计及阶梯式碳交易的牵引供电系统混合储能容量配置

郭文凯; 王果; 闵永智

doi:10.3969/j.issn.0258-2724.20230693

计及阶梯式碳交易的牵引供电系统混合储能容量配置

doi: 10.3969/j.issn.0258-2724.20230693

郭文凯^{1, 2,},
王果^{1, 2, ,},
闵永智^{1, 2}

1.
兰州交通大学自动化与电气工程学院，甘肃兰州 730070
2.
兰州交通大学甘肃省轨道交通电气自动化工程实验室，甘肃兰州 730070

基金项目: 国家自然科学基金项目（52467007）；甘肃省科技项目重点研发计划（22YF7GA146）

详细信息

作者简介:
郭文凯（1997—），男，博士研究生，研究方向为轨道交通电气化，E-mail：937781902@qq.com

通讯作者:
王果（1977—），女，教授，博士，研究方向为电气化铁路电能质量及拓扑研究，E-mail：wangguo@lzjtu.edu.cn

中图分类号: TM7
计量
- 文章访问数: 129
- HTML全文浏览量: 33
- PDF下载量: 23
- 被引次数: 0
出版历程
- 收稿日期: 2023-12-22
- 修回日期: 2024-07-14
- 网络出版日期: 2025-04-17
- 刊出日期: 2024-07-21

Hybrid Energy Storage Capacity Configuration for Traction Power Supply Systems Considering Ladder-Type Carbon Trading Mechanism

GUO Wenkai^{1, 2
,},
WANG Guo^{1, 2
, ,},
MIN Yongzhi^{1, 2}

1.
School of Automation and Electrical Engineering, Lanzhou Jiaotong University, Lanzhou 730070, China
2.
Rail Transit Electrical Automation Engineering Laboratory of Gansu Province, Lanzhou Jiaotong University, Lanzhou 730070, China

摘要

摘要:
在“双碳”背景下，为推动铁路行业的低碳转型，提出一种以牵引供电系统成本最小为优化目标的混合储能容量配置方法. 首先，考虑多源互补、新能源高效消纳等因素，构建含新能源发电系统、电-氢混合储能系统、牵引供电系统的综合能源系统框架，并给出碳交易市场的交易方案；其次，构建规划-运行模型，其中，规划层确定电-氢混合储能配置方案，运行层引入阶梯式碳交易机制，以计算牵引供电系统的日运行成本；最后，利用改进海鸥优化算法对模型进行求解，结合牵引供电系统与新能源实测数据，验证所提模型的有效性. 结果表明：与仅考虑阶梯式碳交易方案和仅考虑电-氢混合储能方案相比，系统总成本分别降低48%与36%，弃风弃光率则下降11%与3%；与仅考虑阶梯式碳交易搭配单一储能介质（蓄电池或氢储能）方案相比，系统总成本分别降低19%与40%，新能源消纳率则提升4%与6%.
- 牵引供电系统 /
- 阶梯式碳交易机制 /
- 新能源消纳 /
- 电-氢混合储能 /
- 改进海鸥算法
Abstract:
To promote the low-carbon transformation of the railway industry in the context of “carbon peaking and carbon neutrality” , a hybrid energy storage capacity configuration method was proposed, with an optimization objective of minimizing the total cost of the traction power supply system. Firstly, by considering factors such as multi-source complementarity and efficient consumption of new energy, a comprehensive energy system framework integrating new energy generation systems, electric–hydrogen hybrid energy storage systems, and traction power supply systems was constructed, and trading schemes for the carbon trading market were provided. Secondly, a planning–operation model was developed. The electric–hydrogen hybrid energy storage configuration scheme was determined at the planning level, and a ladder-type carbon trading mechanism was introduced at the operation level to calculate the daily operating cost of the traction power supply system. Finally, the improved seagull optimization algorithm was utilized to solve the model, and the actual data of the traction power supply system and new energy were combined to verify the effectiveness of the proposed model. The results show that compared with that of scenarios considering only ladder-type carbon trading schemes or electric–hydrogen hybrid energy storage schemes, the total system cost of the proposed method is reduced by 48% and 36%, respectively, while the renewable energy curtailment rate decreases by 11% and 3%, respectively. Compared with that of scenarios considering only ladder-type carbon trading combined with single energy storage media (battery or hydrogen energy storage), the total system cost is reduced by 19% and 40%, respectively, while the new energy consumption rate is improved by 4% and 6%, respectively.
- traction power supply system /
- ladder-type carbon trading mechanism /
- new energy consumption /
- electric–hydrogen hybrid energy storage /
- improved seagull optimization algorithm

