ZENG Yongping, LIU Liwei, TAO Qi, WAN Xing, ZHANG Xun, JIA Hongyu. Analysis of Impact Effect of Cable Breakage in Half-Through Railway Arch Bridges with CFRP Cables[J]. Journal of Southwest Jiaotong University. doi: 10.3969/j.issn.0258-2724.20240555
Citation: ZENG Yongping, LIU Liwei, TAO Qi, WAN Xing, ZHANG Xun, JIA Hongyu. Analysis of Impact Effect of Cable Breakage in Half-Through Railway Arch Bridges with CFRP Cables[J]. Journal of Southwest Jiaotong University. doi: 10.3969/j.issn.0258-2724.20240555

Analysis of Impact Effect of Cable Breakage in Half-Through Railway Arch Bridges with CFRP Cables

doi: 10.3969/j.issn.0258-2724.20240555
  • Received Date: 29 Oct 2024
  • Rev Recd Date: 28 Feb 2025
  • Available Online: 10 Jul 2025
  • To study the effect of cable breakage on the impact response of concrete-filled steel tube arch bridges and the difference in safety factor requirements between carbon fiber reinforced polymer (CFRP) cables and steel cables, the dynamic response of a railway bridge under accidental cable breakage was analyzed. A spatial finite element model was established by ANSYS. The force characteristic variations of the residual structure of the arch bridge under five cable breakage conditions were studied based on the equivalent unloading method. The impact sensitivity of the structure after cable breakage was evaluated by dynamic amplification factor (DDAF) and demand capacity ratio (DDCR). The effects of different cable materials, namely steel cables and carbon cables, on the dynamic response of the arch bridge were compared. The results show that the dynamic response of the main girder and the stress of the arch rib are greatly affected by the position and number of cable breakages. The redistribution ratio of the cable force is inversely proportional to the distance from the broken cable area and the cable length and directly proportional to the number of failed cables. The DDAF of the arch bridge with carbon cables is higher than that of the arch bridge with steel cables, ranging from 1.19 to 1.43. The DDCR of the remaining cable after cable breakage does not exceed 1, indicating large redundancy. Compared with bridges with steel cables, arch bridges with carbon cables require smaller safety factors under cable breakage conditions, ranging from 1.0 to 1.5.
