隧道入口侧风条件下高速铁路隧道内流场特性

骆建军

doi:10.3969/j.issn.0258-2724.2017.04.013

隧道入口侧风条件下高速铁路隧道内流场特性

doi: 10.3969/j.issn.0258-2724.2017.04.013

骆建军^1,2

基金项目:

国家863计划资助项目（2011AA11A103）

国家自然科学基金资助项目（51678036，51178030）

详细信息

作者简介:
骆建军(1971—),男,副教授,博士,研究方向为高速铁路隧道空气动力学,电话:13611303609,E-mail:jj_luo@126.com

计量
- 文章访问数: 685
- HTML全文浏览量: 109
- PDF下载量: 201
- 被引次数: 0
出版历程
- 收稿日期: 2015-12-06
- 刊出日期: 2017-08-25

Tunnel Entrance Field Characteristics Induced by High Speed Train with Crosswind at Entrance

LUO Jianjun^1,2

摘要

摘要: 为了保证高速列车在隧道入口有侧风环境中的安全，采取数值分析的方法，建立高速列车进入隧道口存在侧风时的三维可压缩、粘性、非稳态湍流数学模型，研究了当隧道洞口有无侧风和隧道洞口侧风速度变化时隧道内的压力变化以及隧道内活塞风的变化规律.研究结果表明：隧道入口存在侧风时，隧道内测点先出现负压力峰值，后逐渐上升到正压力峰值；随着压缩波的向前传播，波形逐渐分化成两个波峰，并且压缩波越往前传播，第一个波峰逐渐消失，第二个波峰得到加强，其波峰的正压峰值超过无侧风时的最大正压峰值；隧道内速度场出现明显的非对称性，隧道内靠近迎风一侧的环状空间的列车风比背风一侧环状空间的小，背风一侧隧道入口处出现比较明显的涡流，侧风速度越大，最大负压值绝对值越大，隧道内测点的最大正压值、最大负压值均与侧风的速度成正比；当列车速度为350 km/h，侧风速度到达40 m/s时，隧道内活塞风的速度可达21.8 m/s，隧道内的压缩波的最大负压值可达-6 547 Pa.
- 高速列车 /
- 隧道 /
- 压缩波 /
- 速度 /
- 侧风
Abstract: In order to ensure the safety of high speed trains under the existing geographical landscape, a numerical simulation was performed to study the aerodynamic effects of crosswinds at the tunnel entrances. The results of the model show that a crosswind at the tunnel entrance creates a negative pressure peak at the measuring point in the tunnel, and that the pressure increases to a positive peak when there is no crosswind. As the crosswind decreases, the simulated compression wave propagates forward and gradually form two peaks. As the wind speeds progressively decrease, the first compression wave peak gradually disappears and the second peak strengthens to the values above the positive pressure peak when no crosswind is present. Further evaluation of the simulated results showed the piston wind is smaller on the upwind side of the annular space than the leeward side when a crosswind is present at the tunnel entrance. It creates a significant eddy current on the leeward side of the entrance to the tunnel. When the crosswind velocity reaches 40 m/s, the piston wind can reach the velocities of 21.8 m/s. When the crosswind velocity is high, the compression wave at the measured point displays a smaller maximum value and the maximum negative pressure value increases. The maximum negative pressure value and crosswind velocity are proportional to the overall pressure, but the increases in amplitude of the maximum negative peak are greater than the maximum positive pressure increase. When the crosswind velocity reaches 40 m/s, the compression wave in the tunnel can reach a maximum negative pressure value of -6 547 Pa.
- high-speed train /
- tunnel /
- pressure wave /
- velocity /
- cross wind

HTML全文

参考文献(32)

FUKUCHI G. A method of aerodynamics drag abatement for high speed train in single-tunnel[C]//Proceeding of First International Conference on Vehicle Mechanics. Detroit: Swets Zeitlinger, 1968: 68-87.

WOODS W A, POPE C W. Secondary aerodynamic effects in rail tunnels during vehicle entry[C]//Proceedings of the Second International Symposium on the Aerodynamics and Ventilation of Vehicle Tunnels. Cranfield: BHRA, Fluid Engineering, 1976: 71-86.

AOKI T, MATSUO K, HIDAKA H, et al. Attenuation and distortion of propagating compression waves in a high-speed railway model and real tunnels[C]//20th International Symposium on Shock Waves. Marseille: World Scientific, 1996: 347-352.

POPE C W, GAWTHORPE R G, RICHARDS. An experimental investigation into the effect of train shape on the unsteady flows generated in tunnels[C]//The 4th International Symposium on the Aerodynamics and Ventilation of Vehicle Tunnels. Cranfield: BHRA, 1982: 107-128.