HTML全文

图 1 系统框架

Figure 1. System framework

下载: 全尺寸图片幻灯片

图 2 模型结构

Figure 2. Model structure

下载: 全尺寸图片幻灯片

图 3 系统运行控制策略

Figure 3. Operation and control strategy of the system

下载: 全尺寸图片幻灯片

图 4 模型求解流程

Figure 4. Model solving process

下载: 全尺寸图片幻灯片

图 5 牵引负荷功率

Figure 5. Traction load power

下载: 全尺寸图片幻灯片

图 6 新能源功率

Figure 6. New energy power

下载: 全尺寸图片幻灯片

图 7 混合储能响应结果

Figure 7. Response results of hybrid energy storage

下载: 全尺寸图片幻灯片

图 8 系统功率平衡

Figure 8. System power balance

下载: 全尺寸图片幻灯片

图 9 牵引所功率曲线

Figure 9. Traction substation power curves

下载: 全尺寸图片幻灯片

图 10 碳交易收益与总成本变化情况

Figure 10. Variations in carbon trading benefit and total cost

下载: 全尺寸图片幻灯片

图 11 不同算法模型结果

Figure 11. Results of different algorithm models

下载: 全尺寸图片幻灯片

表 1 牵引所1各部分功率

Table 1. Power of components at traction substation 1 kW

时间	牵引负荷总功率	光伏发电总功率	风力发电总功率	蓄电池总功率	电解槽总功率	燃料电池总功率	弃风弃光总功率	外部电网总功率	再生制动能量回收总功率	控制策略
8 ：10—8 ：30	31203	4137	11862	15204	0	0	0	0	0	E
9 ：30—9 ：35	−8800	5203	4827	−9000	−3600	0	0	0	2570	D
12 ：10—12 ：20	−2016	16804	10951	−13500	−5400	0	8855	0	0	C
12 ：40—12 ：45	16500	11541	7625	−2666	0	0	0	0	0	A
13 ：40—13 ：45	7333	11232	7990	−9000	−2889	0	0	0	0	B
18 ：15—18 ：20	33697	936	7355	9000	0	2400	0	14006	0	G
18 ：25	9460	371	3659	4500	0	930	0	0	0	F

下载: 导出CSV

表 2 不同牵引所运行结果对比

Table 2. Comparison of operation results of different traction substations

牵引供电所	系统总成本/万元	碳交易成本/万元	弃风弃光率/%	外部电网出力占比/%
1	10067	−363	6	6
2	8125	−525	4	2

下载: 导出CSV

表 3 不同牵引所储能配置结果对比

Table 3. Result comparison of different energy storage configurations for traction substations kW

牵引变电所	蓄电池功率	电解槽功率	燃料电池功率
1	4500	1800	1200
2	6300	2400	960

下载: 导出CSV

表 4 不同方案结果对比

Table 4. Result comparison of different schemes

方案	总成本/ 万元	碳交易成本/万元	弃风弃光率/%	外部电网出力占比/%	蓄电池功率/kW	电解槽功率/kW	燃料电池功率/kW
1	19523	1321	17	32	0	0	0
2	12381	−165	10	25	6842	0	0
3	16548	−124	12	23	0	2854	3664
4	15698	0	9	16	3657	886	653
5	10067	−363	6	6	4500	1800	1200

下载: 导出CSV
