-干湿耦合循环下粉煤灰混凝土损伤度分析[J]. 混凝土, 2020(5): 32-35, 39. doi: 10.3969/j.issn.1002-3550.2020.05.009 LIU Yan, WANG Zekun, LI Zhongxian, et al. Analysis on the damage degree of fly ash concrete under freeze-thaw-dry-wet coupling cycle[J]. Concrete, 2020(5): 32-35,39. doi: 10.3969/j.issn.1002-3550.2020.05.009
[8]	孔骏, 韩敏, 丁永发, 等. 干湿循环和冻融循环作用下硫酸钠腐蚀对混凝土应力-应变曲线的影响[J]. 宁夏大学学报(自然科学版), 2022, 43(1): 51-55. KONG Jun, HAN Min, DING Yongfa, et al. Effect of sodium sulfate corrosion on stress-strain curve of concrete under dry wet cycle and freeze-thaw cycle[J]. Journal of Ningxia University (Natural Science Edition), 2022, 43(1): 51-55.
[9]	李文霞, 朱忠业. 干湿−冻融交替作用下混凝土受硫酸盐侵蚀研究[J]. 混凝土, 2017(5): 12-14, 18. doi: 10.3969/j.issn.1002-3550.2017.05.004 LI Wenxia, ZHU Zhongye. Sulfate attack on concrete under alternate freeze-thaw and dry-wet cycling[J]. Concrete, 2017(5): 12-14,18. doi: 10.3969/j.issn.1002-3550.2017.05.004
[10]	中华人民共和国住房和城乡建设部. 普通混凝土长期性能和耐久性能试验方法标准: GB/T 50082—2009[S]. 北京: 中国建筑工业出版社, 2009.
[11]	胡杨. 河套湿地水文和植被特征及水体净化潜力[D]. 呼和浩特: 内蒙古农业大学, 2016.
[12]	景宇鹏, 李跃进, 高娃, 等. 不同利用方式河套平原盐碱土盐分特征[J]. 水土保持研究, 2020, 27(1): 372-379. JING Yupeng, LI Yuejin, GAO Wa, et al. Salt characteristics of saline-alkali soil in Hetao Plain with different utilization methods[J]. Research of Soil and Water Conservation, 2020, 27(1): 372-379.
[13]	武海荣. 混凝土结构耐久性环境区划与耐久性设计方法[D]. 杭州: 浙江大学, 2012.
[14]	中国气象局国家气象信息中心. 中国气象科学数据共享服务[DB/OL]. [2023-05-27]. http://data.cma.cn/.
[15]	中华人民共和国住房和城乡建设部, 国家市场监督管理总局. 混凝土物理力学性能试验方法标准: GB/T 50081—2019[S]. 北京: 中国建筑工业出版社, 2019.
[16]	路承功, 乔宏霞, 魏智强, 等. 盐渍土地区混凝土加速损伤劣化机理及基于Wiener过程可靠性分析[J]. 中国矿业大学学报, 2021, 50(2): 265-272, 288. LU Chenggong, QIAO Hongxia, WEI Zhiqiang, et al. Accelerated damage and deterioration mechanism of concrete in saline soil area and reliability analysis based on Wiener process[J]. Journal of China University of Mining & Technology, 2021, 50(2): 265-272,288.
[17]	甘磊, 吴健, 沈振中, 等. 硫酸盐和干湿循环作用下玄武岩纤维混凝土劣化规律[J]. 土木工程学报, 2021, 54(11): 37-46. doi: 10.15951/j.tmgcxb.2021.11.001 GAN Lei, WU Jian, SHEN Zhenzhong, et al. Deterioration law of basalt fiber reinforced concrete under sulfate attack and dry-wet cycle[J]. China Civil Engineering Journal, 2021, 54(11): 37-46. doi: 10.15951/j.tmgcxb.2021.11.001
[18]	李福海, 黄绍宁, 肖赛, 等. 高温-干湿循环作用下混凝土分区抗硫酸盐侵蚀性能研究[J]. 西南交通大学学报, 2026, 61(1): 41-51. LI Fuhai, HUANG Shaoning, LIU Menghui, et al. Resistance against sulfate erosion of concrete partition under high temperature and dry−wet cycle[J]. Journal of Southwest Jiaotong University, 2026, 61(1): 41-51.
[19]	刘慕宸, 崔自治, 宋鑫. 硫酸钠-干湿−冻融共同作用对水泥土性能的影响[J]. 科学技术与工程, 2022, 22(29): 12977-12984. doi: 10.3969/j.issn.1671-1815.2022.29.034 LIU Muchen, CUI Zizhi, SONG Xin. Effects of sodium sulfate on properties of cement-soil under dry-wet and freeze-thaw cycles[J]. Science Technology and Engineering, 2022, 22(29): 12977-12984. doi: 10.3969/j.issn.1671-1815.2022.29.034
[20]	WANG J G, ZHANG J X, CAO D D, et al. Comparison of recycled aggregate treatment methods on the performance for recycled concrete[J]. Construction and Building Materials, 2020, 234: 117366. doi: 10.1016/j.conbuildmat.2019.117366
[21]	刘超, 姚羿舟, 刘化威, 等. 硫酸盐干湿循环下再生复合微粉混凝土的劣化机理[J]. 建筑材料学报, 2022, 25(11): 1128-1135. LIU Chao, YAO Yizhou, LIU Huawei, et al. Deterioration mechanism of recycled composite powder concrete under dry-wet cycles of sulfate[J]. Journal of Building Materials, 2022, 25(11): 1128-1135.
[22]	孙金阳. 混凝土湿润与干燥过程中水分传输规律研究[D]. 杭州: 浙江大学, 2012.
[23]	乔宏霞, 杨安, 杨博, 等. 基于威布尔分布下纳米碳酸钙改性混凝土寿命预测研究[J]. 工业建筑, 2022, 52(1): 174-179. QIAO Hongxia, YANG An, YANG Bo, et al. Research on life prediction of nano-CaCO₃ modified concrete based on weibull distribution[J]. Industrial Construction, 2022, 52(1): 174-179.