赵汗青,薛雷平,向新桃,等. 高速列车穿越隧道时压强时间导数的影响因素及其分析[J]. 力学季刊,2012,33(1): 15-20. ZHAO Hanqing, XUE Leiping, XIANG Xintao, et.al. Analysis of the influence factor on time rate of pressure by a high speed train entering tunnel[J]. Chinese Quarterly of Mechanics, 2012, 33(1): 15-20.

贾永兴,杨永刚,梅元贵. 基于一维流动模型的高速列车隧道压力波特性[J]. 机械工程学报,2014,50(24): 106-114. JIA Yongxing, YANG Yonggang, MEI Yuangui. Characters of pressure wave caused by high-speed trains passing tunnels based on 1D non-homentropic flow model[J]. Journal of Mechanical Engineering, 2014, 50(24): 106-114.

WILLIAM-LOUIS M J P, GR GOIRE R. 1-d calculations of pressure fluctuation outside and inside a pressure sealed high speed trainset traveling throughtunnels[C]//Notes on Numerical Fluid Mechanics and Multidisciplinary Design 79. Berlin: Springer-Verlag, 2002: 342-357.

HOWE M S. On the compression wave generated when a high-speed train enters a tunnel with a flared portal [J].Journal of Fluids and Structures,1999, 13(4): 481-498.

骆建军,高波,王英学,等. 高速列车穿越隧道时二维非定常流的数值模[J]. 铁道学报,2003,25(2): 68-73. LUO Jianjun, GAO Bo, WANG Yingxue, et al. Numerical simulation on an unsteady two dimension flow produced by high-speed train passing a tunnel[J]. Journal of the China Railway Society, 2003, 25(2): 68-73.

梅元贵,贾永兴. 单列高速列车通过内置开孔隔墙隧道时的压力波数值分析[J]. 铁道学报,2013,35(12): 95-100. MEI Yuangui, JIA Yongxing. Numerical investigation on pressure waves produced by a high-speed train passing through a tunnel with perforated wall[J]. Journal of the China Railway Society, 2013, 35(12): 95-100.

李人宪,关永久. 高速列车隧道会车压力波动问题[J]. 机械工程学报,2012,48(20): 127-134. LI Renxian, GUAN Yongjiu. Investigation of air pressure pulse when two high-speed trains passing by each other in tunnel[J]. Journal of Mechanical Engineering, 2012, 48(20): 127-134.

费瑞振,彭立敏,杨伟超,等. 高速铁路隧道空气动力效应对人员安全的影响研究[J]. 中国安全科学学报,2013,23(7): 79-84. FEI Ruizhen, PENG Limin, YANG Weichao, et al. Study on aerodynamic force effect on personnel safety inhigh-speed railway tunnel[J]. China Safety ScienceJournal, 2013, 23(7): 79-84.

赵宇. 高速铁路隧道竖井形状和面积对气动效应的影响研究[D]. 成都:西南交通大学,2007.

骆建军,姬海东. 高速列车进入有缓冲结构隧道的压力变化研究[J]. 铁道学报,2011,33(9): 114-118. LUO Jianjun, JI Haidong. Study on changes of pressure waves induced by a high-speed train entering into a tunnel with hood[J]. Journal of the China railway Society, 2011, 33(9): 114-118.

李人宪,关永久,赵晶,等. 高速铁路隧道缓冲结构的气动作用分析[J]. 西南交通大学学报,2012,47(2): 175-180. LI Renxian, GUAN Yongjiu, ZHAO Jing, et al. Aerodynamic analysis on entrance hood of high-speed railway tunnels[J]. Journal of Southwest Jiaotong University, 2012, 47(2): 175-180.

余南阳,雷波,许志浩,等. 高速列车隧道压力波浅水槽模拟试验研究[J]. 铁道学报,2004,26(2): 52-55. YU Nanyang, LEI Bo, XU Zhihao, et al. Shallow-water simulation experiment and study of pressure waves produced when a high speed train enters a tunnel[J]. Journal of the China Railway Society, 2004, 26(2): 52-55.

王英学,骆建军,李伦贵,等. 高速列车模型试验装置及相似特征分析[J]. 西南交通大学学报,2004,39(1): 20-24. WANG Yingxue, LUO Jianjun, LI Lungui, et.al. Model experiment system for high-speed trains and analysis of its similarity[J]. Journal of Southwest Jiaotong University. 2004, 39(1): 20-24.

WHITE W R, POPE C W. The use of a hydraulic analogy for modeling the unsteady flows in railway tunnels[C]//Proc. of 3rd Int. Symp. on the Aerodynamics and Ventilation of Vehicle Tunnels(Paper H1). Sheffield:[s.n. ], 1979: 35-43.

DAYMAN B, VARDy A E. Alleviation of tunnel air pressure transients(1): experimental program[C]//Proc. of 3rd Int. Symp. on the Aerodynamics and Ventilation of Vehicle Tunnels(Paper H2). Sheffield:[s.n. ], 1979: 32-41.

OZAWA S, TANEMOTO K, MAEDA T. Model experiments on devices to reduce perssure wave[R]. Tokyo: Railway Technical Research Institute, 1976.

韩坤,田红旗. 客运专线隧道空气动力学实车测试技术的研究与应用[J]. 中南大学学报:自然科学版,2007,38(2): 326-332. HAN Kun, TIAN Hongqi. Research and application of testing technology of aerodynamics at train-tunnel entry on special passenger railway lines[J]. Journal of Central South University: Science and Technology, 2007, 38(2): 326-332.

马伟斌,张千里,程爱军,等. 高速铁路隧道洞口微气压波影响因素与变化规律研究[J]. 铁道学报,2013,35(5): 97-102. MA Weibin, ZHANG Qianli, CHENG Aijun, et al. Study on influence factors and changing law of micro-pressure waves at tunnel portals of high-speed railways[J]. Journal of the China Railway Society, 2013, 35(5): 97-102.

马伟斌,俞瀚斌,付连著,等. 某特长水下隧道气动效应试验研究[J]. 中国铁道科学,2012,33(1): 41-46. MA Weibin, YU Hanbin, FU Lianzhu, et al. Experimental research on the aerodynamics effect ofan extra-long underwater tunnel[J]. China Railway Science, 2012, 33(1): 41-46.

周丹,田红旗,杨明智,等. 强侧风下客车在不同路况运行的气动性能比较[J]. 中南大学学报:自然科学版,2008,39(3): 554-559. ZHOU Dan, TIAN Hongqi, YANG Mingzhi, et al. Comparison of aerodynamic performance of passenger train traveling on different railway conditions up strong cross-wind[J]. Journal of Central South University: Science and Technology, 2008, 39(3): 554-559.

张洁,梁习峰,刘堂红,等. 强侧风作用下客车车体气动外形优化[J] 中南大学学报:自然科学版,2011,42(11): 3578-3584. ZHANG Jie, LIANG Xifeng, LIU Tanghong, et al. Optimization research on aerodynamic shape of passenger car body with strong crosswind[J]. Journal of Central South University: Science and Technology, 2011, 42(11): 3578-3584.

任尊松,徐宇工,王璐雷,等. 强侧风对高速列车运行影响研究[J]. 铁道学报,2006,28(6): 46-50. REN Zunsong, XU Yugong, WANG Lulei, et al. Study on the running safety of high-Speed trains under strong cross winds[J]. Journal of the China Railway Society, 2006, 28(6): 46-51.

毛军,郗艳红,杨国伟. 侧风风场特征对高速列车气动性能作用的研究[J]. 铁道学报,2011(4): 22-30. MAO Jun, XI Yanhong, YANG Guowei. Study on crosswind wind field characteristics of dynamic performance of high speed train gas effect[J]. Journal of the China Railway Society, 2011(4): 22-30.

崔涛,张卫华,王琰. 侧风环境下列车高速交会流固耦合振动安全性分析[J]. 振动与冲击,2013,32(11): 75-79. CUI Tao, ZHANG Weihua, WANG Yan. High speed train rendezvous and fluid solid coupling vibration safety analysis under crosswind conditions[J]. Journal of Vibration and Shock, 2013, 32(11): 75-79.

崔涛,张卫华. 侧风环境下列车高速通过站台的流固耦合振动[J]. 西南交通大学学报,2011,46(3): 403-408. CUI Tao, ZHANG Weihua. The vibration of High-speed train through the fluid-structure coupling of platform under crosswind conditions[J]. Journal of Southwest Jiaotong University, 2011, 46(3): 403-408.

董香婷,党向鹏. 风障对侧风作用下列车行车安全影响的数值模拟研究[J]. 铁道学报,2008,30(5): 36-40. DONG Xiangting, DANG Xiangpeng. Numerical simulation study on traffic safety of trains under crosswind the windbreak effect[J]. Journal of the China Railway Society, 2008,36(5): 36-40.

毕海权,雷波,张卫华. 高速磁浮列车会车压力波数值计算研究[J]. 空气动力学学报,2006,24(2): 213-217. BI Haiquan, LEI Bo, ZHANG Weihua. Numerical study of the pressure load caused by high-speed passing maglev trains[J]. ACTA Aerodynamic Sinica, 2006, 24(2): 213-217.

骆建军.高海拔地区高速铁路隧道空气动力学特性[J]. 西南交通大学学报,2016,54(1): 607-614. LUO Jianjun. Aerodynamic effect induced by high-speed train entering into tunnel in high altitude area[J]. Journal of Southwest Jiaotong University. 2016, 54(1): 607-614.
